| What |
Technical details |
Manuals |
whd
orig |
Inv.Nr.
|
Where
|
| |
|
|
|
|
|
| ACOM 2000A
2001 |
Short wave linear amplifier 1.8 - 30 MHz, remote control
via serial line, automatic tune-up, two 4CX800 tubes, over
2000 W PEP output, built-in 230 VAC power supply |
Copy |
bo |
RA0000500 |
os
|
| |
|
|
|
|
|
| AGA Baltic 353 1942 |
Swedish long, medium and shortwave
broadcast receiver, tubes ECH11 EF11 EBF11 EL11 EM4 AZ11 |
|
nickel |
RA0000750 |
ra-ku
|
| |
|
|
|
|
|
| Aleksandrov Radio
Works Wolna-K 1960 |
Russian maritime Receiver 12 kHz
to 20 MHz |
|
HA1UK (Laa) |
RA0208000 |
ra-lkk
|
| |
|
|
|
|
|
| Alinco Works DR-599T/E 19xx |
Mobile radio for VHF (50W) and UHF
(35W), supply 12VDC |
|
oe5wgl |
RA0000900 |
al-fu
|
| |
|
|
|
|
|
|
AME 7G-1680
1950
|
Shortwave receiver 1.68 - 40 MHz,
the "biggest and heaviest" in the collection (surface
taken up = 0.4m2, weight 65 kg) and the only one using a
"magic eye", power supply built in, with shock absorbers
for vehicle operation. This thing would cost 200000
French Francs in 1950 (about 10 - 20 average annual
salaries or appr. 20000 EUR in today's money). Pour les
Français: Conversion de la valeur en 1950 à 1660 unités
(heures de travail) "SMIG", reconversion avec le SMIC
2010 pour la même quantité donnerait 13000€. La
conversion monnétaire pure et simple donnerait 300€
valeur 1950, ou bien 1.05 fois la puissance de 60 fois
300 égal 5600€. Valeur d'echange entre collectionneurs:
quelques centaines d'Euros selon état de l'appareil |
Technical folder |
SAR Marseille |
RA0001000 |
ra-lkk
|
| |
|
|
|
|
|
| Ameritron ALS-500M 2019 |
Short wave linear amplifier 3 - 30 MHz for vehicular
use, 4 power transistors, 500 W PEP output, power supply
12VDC 80A |
orig |
wza |
RA0001900 |
al-k1
|
| Ameritron AL-800
2013 |
Short wave linear amplifier 1.8 - 30 MHz, single 3CX800
tube, 1200 W PEP output, built-in 230 VAC power supply |
Copy |
fmj |
RA0002000 |
al-k2
|
| |
|
|
|
|
|
|
AMP Supply LK-500ZA 1988
|
Shortwave amateur linear
amplifier, 2 tubes 3-500Z (presently 4-400A from
Amperex), supply 230VAC. Main transformer missing and
replaced by temporary HV-transformer, heater transformer
not original, 10m input circuit missing, wiring
partially removed; unit could so far not be tested. |
copy but not precisely for this
model |
gkw |
RA0001500 |
al-fu |
| |
|
|
|
|
|
AMTRON UK-965
1972 |
Tuned preconverter for car AM-radio, converting the 26 -
28 Mhz band to a fixed frequency of 1600kHz, supply 12VDC |
|
Nick |
RA0002500 |
al |
| |
|
|
|
|
|
| AN/ARC-27 |
Airborne tactical radio transceiver RT178 from the
fifties, covering 200 - 399.9 MHZ, supply 28VDC |
None |
Her |
RA0002600 |
al-k2 |
| AN/ARC-34B |
Airborne tactical radio transceiver RT463A from the
fifties, covering 200 - 399.9 MHZ, supply 28VDC |
None |
Her |
RA0002700 |
al-k2 |
| AN/GRC-7 |
Mobile tactical radio unit from WWII into the sixties;
RT68/GRC, AM65/GRC, RT110/GRC, PP112/GRC, main frame; used
as the original display unit for the Austrian Dodge radio
car ("Lohner Dodge") |
Original |
jacqu |
RA0003000 |
ra-lkk
|
| AN/VRC-7 |
Mobile tactical radio unit from WWII into the sixties;
RT70/GRC, AM65/GRC, main frame, runs on 24VDC |
Original |
Nick |
RA0003100 |
ra-lkk
|
| AN/VRC-7 |
Mobile tactical radio unit from WWII into the sixties;
RT70/GRC, AM65/GRC, main frame, runs on 24VDC |
Original |
Nick |
RA0003200 |
ra-lkk
|
| |
|
|
|
|
|
| Autophon E-44 1940 |
Swiss general coverage shortwave receiver using D1F's
for all stages, separate 220 VAC power supply E-44Z
with AF-amplifier (EBL21) and speaker. part of radio
station M1K
|
|
jos |
RA0004000
PC0004700
|
al-k2
|
| Autophon E-627 1954 |
Swiss general coverage shortwave receiver, built-in 220
VAC power supply or chopper power supply Z 627/1,
original carrying box |
Copy |
oth |
RA0004000 |
ra-lkk
|
| Autophon E-628 1955 |
Swiss general coverage VHF receiver, built-in 220 VAC
power supply or chopper power supply Z 627/1,
kept its "Revue"-clock plus a few accessories for a wire
antenna, tube complement ECC84, EF85, EF80, ECC81,
3xEF85, 6BN6, EF86, EL91, 2xEBF80, EL91 and EZ80 as
rectifier. |
Original |
huel |
RA0005000 |
ra-lkk
|
| Autophon SE 18TT 19?? |
Government radio set for the 2m
band |
Copy |
bhb |
RA0005100 |
al-k1
|
| |
|
|
|
|
|
| BBC SE-221 1969 |
FM radio set for flood warning,
with original remote control unit |
Original |
Nick |
RA0005500 |
al
|
| |
|
|
|
|
|
Belcom Liner 430
1976 |
70cm SSB/CW mobile transceiver,
supply 12VDC, with Belcom
microphone
|
None
|
vla |
RA0005600 |
al-bu |
| Belcom LS707
1976 |
70cm all mode base station
transceiver, supply 12VDC, with Belcom microphone |
Colour copy
|
vla |
RA0005650 |
al-680Fu |
| |
|
|
|
|
|
BC-312
(Unknown maker) 1936
|
WW II short wave radio receiver
(part of SCR-399) |
Original
French SCR-399 manual |
phil |
RA0006000 |
ra-lkk
|
BC-312 1936
|
WW II short wave radio receiver
(part of SCR-399) |
Original French
SCR-399 manual |
phil |
RA0007000 |
ra-lkk
|
BC-312 1936
|
WW II short wave radio receiver,
built by Farnsworth, built in PS 220VAC (part of SCR-399) |
Original French
SCR-399 manual |
tief |
RA0007002 |
ra-kü
|
BC-314 1939
|
WW II long wave radio receiver
(part of SCR-399),
AF stage missing, power connector replaced by tube
socket |
Original French
SCR-399 manual |
phil |
RA0008000 |
ra-lkk
|
BC-342N 1940
|
WW II short wave radio receiver
(part of SCR-399) |
Original French
SCR-399 manual |
oe5mbl |
RA0009000 |
al-ku
|
BC-342N 1940
|
WW II short wave radio receiver
(part of SCR-399) |
Original French
SCR-399 manual |
phil |
RA0010000 |
ra-lkk
|
BC-348 (Unknown maker)
1940
|
WW II radio receiver with French
markings |
|
F5SDT |
RA0011000 |
al-k1
|
BC-348-K (Unknown maker) 1941
|
WW II radio receiver,
US-production, built-in 220VAC-supply
|
|
bhb |
RA0011100 |
al-k2
|
BC-603 (Unknown
maker) 1942
|
FM revceiver 20 - 28 MHz with a small home made power
supply |
|
tannen |
RA0012000 |
al-wo |
BC-1306
1944
|
Shortwave backpack transceiver from WW2, 3.8 - 6.5 MHz,
final 2E22, 1.5V and 550V supply, also known as SCR-694,
predecessor of AN/GRC-9 |
|
tannen |
RA0013000 |
al-wo |
| |
|
|
|
|
|
| Berger 11187 1950 |
Shortwave radio station for government use, range 3 to 6
MHz, complete station with accessories
|
SNr. 204, copy |
bhb |
RA0013500 |
ra-wk
|
| Berger 11187 1950 |
Shortwave radio station for government use, range 3 to 6
MHz, receiver only, no cables, no accessories, calibration
button missing.
|
SNr. 120 |
neul |
RA0013510 |
al-k1
|
| Berger 11187 1950 |
Shortwave radio station for government use, range 3 to 6
MHz, transmitter part only
|
SNr. 186 |
mwag |
RA0013520 |
al-fu |
| Berger 11187 1950 |
Shortwave radio station for government use, range 3 to 6
MHz, complete station but without accessories
|
Ser.Nr. 178 (RX) and 172 (TX) |
dkw |
RA0013530 |
ra-kü |
| |
|
|
|
|
|
| Biennophone E-606 1966 |
FM, shortwave, mediumwave, longwave and wire broadcast
portable receiver for Swiss civil protection, 9V battery
or 220VAC, transistorised, internal, telescopic or
external antenna on spool, connection hardware for cable
broadcast - condition unknown |
|
ri |
RA0014000 |
al-fu
|
| Biennophone E-606
1966 |
FM, shortwave, mediumwave, longwave and wire broadcast
portable receiver for Swiss civil protection, 9V battery
or 220VAC, transistorised, internal, telescopic or
external antenna on spool, connection hardware for cable
broadcast, original transport box |
Original |
ri |
RA0015000 |
al-k1
|
| |
|
|
|
|
|
| Blaupunkt Sevilla 110°
4N 70444 1962 |
BW TV receiver VHF bands I and III, Band IV (UHF)
existed as option, 23 tubes: PCC88 PCF82 EF183 EF80 PCL84
PM84 PCF82 EF184 PABC80 PL82 ECH81 ECC81 PCL82 PL36 PY88
DY86 AW53-88 Semi-conductors K1,5/20 G5/2 OA160 OA261
G5/61 RL43 RL34 E50C5 E220C400
|
|
kaheiho |
RA0015500 |
ra-lkk
|
| Blaupunkt Derby
1962 |
Transistorised medium, long and short wave and FM
receiver running off car or own battery; designed to be
used in car or, being pulled out, as a protable home
radio. Small corrosion in battery box, UKW ("FM" contacts
need pushing up the button to make contact) |
|
ri |
RA0016000 |
al
|
| Blaupunkt Derby
H 1969 |
Medium, long and short wave and FM receiver running 9VDC
or 220VAC power |
|
Ge Fl |
RA0017000 |
al |
| Blaupunkt KV900
1965 |
Shortwave preconverter for long/medium wave automobile
radios, 12V, negative earth, transistorised |
|
eb |
RA0018000 |
al
|
| Blaupunkt Köln
Tr G92xxx Series 1956 |
LW MW FM-Band Car radio, stamped 17. August 1957 on the
inside of the lower cover, specially made for Porsche 356,
12VDC supply, using the latest generation of tubes (ECC85,
EF89, ECH81, EBF89, EABC80, ECF80, EC92) plus two
transistors TF80/30 and one TF80/30z for audio final and
power conversion circuits, the world's first automatic
scan/lock function for FM transmitter tuning is working
extremely well, very good receiver working fine on all
bands without any switchover problems. Original knobs
available, as well as the triple colour sensitivity switch
for the automatic scan/lock. Two different speaker output
impedances for optimum matching. Connection cable for
other audio equipment attached. Take care: Audio-in and
audio-out must be bridged on this cable (normally done by
a special plug), otherwise the radio won't work.
Volume/bass/treble potentiometer also houses power
contact, which is broken. Therefore the power connection
cable is modified and enters the converter unit rather the
main radio. The radio has an original additional plastic
half housing for mounting it outside the dashbord. |
|
ri |
RA0019000 |
al
|
| Blaupunkt London
RDM105 |
Car radio with CD, MW and FM, keycard, works but volume
control microswitches make trouble. |
|
ri |
RA0020000 |
al
|
| |
|
|
|
|
|
| Braun BSK239
1939 |
Portable broadcast heterodyne receiver for long, medium
and short wave, tubes KK2 KF4 KBC1 KDD1, battery supply
2VDC and 120VDC, expensive high performance design with a
price tag around 250RM (1/3 of the cheapest car), red (!!)
version
|
|
dorr |
RA0021100 |
al-fu |
| Braun HM
6-81 1958 |
"Musikschrank" model HM 6-81 with stereo receiver, disc
player and ample space for vinyl-discs |
|
bo-mar |
RA0021000 |
al-wo |
| |
|
|
|
|
|
| Central Electronics Multiphase Exciter
20A 1952 |
SSB exciter, tubes 3xECC81 (12AT7), ECF82 (6U8), EH-type
(6BA7), EM-type (6E5), ECC-type (12BH7), 2xED-type (6AG7),
EB91 (6AL5), rect.-type (5U4G), supply 110/220VAC, 160 -
10m amateur bands, crystal controlled or external VFO,
output 20WPEP, mass 16kg |
|
gkw |
RA0022000 |
ra-kü
|
| Central Electronics 100V 1952 |
Frequency coverage 3.5 to 4.5 MHz, 6.5 to 7.5 MHz, 13.5
to 14.5 MHz, 20.5 to 21.5 MHz and 27.7 to 29.7 MHz. Nine
operating modes: FSK, CW, PM, AM, LSB, USB, DSB, LS-C,
US-C. Phasing SSB generation and PA with broad-band
couplers, no tuning needed; Power output: 100 watts PEP
SSB. Audio limiter module missing!
|
|
ri |
RA0022050 |
ra-lkk
|
| |
|
|
|
|
|
| Charkov_Radio_Works R-250M2 1966 |
Military shortwave radio receiver |
Original |
tief |
RA0021200 |
al-k1
|
| Charkov_Radio_Works R-310 1957 |
Military shortwave radio receiver, 1.5 - 25MHz using 16 penthodes 2Ж27Л |
Original |
anzess |
RA0021250 |
al-tr
|
| Charkov_Radio_Works R-355 1966 |
Military shortwave panorama adapter and burst decoder |
Original |
tief |
RA0021300 |
al-k1
|
| |
|
|
|
|
|
| Collins T-195/GRC-19 |
1.5-20 MHz, 100 W AM/CW/FSK
transmitter for vehicular use, supply 28 VDC at 44A,
mass 55kg, 560 by 290 by 360mm, tubes E91AA, 2xEF93,
3xECC83, 2xQE03/10, E82CC, EF94, 2x6AK6 (1W EL-type),
3xEL90, 2xECC81, 150C2, 3x QEL1/150H |
|
pwm |
RA0023000 |
ra-to2
|
| Collins T-368F/URR |
RF deck only |
|
ji |
RA0023500 |
al-k2
|
| Collins T-368E/URR
1951 |
Transmitter modified into a
shortwave linear amplifier using 2 parallel tubes of
type 4-400A (QB4/1100) in triode-grounded-grid
configuration, plus heater transformer and a three phase
power supply supplying the anodes. |
|
xrm |
RA0023550 |
al-fu
|
| Collins T-368F/URR |
1.5-20 MHz 400 W AM/CW/FSK
transmitter for vehicular use, supply 115/230 V 50 - 400
Hz at 1.2kVA, mass 350kg (repaired and tested Xmas 2007
- the unit had 26 major faults because it was officially
put out of service prior to selling. Fortunately no key
elements were smashed.) Presently qrv with 75-A4
receiver and dynamic microphone preamplified with a
small mixing table. |
Copy of all army manuals |
ji |
RA0023600 |
ra-lkk
|
Collins 51J-4 1957
|
1.8 - 30 MHz professional radio
receiver (also called R-388) |
2 copies, various web-descriptions |
wgl50 |
RA0025000 |
ra-lkk
|
Collins 75A-4 1955
|
1.8 - 30 MHz amateur radio
receiver, with three mechanical filters, the only "A"
Collins that is designed to operate also in mode SSB
|
original |
GI3NUM |
RA0026000 |
ra-lkk
|
Collins 51S-1 1959
|
0.5 - 30 MHz professional radio
receiver, with three mechanical filters, power cord,
manual |
original |
9A |
RA0027000 |
al-wo |
Collins DL-1 1960
|
dummy load 52 Ohms (listed under
aerials) |
|
GI3NUM |
AR0001500 |
al
|
Collins R-392/URR 1954
|
0.5-32 MHz in 1MHz segments, all
bands are equipped, supply 28 V 5 A |
Original army manual |
W8 |
RA0029000 |
al-k2
|
Collins R-392/URR (license
Stewart Warner) 1954
|
0.5-32 MHz in 1MHz segments, all
bands are equipped, supply 28 V 5 A |
|
OE5MBL |
RA0030000 |
al-ku
|
Collins R-392/URR 1954
|
0.5-32 MHz in 1MHz segments, all
bands are equipped, supply 28 V 5 A |
|
OE5PWM |
RA0030020 |
ra-to2
|
Collins R-392/URR 1954
|
0.5-32 MHz in 1MHz segments, all
bands are equipped, supply 28 V 5 A, dismounted, VFO
broken, IF section bad |
|
W8 |
RA0031000 |
sh2
|
Collins R-390/URR
(license Motorola) 1952
|
0.5-32 MHz in 1MHz segments, all
bands are equipped, supply 115/230 V 50 - 400 Hz |
SNr 3640
|
W8 |
RA0032000 |
ra-lkk
|
Collins R-390/URR
1951 |
0.5-32 MHz in 1MHz segments, all
bands are equipped, supply 115/230 V 50 - 400 Hz |
SNr 3254
|
W0NKL |
RA0033000 |
ra-lkk
|
Collins R-390A/URR
(license Electronic Assistance Corp.) 1956
|
0.5-32 MHz in 1MHz segments, all
bands are equipped, supply 115/230 V 50 - 400 Hz, small
transport damage |
SNr 2777
|
ua3adr |
RA0034000 |
al-k2
|
Collins R-390A/URR
(license AMELCO) 1962 |
0.5-32 MHz in 1MHz segments, all
bands are equipped, supply 115/230 V 50 - 400 Hz,
special symmetric connector fitted, shutter for dial
still on
|
SNr 1214
|
goep |
RA0034100 |
ra-wk
|
| Collins 651S-1 1971 |
Short wave receiver 0.25 - 30 MHz,
Nixie tube display |
|
ji |
RA0035000 |
ra-lkk
|
| Collins KWM-1 1957 |
14, 21, 28-30 MHz in 0.2 MHz
segments, supply by special power supply |
original |
ji |
RA0036000 |
al-bu
|
| Collins KWM-2 1959 |
short wave transceiver
3-30 MHz in 0.2 MHz segments, supply by special power
supply |
Original |
GI3NUM |
RA0038000 |
ra-lkk
|
Collins 75S-3B with C mod's 1963
|
short wave receiver 3-30 MHz
receiver in 0.2 MHz segments |
|
GI3NUM |
RA0039000 |
al-ku
|
| Collins 312B-5 1962 |
S-line station
console/wattmeter/phone patch, second VFO |
|
GI3NUM |
RA0037000 |
al-wo
|
| Collins 312B-4 1959 |
S-line station
console/wattmeter/phone patch |
|
GI3NUM |
RA0040000 |
ra-lkk |
| Collins 32S-3B |
3-30 MHz transmitter in 0.2 MHz
segments, supply by special power supply |
original |
GI3NUM |
RA0041000 |
ra-wk |
| Collins 516F-2 1960 |
Power supply for KWM-2 or 32S-3 transmitters (old 312-B2
console in new case) |
original |
GI3NUM |
PC0010000 |
ra-lkk |
Collins 516F-2
1960 |
Power supply for KWM-2 or 32S-3 transmitters |
original |
GI3NUM |
PC0011000 |
ra-lkk |
| Collins accessory: GD6-C digital frequ.
display |
Displays accurate transmitting and
receiving frequency of S-line |
original |
GI3NUM |
RA0044000 |
ra-lkk |
| Collins accessory: Magnum SIX RF compressor |
RF compressor for S-line |
original |
GI3NUM |
RA0045000 |
ra-wk |
| Collins 30S-1 1959 |
3 - 30 MHz 1kW Linear Amplifier
115/230 V AC (tubes 4CX1000, 12AL5, 866A=DCG4/1000) |
original+ bound copy |
GI3NUM |
RA0046000 |
al-k2
|
| Collins CC-2 |
Carrying case for KWM2 or 30-L1 |
|
GI3NUM |
RA0047000 |
ra-lkk
|
| Collins CC-2 |
Carrying case for KWM2 or 30-L1 |
|
GI3NUM |
RA0048000 |
ra-lkk
|
| Collins CC-2 |
Carrying case for KWM2 or 30-L1 |
|
GI3NUM |
RA0049000 |
ra-lkk |
| Collins PP-1659/G |
Battery Charger 0-120 V 0-15 Amp,
license manufacturing |
|
W8 |
PC0013000 |
al-we
|
| Collins PP-2352 |
airborne 28 VDC input static power
converter for supply of 618T1 (3x117VAC 400Hz, 1x117VAC
400Hz) |
|
W8 |
PC0014000 |
ra-lkk |
| Collins 30L-1 |
3 - 30 MHz Linear 115/230 V AC
(tubes 4x811A) |
|
GI3NUM |
RA0052000 |
ra-lkk |
| Collins KWS-1 |
Transmitter still missing but the
manual is around... |
Original |
n2 |
RA0053000 |
sc |
| Collins SM-2 |
Station microphone |
|
GI3NUM |
AM0011000 |
al
|
| Collins MM-1 |
Handheld microphone |
|
GI3NUM |
AM0010000 |
al-case
|
| Collins 618 T 1 (French version
built by C.I.T., France) |
3 - 30 MHz@400W PEP in 1 kHz
steps, with 28VDC power supply PP 2352/URR adapted from
AN/TRC 75, control unit, manual copy (tubes 2x4CX250) |
Copy of army manuals |
SAR Marseille |
RA0055000 |
ra-lkk |
| |
|
|
|
|
|
| Conserton MD 2508U/89 1958 |
LW MW SW FM band table radio with U-tubes. Swedish
equivalent to Philips Philetta. |
|
bl |
RA0055500 |
ra-lkk |
| |
|
|
|
|
|
| Crown TR-702 1965 |
MW SW portable radio , 7 transistors, supply 9VDC. |
|
family |
RA0055600 |
al-ku |
| |
|
|
|
|
|
CTE CT-1600
1985
|
VHF 144 MHz handheld transceiver (three battery packs) |
|
fc1gyo |
RA0197020 |
al-k1 |
| CTE International Booster |
144 MHz 40W FM/80 Watt SSB amplifier |
|
fc1gyo |
RA0197000 |
al-k2
|
| |
|
|
|
|
|
| CX9AAB+ PA 19xx |
Short wave linear amplifier,
supply 230VAC, 3.5 to 30 MHz, further details unknown
|
|
david |
RA0197024 |
al-ku
|
| |
|
|
|
|
|
| Czeija_Nissl_306/1 "Hekaphon" 1950
|
Wire broadcast receiver ("School radio"), tube
complement UCH21 UBL21 UY1N, supply 220VAC or 220VDC
|
|
40x30x14.5 roli |
RA0015200 |
al-k1
|
| |
|
|
|
|
|
| DEBEG E555
1958 |
SW MW LW receiver for maritime use as
emergency/auxiliary equipment, single conversion with EF85
ECH42 EF43 EBC41 EM80 EL84 TE50 (80V 50mA stabiliser),
supply 220VAC or 12/24VDC, mass 15kg |
Ser.Nr. 336 |
zieg |
RA0058010 |
ra-to
|
| DEBEG Sailor 7281
1972 |
SW MW LW receiver for maritime use, upper frequency
limit = 4 Mhz |
|
HB9JNH |
RA0058000 |
ra-wk
|
| |
|
|
|
|
|
| DF9CR+ 23cm LDMOS Linear
2023 |
1296Mhz LDMOS amplifier, gain
13dB, 1W input to 30W output, supply 28VDC
|
|
1vhs |
RA0058800 |
al-fu
|
| |
|
|
|
|
|
| DK3EH+ 23cm Transverter
19xx |
Transverter from 144 to 1296Mhz
with 2C39 final for up to 100W output, supply 230VAC
|
|
3eh |
RA0058900 |
al-fu
|
| |
|
|
|
|
|
| DRAKE 2B 1966 |
with Q-Multiplier
& speaker |
|
F8RU |
RA0059000 |
ra-lkk |
| DRAKE R4C 1973 |
shortwave receiver, many options
including 500 Hz/250 Hz CW filters, with manual |
|
OE6WU+ |
RA0060000 |
ra-lkk |
| DRAKE T4XC 1973 |
shortwave transmitter, speech amp
and fan added, with manual, power
supply made by OE6WU |
|
OE6WU+ |
RA0061000
PC0074500 |
ra-lkk |
| DRAKE L4B 1966 |
shortwave linear amplifier, with
manual |
|
f8ru
|
RA0062000 |
ra-lkk |
| DRAKE MS4 1970 |
Console power Supply for DRAKE 4 line, with speaker and
plugs |
|
ri |
PC0014500 |
ra-lkk |
| DRAKE CC-1
1974 |
VHF converter 144 --> 28 MHz, look of 4-line, with
SC-2 built in |
Original |
eb |
RA0064000 |
ra-lkk |
| DRAKE C-4 with
Coax Relay and Power Strip 1974 |
Console for multiple station, multiple antenna and rotor
control; mechanical digital clock included |
|
ri |
RA0065000 |
ra-lkk |
| DRAKE TC-2
1972 |
VHF transverter 28 --> 144 MHz, power 100 W on 144
MHz (driver 7558, final 8643) |
Original |
eb |
RA0066000 |
ra-lkk |
| DRAKE TR-4310 1981 |
0.01 - 30 MHz, professional
version of TR7 with digital VFO |
Original incl. service manual |
dpt. 01 |
RA0067000 |
ra-lkk |
| Drake RR-1 1972 |
Shortwave receiver looking like
the brother of the TR-4310, but delivered as a Hagenuk
with German markings |
|
Ni |
RA0068000 |
ra-wk |
| DRAKE MN7 1972 |
3 - 30 MHz, Antenna
Tuner/Wattmeter |
|
dpt. 01 |
AR0011500 |
ra-wk |
| DRAKE W4 1970 |
3 - 30 MHz, Wattmeter |
|
dpt. 01 |
MA0033500 |
ra-lkk |
| DRAKE WV4 1970 |
30 - 200 MHz, Wattmeter |
|
dpt. 01 |
MA0033550 |
ra-lkk |
| DRAKE AK75 |
Doublet for shortwave |
|
dpt. 01 |
AR0011000 |
ra-lkk |
| DRAKE SP75 1977 |
RF speech processor |
|
dpt. 01 |
RA0072000 |
ra-lkk |
| DRAKE DL300
1971 |
Dummy load |
|
dpt. 01 |
AR0010500 |
ra-lkk |
| DRAKE PS7 1978 |
Power supply 14 V 25 A |
|
dpt. 01 |
PC0015000 |
ra-lkk |
| DRAKE PS7 1978 |
Power supply 14 V 25 A |
|
HB9QC |
PC0015001 |
ch-sh1
|
| DRAKE MN-2700 1978 |
1.5 kW antenna
tuner/wattmeter/dummy load, optional balun |
Original |
G4JBH |
AR0011600 |
ra-lkk |
| DRAKE MN-2000 1970 |
2kW Antenna Tuner/Wattmeter for
Amateur Bands 80-10 |
|
HB9 |
AR0011700 |
ra-lkk |
| DRAKE TR-M 1970 |
Crystal controlled SSB marine
transceiver for 11 preset channels |
Original |
USA |
RA0078000 |
ra-lkk |
| DRAKE TR-4C 1964 |
Amateur radio SSB
transceiver for the classic shortwave bands. Tubes 12AX7 (ECC83) 6EV7 (ECC-type) 6GX6 (EL-type)
3x12BA6 (HF93) 6BZ6 (EF-type) 12AX7A (ECC83) 6AQ5A (EL-type) 6HS6 (EL-type) 2x6EA8 (ECF82)
13DE7 (ECC-type) 6BA6 (EF93) 12BY7 (EL180) 3x6JB6 (EL-type beam deflection tube) |
copy |
EA3 |
RA0078200 |
ra-lkk |
| DRAKE TR-7 1964, AUX-7, NB-7,
VF-7 1980 |
1.5 - 30 MHz transceiver in 10
bands, CW-filter, fan unit, noise blanker, second VFO |
|
HB9QC+ |
RA0079000 |
sh1 |
| DRAKE MS7 1980 |
Loudspeaker for Drake 7 series |
|
UA3ADR |
AM0013000 |
ra-wk |
| DRAKE MS7 1980 |
Loudspeaker for Drake 7 series |
|
OE7WDH |
AM0014000 |
ra-lkk |
| DRAKE R7 1981 |
0.01 - 30 MHz general coverage
receiver in 10 bands, Filter 300/1800/2300, NB-7,
Manual, Service Manual, Cable set for transceive
operation with Drake TR7 |
Original |
DL1ZBO |
RA0082000 |
ra-wk
|
| DRAKE R8 1995 |
with all options and filters - ok
|
Original |
Jormanainen BC |
RA0083000 |
ra-lkk |
| DRAKE L7 1978 |
shortwave linear amplifier - ok |
Original |
VK3ST |
RA0084000 |
al-k2
|
| DRAKE SSR-1 1976 |
Shortwave general coverage
receiver, solid state, Barlow Wadley principle, 12V and
117/234 Volt supply, built-in telescopic antenna - ok
after repair of cold solder point at plug-in unit |
Copy |
eb |
RA0085000 |
ra-wk |
| DRAKE Extension set
series 7 |
extension set for plug-in unit
test and repair |
|
UA3ADR |
RA0086000 |
al-k2
|
| DRAKE TV-CB-LP |
Low Pass Filter against TVI |
|
neup |
AR0011800 |
ra-lkk
|
| DRAKE APS 24E & ESR 324E |
Satellite receiver 950 - 1750 MHz
and dish antenna positioner |
|
eb |
RA0088000 |
ra-lkk |
| |
|
|
|
|
|
| Ducretet tba |
110VAC/DC powered miniature broadcast receiver using
U-tubes |
|
dany |
RA0197040 |
ra-lkk |
| |
|
|
|
|
|
DX-Patrol QO-100
Downconverter 2021
|
Downconverter from 10.5 GHz to selectable HF/VHF/UHF
amateur frequencies (28 or 144 or 432MHz), including an
LNB21 modified dish feed/premixer
|
web |
Obidos PT |
RA0088500 |
al-bu |
| |
|
|
|
|
|
Eddystone EB35
Mk2 1970
|
The "statesman receiver", mains (optionally also
battery) operated transistorised receiver for LW, MW, SW
and FM band. Receiver did not work because of internally
corroded OC171 Germanium HF-transistors in the 3-stage
IF-section. Because I could not get OC171 transistors I
took Russian Germanium HF-transistors as replacement. I
soldered them in without retuning (!!). The receiver now
works very well with these high quality metal encapsulated
fully shielded devices. |
Copy of manual |
wgl50 |
RA0089000 |
ra-lkk |
| |
|
|
|
|
|
EKCO W.S.88 1947
|
38.01 - 42 .15 MHz 4 channel 250mW FM transceiver from
WW2 |
|
tannen |
RA0296000 |
al-wo
|
| |
|
|
|
|
|
| ELTZ (Radione) Wien |
please see for Radione listings |
|
|
n.a. |
|
| |
|
|
|
|
|
ELIN ECS
19xx
|
136 - 174 MHz synthesized FM transceiver for mobile
applications, power output unknown, runs on 14VDC,
complete with attached microphone KYODO KD557 |
|
will |
RA0296500 |
al-fu
|
ELIN EM850-160
19xx
|
136 - 174 MHz FM transceiver for mobile applications,
power output 25W, runs on 14VDC |
|
ampfl |
RA0296551 |
al-we
|
ELIN EM850-160
19xx
|
136 - 174 MHz FM transceiver for mobile applications,
power output 25W, runs on 14VDC |
|
ampfl |
RA0296552 |
al-we
|
ELIN EM850-160
19xx
|
136 - 174 MHz FM transceiver for mobile applications,
power output 25W, runs on 14VDC |
|
ampfl |
RA0296553 |
al-we
|
ELIN EM850-160
19xx
|
136 - 174 MHz FM transceiver for mobile applications,
power output 25W, runs on 14VDC |
|
ampfl |
RA0296554 |
al-we
|
ELIN EM850-160
19xx
|
136 - 174 MHz FM transceiver for mobile applications,
power output 25W, runs on 14VDC |
|
ampfl |
RA0296555 |
al-we
|
| ELIN Bermuda 1982 |
Broadcast table top radio |
|
do |
RA0013700 |
al-k1
|
| |
|
|
|
|
|
| EMY Radio Paris Receiver_"E" |
Emyradio Paris made this prototype shortwave receiver in
the late thirties. Before it could be finished the
receiver was confiscated by the parts supplier. The
antenna trimmer, the power transformer and the internal
metal sheetsware are not mounted. Also the receiver
indicates 4 ranges on the front panel but only two ranges
were actually installed. The receiver works with external
power. It's a one of a kind shortwave receiver using
precision clockwork mechanics including a pull-out 1-to-8
fine reduction for delicate tuning of the main and the
bandspread variable capacitors. |
|
Sor |
RA0091000 |
ra-lkk |
| |
|
|
|
|
|
| Eumig 322U
1949 |
Broadcast receiver for DC or AC power supply, tubes UCH4
UCH4 UBL1 UY1N |
|
nickel |
RA0091210 |
al-ku
|
| Eumig 324GW
1949 |
Broadcast receiver for DC or AC power supply, tubes
UCH42 UAF42 UAF42 UL41 UM4 UY1N |
|
nickel |
RA0091215 |
al-ku
|
| Eumig 324GW
1949 |
Broadcast receiver for DC or AC power supply, tubes
UCH42 UAF42 UAF42 UL41 UM4 UY1N |
|
nickel |
RA0091216 |
al-ku
|
| Eumig 430WH
1940 |
Broadcast receiver for AC power supply, tubes ECH11
EBF11 ECL11 AZ11 |
|
nickel |
RA0091216 |
al-ku
|
| Eumig 439B
1938 |
Broadcast receiver for battery supply (2VDC heaters and
130VDC anode), tubes KK2 KF3 KBC1 KL4 |
|
nickel |
RA0091230 |
al-ku
|
| Eumig 530W
1931 |
Broadcast receiver |
|
cdö |
RA0091240 |
cdö
|
Eumig Eumigette tbc. 1951
|
Broadcast receiver |
|
horn-wolfg |
RA0091245 |
al-ku |
| Eumig Eumigette_W
1955 |
Broadcast receiver |
|
kaheiho |
RA0091250 |
ra-lkk
|
| |
|
|
|
|
|
| Euro CB Pacific
40 |
Classic 40 channel CB-transceiver, all modes |
|
fc1gyo |
RA0091500 |
al
|
| Eurotronics OCR288 1975 |
Portable radio clock, alarm clock and cassette recorder, MW and FM, supply 1.5V and 6V battery pack |
|
Gr.-S. |
RA0091550 |
ra-lkk
|
| |
|
|
|
|
|
Everight B541
1941 |
Long wave, medium wave and short wave single conversion
broadcast receiver, supply 120VDC or 120VAC, using
tubes 6E8MG (ECH35, ref. ECH11), 6M7 (IF pentode),
6Q7MG (predecessor of EBC41), 25L6 (power tetrode) and
25Z6 (double power diode), filament circuit 300mA, all
filaments in series. Produced by Bussenius in occupied
Paris, France
|
|
St. Claude vide grenier 2018
|
RA0091600 |
ra-lkk |
| |
|
|
|
|
|
Ford Kassettenradio
19x |
Car broadcast receiver with slot for music cassette
|
|
ampfl
|
RA0091700 |
al-we |
| |
|
|
|
|
|
| GAGA UV-50 Amplifier |
144/432 MHz FM/SSB Amplifier, 50W
when running on 13.8 VDC |
Original |
ri |
RA0093000 |
al-k1
|
| |
|
|
|
|
|
| Galaxy GT-550
1971 |
Short wave transceiver for the classical amateur bands,
tube complement 12BZ6 (HF-type), 6HG8 (ECF86), 6KE8
(ECF-type), 6EW6 (EF-type), 12BA6 (HF93), 6GX6 (EF-type),
12AT7 (ECC81), 6EJ7 (EF184), 6GK6 (EL84), 2x6LB6 (EL beam
power type designed originally for TV-deflection, Pv=30w
and 315mA max. steady state cathode current). Two tubes in
parallel provide more than 200W PEP output at 550W PEP
input. Two separate power supplies from either 14VDC oder
117/234VAC. Calibrator and VOX installed. |
Original |
laa |
RA0093500 |
ra-ku
|
| |
|
|
|
|
|
| Geloso G209 |
Amateur Radio shortwave receiver for the classical bands
(2x12AT7, ECH81, 6BE6, 6BZ6, 2xEF89, 12AX7, ECL86/6GW8,
OA2, semiconductor diodes for HF circuits and power
supply), dismounted, for parts only
|
original schematic |
oe5mbl |
RA0094000 |
al-ku
|
| Geloso G209 |
Amateur Radio shortwave receiver for the classical bands
(2x12AT7, ECH81, 6BE6, 6BZ6, 2xEF89, 12AX7, ECL86/6GW8,
OA2, semiconductor diodes for HF circuits and power
supply)
|
original schematic |
BB |
RA0094005 |
ra-wk
|
| Geloso G209
1958 |
Amateur Radio shortwave receiver for the classical bands
(2x12AT7, ECH81, 6BE6, 6BZ6, 2xEF89, 12AX7, ECL86/6GW8,
OA2, semiconductor diodes for HF circuits and power
supply) |
original schematic |
oe1ky |
RA0094010 |
al-k2
|
| Geloso G222TR
1961 |
Amateur Radio shortwave AM/CW transmitter for the
classical bands, 220VAC supply, tubes 6CL6, 5763,
12AU7/ECC82, 12AX7/ECC83, 807, 807, 6146, 0A2 |
original schematic |
oe1ky |
RA0094020 |
al-k2 |
| Geloso G222TR 1961 |
Amateur Radio shortwave AM/CW transmitter for the
classical bands, 220VAC supply, tubes 6CL6, 5763,
12AU7/ECC82, 12AX7/ECC83, 807, 807, 6146, 0A2 |
original schematic |
BB |
RA0094021 |
ra-wk |
| Geloso G222TR
1961 |
Amateur Radio shortwave AM/CW transmitter for the
classical bands, 220VAC supply, tubes 6CL6, 5763,
12AU7/ECC82, 12AX7/ECC83, 807, 807, 6146, 0A2, microphone
connector modified for 4-pol input, matching microphone |
nn |
OE5PRL |
RA0094022 |
ra-kü |
| Geloso G222TR
1961 |
Amateur Radio shortwave AM/CW transmitter for the
classical bands, 220VAC supply, tubes 6CL6, 5763,
12AU7/ECC82, 12AX7/ECC83, 807, 807, 6146, 0A2, microphone
connector modified for 4-pol input, matching microphone |
nn |
OE3DKW |
RA0094023 |
ra-kü |
| Geloso G4/103 |
VFO for 144MHz with 2x EL-type Pa=2W (6CL6), ECC81
(12AT7), QE03/10 (5763)
|
original schematic |
igw |
RA0094023 |
ra-lkk
|
| Geloso G4/104 |
VFO for 3.5, 7, 14, 21, 27, 28 MHz with 6CL6 and 5763 |
original schematic |
oe5di |
RA0094024 |
ba
|
| Geloso G4/104 |
VFO for 3.5, 7, 14, 21, 27, 28 MHz with 6CL6 and 5763,
with multipliers added by previous owner |
original schematic |
oe3dkw |
RA0094025 |
ra-kü
|
| Geloso G4/104 |
VFO for 3.5, 7, 14, 21, 27, 28 MHz with 6CL6 and 5763 |
new in original box, no tubes |
gemein |
RA0094026 |
ra-kü
|
| Geloso G4/214
1962 |
Amateur Radio shortwave receiver for the classical bands
(6DC6 EK90 ECC81 EK90 ECC82 EF93 EF93 EAA91 EK90 ECC83
ECC83 EL84 OA2, semiconductor diodes for HF circuits and
power supply) |
|
oe5htm |
RA0094500 |
al-wo |
| Geloso G4/214
1962 |
Amateur Radio shortwave receiver for the classical bands
(6DC6 EK90 ECC81 EK90 ECC82 EF93 EF93 EAA91 EK90 ECC83
ECC83 EL84 OA2, semiconductor diodes for HF circuits and
power supply) |
original schematic |
oe5mbl |
RA0095000 |
ra-lkk |
| Geloso G4/216
1966 |
Amateur Radio shortwave receiver for the classical bands
(6BZ6 12AT7 12AT7 6BE6 ECH81 EF89 EF89 12AX7 6BE6 ECL86
OA2, semiconductor diodes for HF circuits and power
supply) |
original schematic |
ase |
RA0096000 |
ra-wk
|
| Geloso G4/216
1966 |
Amateur Radio shortwave receiver for the classical bands
(6BZ6 12AT7 12AT7 6BE6 ECH81 EF89 EF89 12AX7 6BE6 ECL86
OA2, semiconductor diodes for HF circuits and power
supply). Dial protective glass missing.
|
original bill and technical bulletins |
oe5uvl |
RA0096002 |
al-wo
|
| Geloso G4/220 1968 |
Semiprofessional medium and short
wave receiver 0.53-30.5 MHz, supply 230VAC, front
speaker, tube complement EF89 ECC82 EECH81 EF89 EF89
EABC80 ECL86 OD3 |
none |
berndorf |
RA0096005 |
al-fu
|
| Geloso G4/225
1965 |
Amateur Radio shortwave all mode phase-method
transmitter for the classical bands (ECC83 2xECC81 12BY7
EM87 7360 7360 7360 6CW4 6CB6 6AH6 6146 6146), separate
power supply Geloso G4/226 |
|
oe5htm |
RA0096200
PC0020000 |
al-wo |
| Geloso G16/400
1968 |
Wire broadcast transmission receiver |
|
dany |
RA0096500 |
al-k2
|
| |
|
|
|
|
|
| Gertsch FM-3 1961 |
Frequency Meter (receiver and overtone generator) 20 -
1000 MHz, using 6BH6/E90F, 6AK6, 6BH6/E90F, 6BH6/E90F,
6BJ6/E99F, 6BH6/E90F, 12AT7/ECC81, 6X5GT/EZ90,
0D3/150C5-30 |
partly original |
be |
RA0097000 |
ra-lkk |
| |
|
|
|
|
|
| Graetz Melodia
1314 F "Stereo Großsuper" 1965 |
Classic high-end broadcast receiver, stereo with two
large built-in speakers, last series before exclusive
transistor versions; tube complement ECH81 EAF801 ECC801
and ELL80, also EMM803. FM tuner already fully
transistorised. Terrific sound. One of the last tube radio
top of the line developments. |
|
ri |
RA0098000 |
ra-lkk
|
| |
|
|
|
|
|
| Grundig EliteBoy
1965 |
Portable radio radio receiver |
|
puc |
RA0098400 |
ra-lkk |
| Grundig RF410
1971-75 |
Transistorised desk top broadcast receiver for long
wave, medium wave and VHF-FM, supply 220VAC |
|
Horn |
RA0098650 |
al-kü |
| Grundig RF625
1965 |
Desk top broadcast receiver |
|
Gosdorf |
RA0098700 |
ra-lkk |
| Grundig RF640
1979 |
Desk top broadcast receiver for long, medium, short wave
and VHF-FM reception, fully transistorised, supply 220VAC.
VHF converter does not always work (cold solder joint). 11
transistors: BF414 BF936 BC558 BF494 BC548 BC559 BC548
BC548 BC368 BC369 BC338 and 2 IC's: TBA120S (FM) et TCA440
(AM) |
|
sonja |
RA0098730 |
ra-kü |
| Grundig RTV350a
1979 |
Desk top broadcast stereo receiver/amplifier for long, medium, short wave
and VHF-FM reception, fully transistorised (AF106 NPN VHF, BF194 VHF NPN, BF195 VHF NPN, BF185 IF NPN, BC147 Audio NPN, BC148 audio NPN,
AD161/AD162 PNP/NPN audio power, BA121 var cap diode, 1N60 Ge Det, AA113 Ge diode, AA118 univ.diode, AA119 Ge diode,
BYY59 200V 1.2A power diode, E60C3 Selenium high resistance diode, B30C250 bridge rectifier), supply 220VAC, mass 7.8kg |
|
oevg |
RA0098744 |
ra-kü |
| Grundig 2147Pha
1961 |
Desk top stereo phono combination, tubes ECC85 ECH81
EF89 EABC80 EM84 EL84 |
|
nickel |
RA0098800 |
al-ku |
| Grundig Satellit
3400 Professional 1977 |
Top of the line portable radio radio receiver, including
short wave bands |
|
family |
RA0098500 |
ra-lkk |
| Grundig Yachtboy
N210 1970 |
Portable radio radio receiver, including one short wave
ban, supply 6x1.5VDC dry batteries or mains 220VAC |
|
puc |
RA0098600 |
ra-lkk |
| Grundig CC200
19xx |
Stereo tower with cassette and disc player |
|
nickel |
RA0098900 |
al-ku |
Grundig KWV 1000
1970
|
Shortwave preconverter for long/medium wave automobile
radios, transistorised, 12V, negative earth |
|
eb |
RA0099000 |
ra-lkk |
| |
|
|
|
|
|
Hagenuk EE 421 1973
|
Shortwave receiver equivalent to
Drake RR-1 |
|
Ni |
RA0068000 |
ra-wk
|
Hagenuk Transmitter 1960
|
Shortwave maritime transmitter,
supply 220VAC |
|
BB |
RA0069000 |
ra-ga
|
| |
|
|
|
|
|
Hallicrafters CB-7 1965
|
CB transceiver, four channels,
using 12AU6, 12BE6, 12BA6, 6BL8, 6BN8, 6GW8, 8CX8 |
|
TI |
RA0101000 |
al
|
| Hallicrafters CRX-1 |
30 MHz - 50 MHz tunable, FM only
(works according to spec's, original "Hallicrafters"
tubes still installed) |
|
HS |
RA0102000 |
al
|
| Hallicrafters CRX-105 1967 |
Solid state FM receiver, 150 MHz -
174 MHz in original shipping package |
original |
leb |
RA0103000 |
al-k2
|
| Hallicrafters EC-1B "Echophone"
1948 |
Broadcast receiver, for display
only |
none |
tief |
RA0103500 |
al-k1
|
| Hallicrafters HA-1 1960 |
Automatic Keyer with built-in
power supply |
|
DL |
TT0014000 |
al
|
| Hallicrafters HA-2, inside view 1962 |
28 to 144 MHz transverter with
6360 (QQE03/12) and 5894 (QQE06/40) in driver and final,
2 tubes (Nuvistor 6CW4 RF Amp and 6AN4 triode mixer)
missing, no channel crystals, output indicator with
magic eye 6FG6 (=EM84) |
|
jens eb |
RA0104000 |
al-k2
|
| Hallicrafters HCM-270 1965? |
CB Transceiver from 1965, 40
channels, AM. |
|
le |
RA0104500 |
al
|
| Hallicrafters HT-4 1938 |
WW II transmitter BC-610E (part of SCR-399) |
Original
French SCR-399 manual |
phil |
RA0105000 |
ra-lkk |
| Hallicrafters HT-5 1938 |
WW II speech amplifier (part of SCR-399) French markings |
Original
French SCR-399 manual |
phil |
AM0023000 |
ra-lkk |
| Hallicrafters HT-5 1938 |
WW II speech amplifier (part of SCR-399) |
Original
French SCR-399 manual |
phil |
AM0024000 |
ra-lkk |
| Hallicrafters HT-7 1939 |
Frequency standard, slightly
modified for 230 V input |
Copy |
ri |
RA0108000 |
ra-lkk |
| Hallicrafters HT-9 1939 |
Crystal controlled AM/CW
transmitter for three bands, final 1x814, AF amplifier
4x6L6 |
Copy |
HB9G |
RA0109000 |
ra-lkk |
| Hallicrafters HT-14 (BC-669B
version) 1946 |
1.5 to 4.5 MHz transceiver for
vehicle or fixed operation. Black finish. Final uses two
807'2. Driver, VFO and modulator all on 6L6's. Back
panel, all connectors and power unit missing. |
|
th hof |
RA0110000 |
ra-lkk |
| Funktechnische
Werkstaetten Mannheim (FTW) SqE543,
a professionally modified Hallicrafters HT-14 built 1950 |
1.5 to 4.5 MHz transceiver for
ship operation. Sand beige finish. Shows as maker
"Funktechnische Werkstaetten Mannheim", type SqE 543,
has a modified receiver dial, German inscriptions,
German handbook, original ship radio license with call
"D ER K", a remotely controlled notch filter for the
receiving antenna with separate output and cabling
probably used for duplex traffic, a handset and six
transmitting channels equipped with crystals.
Transmitter crystal controlled with 6L6 oscillator
driving two 807's to a very moderate 45 Watt output.
Modulator with 6L6's via transformer. Receiver has
continuous coverage with VFO. Dynamotors missing, power
required is 24 VDC filament, 250 VDC 200mA receiver, 500
VDC 900mA modulator and transmitter. |
orig, with schematic, license, trouble shooting. No
description for notch filter in antenna line.
|
Rene |
RA0111000 |
ra-lkk |
| Hallicrafters HT-24
"Littlefone" 1952-57 |
27 MHz transceiver for vehicle or
battery portable operation. 29 tubes, with original
headset.
|
|
leb dpt.94 |
RA0111500 |
ra-lkk |
| Hallicrafters HT-32A 1957 |
5 bands amateur transmitter,
built-in power supply |
Original |
NL |
RA0112000 |
ra-lkk |
| Hallicrafters HT-33A 1957 |
3 - 30 MHz in 5 bands, power
supply built in, modified for use with GU43B |
Original |
HB9QC+ |
RA0113000 |
ra-lkk |
| Hallicrafters HT-33B 1957 |
3 - 30 MHz in 5 bands, power
supply built in, modified by the previous owner |
|
HB9ANO+ |
RA0113500 |
ra-lkk |
| Hallicrafters HT-37 1959 |
5 band amateur phase method ssb
transmitter with power supply built in |
|
DL |
RA0114000 |
ra-lkk |
| Hallicrafters HT-44 1962 |
5 band amateur filter method ssb
transmitter (needs external power supply PS-120) |
|
Nick |
RA0115000 |
ra-lkk |
| Hallicrafters HT-44 1962 |
5 band amateur filter method ssb
transmitter (needs external power supply PS-120) |
|
rhw |
RA0115020 |
ra-m10 |
| Hallicrafters HT-44 1962 |
5 band amateur filter method ssb
transmitter, not complete |
|
Nick |
RA0115010 |
ra-lkk |
| Hallicrafters JB-70 1938 |
WW II junction box (part of SCR-399) |
|
phil |
RA0116000 |
ra-lkk |
| Hallicrafters PS-150-120 1962 |
power supply for HT-44 or SR-150 |
|
OK |
PC0023000 |
ra-lkk |
| Hallicrafters SX-11 SkyRider 1936 |
Medium and shortwave receiver 500
kHz - 34 MHz with BFO and possibility to mute receiver
during transmission |
|
HA1UK (Laa) |
RA0118000 |
ra-lkk |
| Hallicrafters S-19R SkyBuddy 1939 |
Medium and shortwave receiver 500
kHz - 40 MHz with BFO and possibility to mute receiver
during transmission |
Schematic |
Mions (69) |
RA0119000 |
ra-lkk |
| Hallicrafters S-20 SkyChampion 1938 |
General coverage short wave
receiver, single conversion, supply 115 60 Hz |
|
eb |
RA0120000 |
ra-lkk |
| Hallicrafters SX-28 (AN/GRR-2)
1940 |
also known as AN/GRR-2,
communication receiver 500 kHz - 43 MHz, AM/CW, mass 34kg, supply 117VAC,
tube complement 2x6AB7 (EF-type), 2x6SK7 (EF-type), 2x6SA7 (EF-type), 6L7 (EK-type),
6B8 (EBF-type), 6H6 (EAA-type), 6J5 (EC-type), 6SC7 (ECC-type), 2x6V6 (EL-type like EL90), 5Z4 (double diode rectifier) |
Copy |
OE5NG |
RA0121000 |
ra-lkk |
| Hallicrafters SX-28 (AN/GRR-2)
1940 |
also known as AN/GRR-2,
communication receiver 500 kHz - 43 MHz, AM/CW, mass 34kg, supply 117VAC,
tube complement 2x6AB7 (EF-type), 2x6SK7 (EF-type), 2x6SA7 (EF-type), 6L7 (EK-type),
6B8 (EBF-type), 6H6 (EAA-type), 6J5 (EC-type), 6SC7 (ECC-type), 2x6V6 (EL-type like EL90), 5Z4 (double diode rectifier) |
Copy |
rhw |
RA0121001 |
ra-kü |
| Hallicrafters S-36A 1942 |
30 - 143 MHz receiver, single
conversion, supply 115 60 Hz |
|
HB9JI+ |
RA0122000 |
ra-lkk |
| Hallicrafters S-38A 1946 |
0.5 - 32 MHz receiver, single
conversion, supply 115 VAC or VDC (150mA filament series
supply, works perfectly, 4 tubes as plus one rectifier
tube, design without the necessity for a power
transformer - attention - unit must be supplied using a
separation transformer because one leg of the mains
supply is connected to the chassis) |
|
Tand |
RA0123000 |
ra-lkk |
| Hallicrafters S-40B 1947 |
0.5-32 MHz receiver, single
conversion, supply 115 60 Hz, slightly modified but
working fine |
|
ri |
RA0124000 |
ra-lkk |
| Hallicrafters S-40B 1947 |
0.5-32 MHz receiver, single
conversion, supply 115 60 Hz with built-in 230V
step-down transformer. Small mechanical damage to main
frequency dial drive, needs new shaft 6mm, AF works but
second IF stage believed to have a bad component that
causes motorboating |
|
ji |
RA0125000 |
ra-lkk |
| Hallicrafters S-41G 1945 |
0.5 - 30 MHz single conversion (broadcast) receiver with
BFO, tubes 12SA7 (pentagrid converter), 12SK7 (pentode),
2x12SQ7 (double diode & triode), 35L6G (beam power
tube for 1.5W output), 35Z5G (power diode) |
copy |
alain |
RA0126000 |
ra-lkk |
| Hallicrafters SR-42 1964 |
144 MHz transceiver with VFO, supply 6VDC/12VDC/117VAC,
output 12W, tubes 13CW4 UHF triode nuvistor, 6U8A=ECF82,
6U8A=ECF82, 12BA6=HF93, 12BA6=HF93, 12AL5=HAA91, 7059=12V
filament version of ECF82, 12AT7=ECC81, 12AQ5=12V filament
version of EL90, 12BY7A=EL180, 7551=beam power 175MHz
amplifier tube |
|
eb |
RA0126200 |
al-k2
|
| Hallicrafters SX-42 1946 |
Single conversion receiver covering 0.540-1.62, 1.62-5,
5-15, 15-30, 27-55, 55-110MHz |
|
pouc |
RA0126500 |
ra-lkk |
| Hallicrafters S-72L 1949 |
Amateur receiver using 8 tubes (1T4 or DF91, 1U4 or
DF904, 1R5 or DK91, 1U4 or DF904, 1U4 or DF904, 1U5 or
DAF92, 1U5 or DAF92, 3V4 or DL94), coverage: 0.180-0.400,
0.550-1.6, 1.6-4.4, 4.5-11.5MHz, LW-Version of the S-72,
AC 117V or DC battery supply, built-in telescopic aerial.
Main dial string ruptured. |
|
ri |
RA0127000 |
ra-lkk |
| Hallicrafters SX-73 (R-274/FRR)
1952 |
Communication receiver 540 kHz -
54 MHz, AM/CW/SSB with tubes 6AG5 - EF96, 6BA6 - EF93,
6BE6 - EK90, 6C4 - EC90, 6BE6 - EK90, 5 times 6BA6 -
EF93, 6AL5 - EAA91, 6AT6 - EBC90, 6AL5 - EAA91, 6BA6 -
EF93, 6Y6 - VT168, 6AG5 - EF96, 6BA6 - EF93, VR150 -
OD3, 5U4 |
|
astyx |
RA0128000 |
ra-lkk |
| Hallicrafters S-76 1951 |
Amateur general coverage receiver using 8 tubes (6CB6 -
7732, 6AU6 - EF94, 6C4 - EC90, 6BA6 -EF93, 6BE6 - EK90,
6BA6 - EF93, 6AL5 - EAA91, 6SC7 - CV1969 double AF triode,
6K6 - output penthode, VR150, 5Y3 power rectifier),
coverage: 0.53 - 34MHz, IF's 1650kHz and 50kHz. The first
double superhet made by this company, production 1951 thru
1954. |
|
9epc |
RA0128500 |
al-rkk
|
| Hallicrafters S-85 1954 |
Communication receiver - 0.54 - 34
MHz single conversion receiver |
|
ri |
RA0129000 |
ra-lkk |
| Hallicrafters SX-99 1954 |
Communication receiver 500 kHz -
43 MHz, AM/CW/SSB |
|
Munich |
RA0130000 |
ra-lkk |
| Hallicrafters SX-101 1958 |
Amateur Radio receiver 160 - 10 m
amateur bands only, to be restored |
Original |
eb |
RA0131000 |
ra-lkk |
| Hallicrafters S-108 1959 |
General Radio receiver 0.5 - 34,
impeccable, 8 tubes (6SG7 6SA7 6SG7 6SK7 6H6 6SC7 6K6GT
5Y3GT), power supply 117VAC
|
|
f6jti |
RA0131500 |
ra-lkk |
| Hallicrafters SX-117 1965 |
Amateur short wave receiver, tube complement
2x6DC6 (EF-type), 3x6EA8 (ECF82), 12AT7 (ECC81), 2x6BA6 (EF93), 2x6BE6 (EK90),
6BN8 (EAAC-type), 6GW8 (ECL86), built-in power supply 117VAC |
orig |
rhw |
RA0131550 |
ra-m10 |
| Hallicrafters SX-122 1962 |
3 - 30 MHz in 5 bands, 117V 60Hz
(tubes 2x6DC6, 6AU6=EF94, 6C4=EC90, 6BA6=EF93,
6BL8=ECF80, 6BN8, 6BE6=EK90, OA2, 6GW8=ECL86, 5Y3GT) |
|
F5SAD |
RA0132000 |
ra-lkk |
| Hallicrafters SR-150 1961 |
3 - 30 MHz in 5 bands (needs
external power supply PS-120) |
|
OK |
RA0133000 |
ra-lkk |
| Hallicrafters SR-500 "Tornado" |
3.5/7/14 MHz transceiver
originally using the famous 8236 finals (I can't find
them any more) so unit is slightly modified for use with
two 8032's (13V filament version of 6146=QE05/40),
original power supply destroyed by the world's most
famous shipping company. A homemade power supply exists:
PS-500 Hallicrafters copy |
Original |
N1 |
RA0134000
PC0098500
|
ra-wk
al-k2
|
| Hallicrafters TW500 green |
0.18 - 18.5 MHz in 5 bands, mains
and battery operation |
|
ri |
RA0135000 |
ra-lkk |
| Hallicrafters TW1000
black |
0.18 - 18.5 MHz in 5 bands, mains
and battery operation |
|
DL |
RA0136000 |
ra-lkk
|
| |
|
|
|
|
|
| Hammarlund HQ-170A - 1958 |
Ham band only receiver 160 - 10m
(6m & 2m with add'l converters, scale provided) |
|
M3BVL |
RA0137000 |
ra-lkk |
| Hammarlund HQ-200A 1968 |
General coverage triple coversion
shortwave receiver 160 - 10m, tube complement 6BZ6
(EF-type), 2x6BE6 (EF-type), 6C4 (EC90), 2x6BA6 (EF93),
12AX7 (ECC83), 6AQ5 (EL90) plus two diodes (1N34A for AM
detection and 1N541 for noise limiting) |
|
PRG |
RA0137100 |
ra-ki |
| Hammarlund SP-200 -
1941 |
Prewar shortwave receiver, version BC-779B (100-400kHz,
2.5-20 MHz), AF-stage removed to make space for internal
power supply, front panel destroyed by bad paint job which
needs to be redone; not tested |
|
DL3BAY |
RA0138000 |
ra-lkk |
Hammarlund SP-600 - JX17 1950
|
Shortwave receiver, version JX17, double superhet above
7 MHz, 0.5 - 54 MHz, quartz-filters |
|
LA2RL |
RA0139000 |
al-k2
|
| |
|
|
|
|
|
| HB9APB home made |
144 MHz 10 W power amplifier, based on STE |
Original |
HB9APB |
RA0140000 |
ra-wk
|
| HB9APB home made STE |
144 MHz FM and AM transceiver based on STE modules |
Original |
HB9APB |
RA0141000 |
ra-wk |
| HB9xxx amateur make |
Short wave linear amplifier in
housing of FL DX 2000
amplifier but with much better performance and output |
|
bl |
RA0142500 |
ra-lkk |
| |
|
|
|
|
|
| HEA Trixi - 1961 |
Austrian broadcast receiver MW SW
FM-band, mains and battery operation, transistorised, |
|
eby |
RA0143000 |
al-k2
|
| HEA Trixi 2000 - 1969 |
Austrian broadcast receiver MW SW
FM-band, mains and battery operation, transistorised,
very good condition |
|
eby |
RA0144000 |
al
|
| HEA Trixi 2000 - 1969 |
Austrian broadcast receiver MW SW
FM-band, mains and battery operation, transistorised,
very good condition |
|
do
|
RA0144010 |
al-we
|
HEA Viennana 1964
|
9 tube broadcast receiver for car use, power supply 6VDC
or 12VDC; no power converter box. |
|
family |
RA0145000 |
al |
HEA Ultra Baby
1954
|
broadcast receiver for use in bus, medium wave only.
Vibrator box missing.With microphone input and
preamplifier |
|
family |
RA0146000 |
al
|
| |
|
|
|
|
|
Heathkit DX-60 1960
|
Amateur Radio AM/CW xmitter,
supply 110 VAC, corroded chassis, gives a few watts RF,
modulator not yet tested. Tubes 6CL6 6CL6 6146 12AX7
6DE7. May be operated with VFO Heathkit HG-10. |
|
Spain |
RA0147000 |
ra-lkk
|
Heathkit DX-60 1960
|
Amateur Radio AM/CW xmitter,
supply 110 or 220VAC, tested, modulation ok with crystal
microphon. Tubes 6CL6 6CL6 6146 12AX7 6DE7. May
be operated with VFO Heathkit HG-10. |
|
F5? |
RA0148000 |
ra-wk
|
Heathkit DX-100U 1964
|
Amateur Radio AM/CW xmitter for
160/80/40/20/15/10m amateur bands, supply 100 or 250VAC
user selectable - British version using ECC83/6CH6/KT88
in the modulator and 5763/2x6146 in the driver/final
stages. Modified for 10 W output on 160m according to
British regulations. Old version having an internal
switch to change from VFO to crystal operation for only
one single crystal. Mass 42kg. Tubes 6AU6 2x12BY7 5763
2x6146 6AQ5 12AX7 2x5R4GY 2x1625 OA2 5V4 2x6AL5
|
Original |
g3naq |
RA0149000 |
ra-lkk |
Heathkit GC-1A
"Mohican" 1962
|
General coverage medium and
shortwave receiver |
|
wgl50 |
RA0150000 |
ra-m11 |
Heathkit GR-88 1969
|
Battery operated VHF receiver 153 - 174 MHz |
|
ri/camp |
RA0167000 |
al
|
Heathkit GW-11A 1962
|
CB transceiver with original
microphone and built-in power supply (117VAC), output
4W, transmitter crystal controlled, receiver tuneable or
also crystal controlled tube complement ECF82 (6U8) EC90
(6C4) E99F (6BJ6) EAAA-type (6BJ7) PCL80 (6AN8) EL90
(6AQ5A) ECF-type (6AU8) QE03/10 (5763)
|
|
gemein |
RA0151037 |
ra-kü |
Heathkit GW-11A 1962
|
CB transceiver with original
microphone and built-in vibrator driven power converter
from 12VDC, output 4W, transmitter crystal controlled,
receiver tuneable or also crystal controlled tube
complement ECF82 (6U8) EC90 (6C4) E99F (6BJ6) EAAA-type
(6BJ7) PCL80 (6AN8) EL90 (6AQ5A) ECF-type (6AU8) QE03/10
(5763)
|
|
gemein |
RA0151038 |
ra-kü |
Heathkit GW-11A 1962
|
CB transceiver with original
microphone and built-in vibrator driven power converter
from 12VDC, output 4W, transmitter crystal controlled,
receiver tuneable or also crystal controlled tube
complement ECF82 (6U8) EC90 (6C4) E99F (6BJ6) EAAA-type
(6BJ7) PCL80 (6AN8) EL90 (6AQ5A) ECF-type (6AU8) QE03/10
(5763)
|
|
gemein |
RA0151039 |
ra-kü |
Heathkit GW-14A 1971
|
CB transceiver with original
microphone and desktop power supply (12VDC)
|
|
ri |
RA0151040 |
al
|
Heathkit HD-8999 1985
|
Sends morse code from a
computer-like keyboard |
Original |
ase |
RA0164000 |
al-k2
|
Heathkit HG-10 1962
|
VFO for 80 to 2m, perfect with
cable (tube 6CH8 plus oltage stabiliser OB2, 140 VDC
supply) |
|
nick |
RA0164500 |
al
|
Heathkit HG-10 1962
|
VFO for 80 to 2m, under case
restoration (tube 6CH8 OB2, 140 VDC supply) |
|
eb |
RA0165000 |
al
|
| Heathkit HR-1680 1980 |
Amateur Radio receiver 80 - 10m
|
|
F4EHO |
RA0184000 |
ra-wk
|
Heathkit HW-7 1972
|
Amateur Radio small power CW
transceiver 40-20-15m, 2 - 3 Watts on 14 VDC |
|
FC1GAO |
RA0184000 |
ra-lkk |
Heathkit HW-8 1976
|
Amateur Radio small power CW
transceiver 80-15m, 2 Watts on 14 VDC, with carrying
case and other accessories like home made tuner, Morse
key, 80m Dipole. Transceiver has additional broadband
linear amplifier to give 10W output. The added circuit
does not work and will eventually be removed. |
Original |
HB9BEA |
RA0163000 |
al-wo
|
Heathkit HW-8 1976
|
Amateur Radio small power CW
transceiver 80-15m, 2 Watts on 14 VDs, few amendments |
Original |
Nick |
RA0163100 |
ra-lkk |
Heathkit HW-9 1984
|
Amateur Radio small power CW
transceiver 80-10m including all WARC-bands, full
break-in, 4 Watts on 14 VDC |
|
HB9HVQ |
RA0163600 |
ra-lkk
|
| Heathkit HW-12 1963 |
Amateur Radio monoband SSB
transceiver for 80m, with power supply HP-23E, microphone and
mobile mounting bracket, tubes 6AU6 6AU6 6AU6 6AU6 6AU6
6BE6 6EA8 6EA8 6EA8 12AT7 12BY7A 6EB8 6GE5 6GE5. |
none |
vka |
RA0163700 |
al-k2 |
| Heathkit HW-17 1968 |
Amateur Radio monoband AM (FM
optional) transceiver for 2m, with 220VAC power supply
built-in, output 10W. Tubes 7059 (ECF-type medium mu
triode and sharp cutoff pentode), 12GN7 (EF-type, sharp
cutoff pentode), 8156 (EL-type beam power pentode
amplifier) |
none |
horn |
RA0163800 |
al-fu |
Heathkit HW-30 1960
|
Amateur Radio AM/CW 2m transceiver
"The
Twoer" with original microphone, tubes 6BA8
6BA8 6BS8 12AX7 6AQ5
|
none
|
OE6WU+ |
RA0152000 |
ra-lkk |
Heathkit HW-32A
1966
|
Amateur Radio monoband SSB transceiver for 20m (14.2 to
14.35 MHz), modified to include CW, 100W pep with nice
home made power supply containing a matching speaker, uses
two 6DE6 or 6GE5 deflection tubes as finals, tubes 6EA8
6EA8 6EA8 6AU6 6AU6 6AU6 6AU6 6AU6 6BE6 12BY7 12AT7 6EB8
6GE5 6GE5 |
none |
fribourg |
RA0160000 |
al-k2
|
| Heathkit HW-100 1968 |
Amateur Radio transceiver 80-10m
100W PEP with homemade power supply; tubes:
4xECF82(6EA8) 2xEF-type(6HS6) 4xEF94(6AU6)
EAAC-type(6BN8) ECL86(6GW8) EF-type(6CB6) ECC82(12AU7)
6CL6 2xECC81(12AT7) 2xQE05/40(6146) StV150/30(0A2)
transistors: MPF105 2N3393 |
original |
6cy |
RA0161200 |
ra-m11
|
| Heathkit HW-101 1970 |
Amateur Radio transceiver 80-10m
100W PEP with homemade power supply; tubes:
4xECF82(6EA8) 2xEF-type(6HS6) 4xEF94(6AU6)
EAAC-type(6BN8) ECL86(6GW8) EF-type(6CB6) ECC82(12AU7)
6CL6 2xECC81(12AT7) 2xQE05/40(6146) StV150/30(0A2)
transistors: MPF105 2N3393 |
copied schematic of HW-101 |
igw |
RA0161300 |
ra-m11
|
| Heathkit HW-101 1970 |
Amateur Radio transceiver 80-10m
100W PEP with nice homemade power supply; fully repaired
and operational. Original failures traced to bad wiring
of home made power supply that had a non
Heathkit-compatible earth wiring; tubes: 4xECF82(6EA8)
2xEF-type(6HS6) 4xEF94(6AU6) EAAC-type(6BN8) ECL86(6GW8)
EF-type(6CB6) ECC82(12AU7) 6CL6 2xECC81(12AT7)
2xQE05/40(6146) StV150/30(0A2) transistors: MPF105
2N3393 |
copied schematic of HW-101 |
DG2SI |
RA0161400 |
al
|
| Heathkit HW-101 1970 |
Amateur Radio transceiver 80-10m
100W PEP with power supply HP-23E and original speaker,
in perfect condition, tubes: 4xECF82(6EA8)
2xEF-type(6HS6) 4xEF94(6AU6) EAAC-type(6BN8) ECL86(6GW8)
EF-type(6CB6) ECC82(12AU7) 6CL6 2xECC81(12AT7)
2xQE05/40(6146) StV150/30(0A2) transistors: MPF105
2N3393 |
|
F9NS+ |
RA0161500 |
al
|
| Heathkit HW-101 1970 |
Amateur Radio transceiver 80-10m
100W PEP, in perfect condition but without any
accessories. Trouble with "too high" 6BA6 (EF94) tube
that did not fit under the hood. A "shorter" EF94 had to
be found... tubes: 4xECF82(6EA8) 2xEF-type(6HS6)
4xEF94(6AU6) EAAC-type(6BN8) ECL86(6GW8) EF-type(6CB6)
ECC82(12AU7) 6CL6 2xECC81(12AT7) 2xQE05/40(6146)
StV150/30(0A2) transistors: MPF105 2N3393 |
|
andritz |
RA0161600 |
ra-lkk |
| Heathkit HX-10 "Marauder" 1962 |
Amateur radio short wave transmitter, matches the RX-1,
CW/SSB, final 2x6146, supply 230VAC built-in |
Original |
ufb
|
RA0159600 |
ra-wk
|
| Heathkit HX-20 |
Amateur SSB/CW (mobile) transmitter with homemade power
supply; Power input: 90 watts PEP, SSB and CW. 3.5 to 4;
7.0 to 7.5; 14.0 to 14.5; 21.0 to 21.5; 28.0 to 29.5 MHz.
Power requirements: 6.3 or 12.6 V 4 A; -120 volts 20 mA;
300 volts 100 mA, 600 V 130 mA |
Original |
tannen |
RA0166000 |
al
|
| Heathkit RX-1
"Mohawk" 1958 |
Amateur SSB//AM/CW receiver 160 - 10m, 14 tubes, matches
TX-1 |
Original |
ufb
|
RA0166100 |
ra-wk
|
| Heathkit RX-1
"Mohawk" 1958 |
Amateur SSB//AM/CW receiver 160 - 10m, 14 tubes, matches
TX-1 |
Original |
priel
|
RA0166101 |
ra-to
|
| Heathkit TX-1
"Apache" 1958 |
Amateur AM/CW transmitter 80 - 10m, 15 tubes (6AU6 6CL6
5763 6146 6146 6AQ5 12AX7 12AU7 6AL5=EAA91 12BY7
6CA7=EL34, 6CA7=EL34, 5R4GY 5R4GY 5V4 0A2 0B2 0B2),
matches RX-1, mass=50kg
|
Original |
igp
|
RA0166120 |
al-ku
|
| Heathkit TX-1
"Apache" 1958 |
Amateur AM/CW transmitter 80 - 10m, 15 tubes (6AU6 6CL6
5763 6146 6146 6AQ5 12AX7 12AU7 6AL5=EAA91 12BY7
6CA7=EL34, 6CA7=EL34, 5R4GY 5R4GY 5V4 0A2 0B2 0B2),
matches RX-1, mass=50kg
|
Original |
priel
|
RA0166121 |
ra-to
|
| Heathkit SB-10 |
Amateur Radio SSB exciter 80-10m
3W PEP, SSB companion unit for Heathkit TX-1 APACHE or
DX100; external supply from radio (350VDC and 6.3VAC) |
|
leb |
RA0152000 |
ra-lkk |
| Heathkit SB-10 |
Amateur Radio SSB exciter 80-10m
3W PEP, SSB companion unit for Heathkit TX-1 APACHE or
DX100; external supply from radio (350VDC and 6.3VAC) |
|
igp
|
RA0152010 |
al-k1
|
| Heathkit SB-10 |
Amateur Radio SSB exciter 80-10m
3W PEP, SSB companion unit for Heathkit TX-1 APACHE or
DX100; external supply from radio (350VDC and 6.3VAC) |
|
priel
|
RA0152011 |
ra-to
|
| Heathkit SB-101 |
Amateur Radio transceiver 80-10m
100W PEP with power supply HP23E
but power link cable missing, transmitter out of order,
AGC does not work, damage on power connector, main dial
drive slips |
|
eb |
RA0153000 |
al
|
| Heathkit SB-101 |
Amateur Radio transceiver 80-10m
100W PEP, with power cable |
|
vka |
RA0153500 |
al |
| Heathkit SB-102 |
Amateur Radio transceiver 80-10m
100W PEP with power supply HP-23E, condition unknown |
orig |
crp szg |
RA0154000 |
ra-m11 |
| Heathkit SB-200 |
Amateur Radio Linear Amplifier using 2xT172 tubes, 230
VAC supply built in |
orig |
ri |
RA0155000 |
ra-lkk |
| Heathkit SB-200 |
Amateur Radio Linear Amplifier using 2xT172 tubes, 230
VAC supply built in |
orig |
bhb |
RA0155010 |
al-k2
|
| Heathkit SB-220 |
Amateur Radio Linear Amplifier using 2x3-500Z tubes, 230
VAC supply built in |
orig |
eps |
RA0156000 |
al-ku |
| Heathkit SB-300 |
Amateur Radio Receiver |
orig |
bhb |
RA0156200 |
al-k2
|
| Heathkit SB-400 |
Amateur Radio Transmitter |
orig |
bhb |
RA0156300 |
al-k2
|
| Heathkit SB-610 |
Panorama adapter for the SB-series |
none |
bl |
RA0157010 |
ra-lkk |
| Heathkit SB-614 |
Panorama adapter for the SB-series |
none |
crp |
RA0157014 |
ra-wk
|
| Heathkit SB-614
|
Panorama adapter for the SB-series |
none |
ri |
RA0157015 |
ra-lkk |
| Heathkit SB-620 |
Panorama adapter for the SB-series |
orig |
bhb |
RA0157020 |
al-k2
|
| Heathkit SB-1000 |
Amateur Radio Linear Amplifier using a single 3-500Z
tube, 230 VAC supply built in, 160m - 10m |
still with RSO |
RSO |
RA0159000 |
ra-lkk |
| Heathkit SW-717 |
Amateur Radio Short Wave Receiver |
|
bl |
RA0159500 |
ra-lkk |
| |
|
|
|
|
|
| Hornyphon W302
1931 |
Broadcast receiver |
|
cdö |
RA0168060 |
cdö |
| Hornyphon Belcanto
W 1932 |
Broadcast receiver |
|
cdö |
RA0168070 |
cdö |
| Hornyphon Marquis
1932 |
Broadcast receiver |
|
cdö |
RA0168080 |
cdö |
| Hornyphon Prinz
39W W134 1933 |
Broadcast receiver |
|
cdö |
RA0168090 |
cdö |
| Hornyphon W348U
1933 |
Broadcast receiver |
|
cdö |
RA0168100 |
cdö |
| Hornyphon Rex W664A/3 |
Broadcast receiver with 3 loudspeakers, LW, MW, SW,
VHF-FM |
|
w-family |
RA0168000 |
sh2 |
| HornyphonRex
47 1947 |
Broadcast receiver with 3 loudspeakers, LW, MW, SW,
tubes ECH11 EBF11 EL11 AZ11 EFM11 |
|
w-family |
RA0168005 |
al-ku |
| Hornyphon W251U/3
1951 |
Broadcast receiver for LW, MW, SW, tubes UCH42 UAF42
UBC41 UL41 UY41
|
|
kaheiho |
RA0168010 |
ra-lkk |
| Hornyphon Prinzess
W452A 1952 |
Broadcast receiver for LW, MW, SW, tubes ECH42 EAF42
EBC41 EL41 EM34 AZ41
|
|
kaheiho |
RA0168020 |
ra-lkk |
| Hornyphon Prinz
W551 1951 |
Broadcast receiver for LW, MW, SW, tubes UCH42 UAF42
UBC41 UL41 UM4 UY41
|
|
kaheiho |
RA0168030 |
ra-lkk |
| Hornyphon Prinz
W551 1951 |
Broadcast receiver for LW, MW, SW, tubes UCH42 UAF42
UBC41 UL41 UM4 UY41, no rear panel
|
|
kaheiho |
RA0168040 |
ra-lkk |
Hornyphon UKW
W367A 1957
|
Broadcast receiver for LW MW VHF-FM, supply 220VA, tubes
ECC85 ECH81 EF89 EABC80 EM81 EL84 EZ80 |
|
rau |
RA0168050 |
al-k1
|
Hornyphon Weltmeister
43 WT1728U /10 Ch= S4 1959
|
BW TV receiver for VHF, supply 220VA,
20 tubes: PCC88 PCF80 EF80 EF80 EF80 EF80 EF80 PCL82 PCL84
ECC81 PCF80 PCF80 ECH81 PCL82 PL81 PY81 DY87 PY82 PY82
AW43-80 |
|
kaheiho |
RA0168200 |
ra-lkk
|
| Hornyphon WT2134A
1957 |
BW TV receiver, made and sold in the period when Austria
had no TV-transmitters yet. The receiver is designed for
long distance reception (100km) and has exceptionally good
sensitivity. Supply 220VAC, 20 tubes: PCC88 PCF80
EF80 EF80 EF80 EF80 PL83 PCF80 PCF80 PCL82 PCF80 ECH81
PCL82 PCF80 PL36 PY81 DY87 UY82 UY82 AW53-80 |
|
rau |
RA0168210 |
al-k1 |
| |
|
|
|
|
|
| HyGain GT-550
1971 |
Short wave transceiver for the classical amateur bands.
Technical features almost identical to Galaxy GT-550.
AC-power supply only. |
Original |
Nick |
RA0168500 |
ra-wk
|
HyGain V 1979
|
120 channel CB transceiver AM FM LSB USB |
|
puc |
RA0168600 |
al-k2 |
| |
|
|
|
|
|
ICOM IC-T7H
1995
|
2 Watt FM transceiver 144/430, 144-148 430-450 TX
118-174 400-470 RX, supply 5 - 16 VDC |
Original |
ri |
RA0169000 |
al-bu
|
ICOM R-70 1982
|
Short wave receiver 0.1 MHz - 30 Mhz SSB AM FM WF,
CW-filter, 230VAC supply |
2 copies of manual
|
oe5uvl |
RA0169500 |
al-k1
|
ICOM R-7100
DC 1991
|
Measurement receiver 25 MHz - 2 Ghz SSB AM FM WFM with
12V supply |
None |
ri |
RA0170000 |
al
|
ICOM IC-202E
1976
|
144 MHz portable transceiver 1 Watt |
|
fc1gyo |
RA0187000 |
al-k2 |
ICOM IC-215
1976
|
144 MHz portable FM transceiver 0.5/3 Watt |
|
6cy |
RA0187100 |
ra-m11 |
ICOM IC-740
1983
|
Amateur Radio transceiver 1.8 - 30 MHz power 100W,
supply 13.8VDC |
Original |
f3ri |
RA0171000 |
al-680fu
|
| ICOM IC-746
2005 |
Amateur Radio transceiver 1.8 - 144 MHz power 100W,
supply 13.8VDC |
Original |
3gas |
RA0171500 |
al-fu |
| ICOM IC-746
2005 |
Amateur Radio transceiver 1.8 - 144 MHz power 100W,
supply 13.8VDC |
Ser. Nr. 003387 |
2rpl |
RA0171501 |
al-fu |
| ICOM IC-765
1989 |
Amateur Radio transceiver 1.8 - 30 MHz power 100W |
Original |
ct3ee |
RA0172000 |
ch-sh1 |
| ICOM IC-765
1989 |
Amateur Radio transceiver 1.8 - 30 MHz power 100W |
Original |
vjo |
RA0172001 |
os |
| ICOM IC-781
1988 |
Amateur Radio system transceiver 1.8 - 30 MHz power
150W, supply 230VAC, all filters installed including CW |
Original |
f1tjj |
RA0172500 |
al-fu |
| ICOM IC-7300
2022 |
Amateur Radio transceiver 1.8 - 74 MHz with SDR
receiver, power 100W, supply 14VDC |
Original |
1vhs |
RA0172600 |
süv |
| |
|
|
|
|
|
| Ingelen Columbus_52W 1951 |
Broadcast receiver LW MW SW, tubes ECH42 EAF42 EAF42
EL41 EM34 AZ41, supply 110/220VAC
|
none |
kaheiho
|
RA0173200 |
ra-lkk
|
| Ingelen Cosmos W 1953 |
Broadcast receiver LW MW SW, tubes ECH42 EAF42 EBC41
EL41 EM34, supply 110/220VAC
|
none |
kaheiho
|
RA0173210 |
ra-lkk
|
| Ingelen HB1300
2010 |
Satellite receiver with remote control |
none |
krems
|
RA0173220 |
al-k1
|
| |
|
|
|
|
|
| Intel Baden Baden 1966 |
Broadcast receiver LW MW SW VHF-FM, semiconductors
SFT358 SFT357 SFT316 SFT316 SFT316 SFT337 SFT353 SFT325
SFT325, supply 220VAC
|
none |
kaheiho
|
RA0173250 |
ra-lkk
|
| |
|
|
|
|
|
| ITT R80 |
Synthesised tuner FM band 88 to
108 MHz coverage, 220 V supply |
none |
dany |
RA0173500 |
al-k2
|
| ITT Viola automatic |
Desk top broadcast receiver supply
230VAC |
none |
gosdorf |
RA0173600 |
ra-lkk
|
| |
|
|
|
|
|
| Jennen 9R-59 |
9 tube short wave radio receiver 0,55
to 30 MHz coverage, 220 V supply, Q-Mulitplier and BFO |
none |
Har |
RA0173000 |
ra-lkk |
| |
|
|
|
|
|
JRC NRD-525G
1986
|
LW MW SW receiver, range 90 kHz - 34 MHz, double
superhet with up-conversion to 70Mhz first IF, CW AM SSB
RTTY NFM equipped, no VHF/UHF converter installed |
copy + original |
wlg50 |
RA0174000 |
al-bu
|
| |
|
|
|
|
|
JVC KS-FX830R
2003
|
Car stereo receiver with cassette player and 12-fold
CD-ROM stacker, 12VDC operation, 4x40W audio power
|
|
kran |
RA0175050 |
al-bu
|
| JVC KD-SX841R |
Car stereo receiver with CD-ROM reader, 12VDC operation,
audio power 4x40W |
|
mm |
RA0175000 |
280GE |
| JVC KD-S8R |
Car stereo receiver with CD-ROM reader, 12VDC operation,
audio power 4x40W |
original |
mm |
RA0176000 |
mb100 |
| JVC KD-S8R |
Car stereo receiver with CD-ROM reader, 12VDC operation,
audio power 4x40W |
original |
mm |
RA0177000 |
89KK |
JVC T-X200L 1985
|
Stereo Tuner 88 - 108 MHz FM |
|
puces |
RA0178000 |
pr |
| |
|
|
|
|
|
| Kamensk Uralsk Radio
Works Neywa 403
1979 |
USSR broadcast receiver LW only,
supply 9VDC battery
|
|
family |
RA0180400 |
al-ku
|
| |
|
|
|
|
|
| Kapsch S3S 1938 |
Austrian broadcast receiver LW MW
SW, tubes EK2 EF9 EBL1 AZ11, supply from 110 to 240 VAC
|
|
nickel |
RA0180400 |
al-ku
|
| Kapsch Viktoria51
Allstrom 1950 |
Austrian broadcast receiver LW MW
SW, tubes UCH21 UCH21 UBL21 UY1N plus an NTC-Resistor,
supply from 110 to 240 VAC or VDC
|
|
kaheiho |
RA0180500 |
ra-lkk
|
Kapsch Dominant de Luxe II 1968
|
Austrian broadcast receiver LW MW
SW FM-band, tubes : ECH81 EAF801 ECL86 EM87,
semi-conductors AF106 AF125. One of the last tube-equipped receivers.
|
|
s59 |
RA0180600 |
ra-lkk
|
Kapsch Troubadour TR 7012 1972
|
Austrian table-top broadcast
receiver, 8 transistors, supply 220VAC
|
|
oevg |
RA0180700 |
ra-kü
|
Kapsch Troubadour TR 7020 1972
|
Austrian table-top broadcast
receiver, 8 transistors, supply 220VAC
|
|
pwm |
RA0180700 |
ra-to2
|
Kapsch TRM-540
1978
|
Autoradio with cassette tape player, MW and FM, 4
speaker outputs, tape section does not work. |
|
mb100 |
RA0181000 |
al
|
| |
|
|
|
|
|
| Kathrein MFK11 |
TV and radio measurement receiver |
|
kk |
RA0180500 |
ra-lkk |
| Kathrein MFK53/N |
TV and radio measurement receiver |
|
wgl50 |
RA0179000 |
ra-lkk |
| |
|
|
|
|
|
| Kauno Radijo Gamykla
KRG Euromatic 405 |
Portable TV receiver for mains and
battery operation |
|
oe6wu |
RA0179500 |
ra-lkk |
| |
|
|
|
|
|
| Kenwood TH27E 1991 |
Handheld 2m 1W transceiver with DTMF/CTSSS,
supply internal 7.2V rechargeable battery or 7.2 - 16VDC external |
orig with box |
6cy |
RA0182000 |
ra-m11
|
| Kenwood TM215 |
Handheld 2m transceiver with DTMF
|
|
F2YT |
RA0182500 |
al-bu
|
| Kenwood TL-922 1985 |
Shortwave linear amplifier, tubes 2x3-500ZG, supply 230VAC |
|
oe3asa |
RA0182600 |
al-ku
|
| Kenwood TS50 |
Mobile transceiver 30 kHz - 30
MHz, transmit on hambands only, 12V supply 100 W |
Original |
F2YT |
RA0183000 |
al-300 |
| |
|
|
|
|
|
| Knight R-100A |
Single conversion general coverage
kit receiver with calibrated amateur band spread, tubes
are 6BZ6 RF, 6BH6 Mixer/oscillator, 6AZ8 IF1, 6AZ8 IF2,
12AX7 Q-multiplier, 6BC7 AVC and detector noise limiter,
6AW8 AF power and BFO, OB2 stabiliser, 6X4 power rect. |
|
faido |
RA0189000 |
al-ku
|
| Knight R-100 |
Single conversion general coverage
kit receiver with calibrated amateur band spread, tubes
are 6BZ6 RF, 6BH6 Mixer/oscillator, 6AZ8 IF1, 6AZ8 IF2,
12AX7 Q-multiplier, 6BC7 AVC and detector noise limiter,
6AW8 AF power and BFO, OB2 stabiliser, 6X4 power rect. |
|
faido |
RA0190000 |
ra-wk |
| Knight T-60 |
Amateur transmitter, crystal
controlled, 60W |
|
faido |
RA0190500 |
ra-lkk |
| |
|
|
|
|
|
| |
|
|
|
|
|
| DB6NT Kühne 1296
linear |
23 cm linear amplifer 1W to 10W |
|
cuy |
RA0056000 |
al-k1
|
| DB6NT Kühne 1296/28 |
23 cm transverter 1 W output |
|
cuy |
RA0057000 |
al-k1
|
| KW Electronics KW-2000A |
Short wave 100W amateur radio
transceiver 160 - 10m with original solid state power
supply, works at half power because of unmatched 6146W
tubes at lifetime limit and only after repair of
mechanical filter 455kHz (filter damping material
decomposed over the years; replaced by cotton material -
filter insertion loss now about 6 dB when measured with
50 Ohm circuitry), replacement of T/R-relay tube,
realignment of IF, replacement of driver EL821; receiver
sensitivity only 100microVolts because of missing
adjustment core in one band filter. |
Original |
eb |
RA0191000 |
ra-wk |
| KW Electronics KW Viceroy 1961 |
Short wave 100W amateur radio SSB
transmitter 80 - 10m without power supply |
n.n. |
oe3dkw |
RA0191010 |
al-fu |
| |
|
|
|
|
|
| Lafayette Dyna Com 23 1975 |
27 MHz handheld battery operated
transceiver
|
SerNr 1216 |
wza |
RA0191800 |
al-k1
|
| Lafayette Dyna Com 23 1975 |
27 MHz handheld battery operated
transceiver
|
SerNr 1217 |
wza |
RA0191801 |
al-k1
|
| Lafayette HA-260 |
144 MHz VHF mobile power amplifier
with 65 Watts output from 1-5W drive, supply 14VDC,
tube=Amperex DX296/8637 twin tetrode, two converter
transistors
|
none |
Mus |
RA0191900 |
al-k1
|
| Lafayette HA-460 |
50-52 MHz 10W AM transceiver using
single 2E26 final tube modulated by two EL84; VFO or
crystal operation. |
Schematic |
Nick |
RA0192000 |
ra-lkk |
| |
|
|
|
|
|
| LOEWE. Studio Art 1 1985 |
Design TV receiver, received 1985
design prize, first TV receiver with stereo amplifier
and speakers
|
|
kaheiho
|
RA0192500 |
ra-p1 |
| LOEWE. Apollo
Plastik 761W 1956 |
High end broadcast receiver with
three built-in speakers, all bands including wire
broadcast
|
|
kuk
|
RA0192540 |
hh-phil |
| LOEWE. Truxa Stereo
741W 1959 |
High end broadcast receiver with
stereo amplifier and built-in speakers
|
|
kaheiho
|
RA0192550 |
ra-lkk |
| LOWE. HF-225 1989 |
Transistorised radio receiver for
amateur purposes, coverage 30kHz-30MHz, supply 12VDC
|
|
gkr |
RA0192570 |
ra-bu |
| |
|
|
|
|
|
| London Electric
Appliances (Wayfarer)
1936 |
Portable broadcast receiver for
medium and longwave, audion type, tubes S22 (tetrode),
PM1 (triode), PM1 Y220 (pentode), supply by battery 2VDC
and 90VDC |
|
dorr |
RA0192750 |
al-fu |
| |
|
|
|
|
|
| Lorenz (front view) A
good friend took care of it... |
SW only "RV12P2000" tubes (needs
110 or 220VAC) |
|
family |
RA0193000 |
adr |
| Lorenz (view in original box) |
SW only "RL12P35" tubes (220VAC
power supply SGLE 0.2/12 using Selenium) |
|
family |
RA0194000 |
ba |
| Lorenz (view in original box) |
SW only "RL12P35" tubes (220VAC
power supply SGLE 0.2/12 using LG12 tube rectification) |
|
eb |
RA0195000 |
ba |
| Lorenz Lo6k39 1939 |
Professional short wave receiver,
4 tuned RF-amplifiers followed by regenerative detector,
8 tubes RV12P2000 |
|
gkw |
RA0195020 |
ra-kü |
| Lorenz EO 4139
"Netzlore", 1943 |
Professional single conversion
short wave receiver covering 1.5 - 24MHz, tubes EF13
ECH11 EF12 EF13 EF12 EF12 EB11 EL11 EZ12 STV150/20,
supply 220VAC |
|
gkw |
RA0195040 |
ra-kü |
| Lorenz 20.W.S.d 1942 |
20W transmitter 42 to 48MHz using
4 tubes RL12T15 |
|
wza |
RA0195100 |
al-k1 |
| Lorenz 200/108 1935 |
200W transmitter 182kHz to 1.2MHz,
tubes 2xRL12T15, 3xRS237, 1xRE134, supply 12VDC and
1000VDC |
|
wza |
RA0195200 |
al-k1 |
| Lorenz München
LW 1934 |
Broadcast receiver |
|
cdö |
RA0195300 |
cdö |
| |
|
|
|
|
|
| Mediator M230 |
Small broadcast receiver, made by
Mediator in La Chaux de Fond (Switzerland) from 1948 to
1950, equipped with ECH21, ECH21, EBL21 and the
venerable AZ1 |
|
huel |
RA0196000 |
ra-lkk |
| |
|
|
|
|
|
| MessTec ER30 |
Battery driven general coverage
receiver 9 kHz to 3 GHz, control board does not work |
|
ecarn |
RA0197000 |
ra-lkk |
| |
|
|
|
|
|
| MicrowaveModules 70cm
transverter |
MWM transverter, 3 Watt out on 70cm |
|
cuy |
RA0198000 |
al-k1 |
| |
|
|
|
|
|
| MICS (Ets. MICHEL, Auxerre, France) HA64 receiver |
Amateur receiver 80 - 10m, and 4m. |
|
leb |
RA0198500 |
al-k2
|
| MICS (Ets. MICHEL, Auxerre, France) M100 transmitter |
Amateur AM/CW transmitter 80 - 10m. Presently no power
supply. |
|
leb |
RA0199000 |
al-k2
|
| Military UK (different makers) R1155 1940 |
Military long, medium and short wave receiver, covers
75kHz to 18.5MHz in five ranges, supply 220VAC, not
functional (oscillator missing), tubes 2xVR99A(ECH35)
3xVR100(EF type) VR99(ECH type) 2xVR101(EBC type) VR102
(unusual ECC type, one grid on anode cap) Vi103(ECM type) |
|
tief |
RA0199500 |
al-k1
|
| |
|
|
|
|
|
| Minerva 499 SH
with Hell interface |
Austrian shortwave communications receiver, with
matching Hell interface,
wartime design, EF13 ECH11 EBF11 EBF11 EL11 for receiver,
EZ12 for rectifier and EL11 ECH11 for Hellschreiber
interface. Built-in speaker, covers 72 kHz to 27 MHz
except 410 to 510 kHz, single superhet, modified in
several stages for tubes of more recent design. |
|
cz |
RA0200000 |
al-wo |
| Minerva VE
301 W Dyn 1935 |
Broadcast receiver
|
|
cdö |
RA0200010 |
cdö |
| Minerva DKE 38
B 1935 |
Broadcast receiver "Deutscher Kleinempfänger"
|
|
cdö |
RA0200020 |
cdö |
| Minerva Minerdyn
1936 |
Broadcast receiver "Zwergsuper Minerdyn"
|
|
cdö |
RA0200030 |
cdö |
| Minerva 338W
1938 |
>Empty case of broadcast receiver (tubes EF5 EK2 EF5
EF5 EM1 EB4 EF6 EL5 EZ4)
|
|
nickel |
RA0200040 |
al-ku |
| Minerva 506W/21
1949 |
Broadcast receiver LW MW SW, supply 220VAC, tubes: ECH21
EAF21 EAF21 EBL21 EM34 AZ21
|
|
rau |
RA0200050 |
ra-lkk |
| Minerva 700U
1947 |
Broadcast receiver LW MW SW, AC and DC supply, tubes:
3xUCH4 UBL1 UM4 UY1N
|
|
nickel |
RA0200060 |
al-ku |
| Minerva Minola
1965 |
Broadcast receiver Consul, LW MW SW VHF-FM, supply
220VAC, tubes: ECC85 ECH81 EF89 EABC80 EM84 EL84 EZ80
|
|
kaheiho |
RA0200120 |
ra-lkk |
| Minerva Minerphon1969 |
Broadcast desk top stereo receiver for LW MW SW VHF-FM,
15 transistors (BF222 (repl. BF314) BF185 (repl. BF255)
BF195 BF194 BF238 BF237 BC149 (repl. BC239) BC149 (repl.
BC239) BC181 BC181 AC187 AC188 AC187 AC188 AD162), AF
output 2x4W, supply 230VAC
|
|
gosdorf |
RA0200130 |
ra-lkk |
| Minerva Consul 638R 1958 |
BW TV receiver Consul, supply 220VAC, tubes: PC88
PC86 PCC189 PCF86 EF183 EF80 EF184 PCL84 ECH84 PCF80 PCL85
PCL86 PL500 PY88 DY87 23SP4
|
|
kaheiho |
RA0200140 |
ra-lkk |
| Minerva Gloriette1958 |
BW TV receiver Gloriette, supply 220VAC, tubes:
PCC88 PCF80 EF85 EF80 EM84 or PM84 PCL84 PCL82
ECH81 PL36 PY81 DY87 AW53-80
|
|
rau |
RA0200150 |
al-k1 |
| Minerva Gloriette
1958 |
BW TV receiver Gloriette, as above
|
|
rau |
RA0200101 |
al-k1 |
| Minerva TH-1
1957 |
Transistorised medium wave broadcast receiver
|
|
do |
RA0200102 |
al-we |
| Minerva Perfect 642A
1965 |
Portable transistorised long, medium and FM broadcast receiver, supply 8x1.5V dry batteries or 12VDC,
transistors AF106, AF125, 3xAF126, 2xAC126, AC127, AC128
|
|
Gr.-S. |
RA0200103 |
ra-lkk |
| Mini COM TS
605B |
Channelised 27 MHz CB transceiver, 220VAC supply
built-in |
|
fc1gyo |
RA0187500 |
al
|
| |
|
|
|
|
|
| Miniphase Roma SB7M |
SSB phase method exciter/transmitter (12AX7 12AX7 12AU7
12AT7 7360 7360 6BQ5 6146 6146 OB2 and 4 OA85
transistors), external power and external VFO required |
original |
f8ru |
RA0188000 |
ra-lkk |
| |
|
|
|
|
|
| Minix MR-73B
1975 |
General coverage shortwave receiver made (or resold) by
Richter & Co, Hannover |
original |
wuerm |
RA0188500 |
al-bu
|
| Minix MSK-10B
1975 |
Teletype AFSK converter made (or resold) by Richter
& Co, Hannover |
original |
wzaa |
RA0188500 |
al-k1
|
| |
|
|
|
|
|
| Modry Bod Ideal RadioManon S468 1937 |
Broadcast receiver |
|
cdö
|
RA0188550 |
cdö
|
| |
|
|
|
|
|
| Minsk Radio Works Okean 209 1976 |
Portable short, medium, long wave receiver, 20
transistors, 2W AF output, supply 6x1.5 dry cell or 9VDC
battery or 127/220VAC |
original |
nika
|
RA0188600 |
ra-m1
|
| |
|
|
|
|
|
| National NC-125
with Speaker |
Shortwave communications receiver, 220V version, with
matching speaker,
original price published in 1954 ARRL handbook: 200 USD |
|
oll |
RA0201000 |
ra-lkk |
| National NCL-2000 1968 |
Shortwave amateur power amplifier using 2 tetrodes 8122
driven in the grid at low power |
|
OE2CRP |
RA0202000 |
ra-lkk |
| National NCX-5
1964 |
Shortwave amateur transceiver 80-10m, double/triple
conversion receiver, mechanical digital readout, tubes
6BZ6 (EF-type), 4xHK90 (12BE6), 3xHF93 (12BA6), ECC83
(12AX7), EL90 (6AQ5), ECF-type (6KE8), EL84 (6GK6), ECC81
(12AT7), 2xECC82 (12AU7), ECF-type (6GH8), EF93 (6BA6),
StV150/30 (0A2), finals are 2x6JB6 (anode dissipation 17.5W), supply 110/220VAC or
12VDC, using two different external power supplies |
gkw |
RA0202200 |
ra-lkk
|
| |
|
|
|
|
|
| Neckermann Weltblick 1954 |
TV receiver for VHF bands I and III, 3 IF amplifier,
tube complement PCC84 (cascode tuner) PCF82 ECH81 EF80
EF80 PCL81 ECH81 PCL81 PCL81 ECL80 ECC82 PL81 PY83 EY86
AW43-20 |
|
kaheiho |
RA0186500 |
ra-lkk
|
| |
|
|
|
|
|
| Nissan DENSHI SX-200 |
Scanning receiver VHF 26 - 57,995 MHz (Low); 5kHz VHF 58
- 88 MHz; 12,5 kHz VHF 108 - 180 MHz (High); 5 kHz UHF 380
- 514 MHz; 12,5 kHz, AM/FM |
|
FC1GYO |
RA0186000 |
al-k2
|
| |

The company name "NORA" is the reverse
spelling of company founder Aron, a name found "too
Jewish...". Renamed Heliowatt after forced
takeover.
|
|
|
|
|
| NORA K42N (front view, rear view) |
LW, MW, SW, steel tubes DCH11 DF11
DAF11 DL11 UY11(needs 1.4VDC or 2VDC and 90VDC or
110/220VAC) |
|
family |
RA0203000 |
ba |
| NORA VE301W 1937 |
Broadcast receiver |
|
cdö |
RA0203010 |
cdö |
| |
|
|
|
|
|
| Nordmende A25A "Rigoletto" 1967 |
Broadcast receiver, tubes ECC85 ECH81 EAF801 ECL86 EM84 |
|
velden |
RA0203100 |
ra-kü
|
| |
|
|
|
|
|
| OE3DKW shortwave receiver
19xx |
3.5 7 14 21 28 MHz receiver,
supply 230VAC
|
|
OE3DKW |
RA0203190 |
ra-kü |
| OE3DKW 144MHz amplifier
19xx |
Power amplifier for the 144MHz
band. P.a. tube 829B, 4 auxiliary tubes for grid 2
stabilisation. Required drive power unknown. Relays for
PTT incorporated. Fully metered. Power supply 230VAC
built in. |
|
OE3DKW |
RA0203191 |
ra-kü |
| OE3DKW modified shortwave wartime
BC-342 receiver 1940 |
tbd MHz receiver, supply 230VAC,
improved by OE3DKW
|
|
OE3DKW |
RA0203192 |
ra-kü |
| OE3DKW RP RX 19xx |
General coverage shortwave
receiver, supply 230VAC, built by OE3DKW after an
article in Radio Praktiker (RP)
|
|
OE3DKW |
RA0203193 |
ra-kü |
| OE3DKW TX 19xx |
Portable 50W plate input CW/AM
shortwave transmitter, supply 230VAC, built by OE1SBA,
tubes EF80 ECL80 2E25, modulator with EL95 and ECCxx,
stabiliser tube 150V/30mA, separate power supply with
settable bias
|
|
OE3DKW |
RA0203194 |
ra-kü |
| |
|
|
|
|
|
| OE5PRL shortwave receiver |
3.5 7 14 21 28 MHz receiver,
supply 230VAC
|
|
OE5PRL |
RA0203200 |
al-k2
|
| OE5PRL shortwave transmitter |
1.8 3.5 7 14 21 28 MHz
transmitter, supply 230VAC, power t.b.d.
|
|
OE5PRL |
RA0203201 |
al-k1
|
OE5PRL 28-to-70
transverter
|
Transverter from 28 MHz to 70 MHz, supply 230VAC
|
|
OE5PRL |
RA0203210 |
al-k2
|
| OE5PRL VHF transceiver |
144 MHz transceiver, supply 230VAC |
|
OE5PRL |
RA0203220 |
al-k2
|
OE5PRL QRP transmitter
|
QRP transmitter, supply 12VDC
|
|
OE5PRL |
RA0203230 |
al-k2
|
| OE5PRL VHF receiver |
144 MHz receiver, supply 12VDC
|
|
OE5PRL |
RA0203240 |
al-k2
|
| |
|
|
|
|
|
| OE6WU+ satellite FAX
receiver |
136 MHz satellite FAX receiver and
buffer |
|
OE6WU |
RA0204000 |
ra-lkk |
| OE6WU+ short wave linear |
Very compact 80 - 10 m amateur
band linear amplifier with separate power supply, 500 W
out using one 3-500Z |
|
OE6WU |
RA0206000 |
ra-lkk |
| OE7UT+ QRP-transceiver 19xx |
80m QRP transceiver, supply 12VDC,
further data unknown |
|
OE7HRI |
RA0206050 |
al-fu |
| OE7UT+ shortwave transmitter 19xx |
Transmitter with VFO and
exchangeable tank coil, multiple supply voltages needed
from matching power supply, output tube probably 807,
further data unknown |
|
OE7HRI |
RA0206060 |
ra-kü |
| |
|
|
|
|
|
| Orega BLOC ATLAS |
French broadcast receiver, LW, MW,
SW, made for putting it inside a piece of furniture,
without AF amplification and power supply section which
supposedly was a separate AF amplifier with power
supply. Conncetion to other equipment via a NOVAL tube
base. Tube complement EF41 ECH42 EAF42 EM4 for built in
magic eye |
Orega BLOC
ATLAS |
dpt. 01 |
RA0293000 |
al-we |
| |
|
|
|
|
|
| PALTEC GS2 |
Satellite receiver 950 - 1750 MHz
|
|
OE6WU |
RA0207000 |
ra-lkk |
| |
|
|
|
|
|
| PAN MegaTop 1980 |
CB Radio, 40 channels |
|
krems |
RA0207100 |
al-k1 |
| |
|
|
|
|
|
Philips WR1/P
1941
|
Field portable bbattery operated broadcast receiver
"Rudi" LW, MW, SW, "D" glass "25 series" tubes DCH25
DF25 DF25 DAC25 DC25 DDD25 DF26 U518H supply 1.4VDC and
90VDC |
|
family |
RA0209000 |
al-ku |
| Philips 2511 1928 |
Broadcast receiver with bakelite case and key, needs
external speaker and loop antenna, tubes E442 E442 E415 or
E424 C443 506
|
|
Hül |
RA0210000 |
ra-lkk
|
| Philips 695A 1936 |
Broadcast receiver, tubes AK2 AF3 ABC1 AL1 AZ1
|
|
nickel |
RA0210005 |
al-ku
|
| Philips Ouverture 461A
1938 |
Broadcast receiver
|
|
cdö |
RA0210010 |
cdö
|
| Philips A102A 1938 |
Broadcast receiver
|
|
cdö |
RA0210020 |
cdö
|
| Philips Opera 846U 1938 |
Broadcast receiver
|
|
cdö |
RA0210030 |
cdö
|
| Philips 471A 1939 |
also Korona 80, Broadcast receiver, tubes EK2 EF9 EBL1
AZ1 EM1
|
|
nickel |
RA0210030 |
al-ku
|
| Philips Ungarn Szuper Triumph
1750 1939 |
Broadcast receiver
|
|
cdö |
RA0210040 |
cdö
|
| Philips A60A 1941 |
Broadcast receiver, equivalent to Radiola RA190A, tubes
ECH3 EF9 EBF2 EBL1 EM4 AZ1
|
|
nickel |
RA0210050 |
al-ku
|
| Philips Oesterreich B3A13A/01 1961 |
Broadcast stereo receiver "Sonate" LW MW SW VHF-FM using
7 tubes: ECC85 ECH81 EF89 EABC80 EM84 EL84 EZ80 |
|
kaheiho |
RA0210100 |
ra-lkk
|
| Philips Oesterreich B3A73A 1957 |
Broadcast stereo receiver "Rhapsodie" LW MW SW VHF-FM
using 7 tubes: ECC85 ECH81 EF89 EABC80 EM81 EL84 EZ80 |
|
kaheiho |
RA0210200 |
ra-lkk
|
| Philips Oesterreich B7X65A 1957 |
Broadcast stereo receiver "Rhapsodie" LW MW SW VHF-FM
using 8 tubes: EF89 ECH81 EBF80 ECC83 EM80 EL84 EL84 EZ81 |
|
nickel |
RA0210205 |
al-ku
|
Philips N3A94V
1961
|
Battery operated dashboard-mounted car radio receiver
for medium and long wave, with its vibrator converter,
tube complement 2xECH81+EL95, one transistor, supply 6VDC
or 12VDC
|
|
eb |
RA0211000 |
ra-wk |
Philips D2935
1984
|
Portable Radio synthesized Receiver, battery and mains
suply |
|
do |
RA0212000 |
al-ga4 |
Philips D2935
1984
|
Portable Radio synthesized Receiver, battery and mains
suply |
|
do |
RA0213000 |
al
|
| Philips 23TA324A
1962 |
BW TV receiver, supply 220VAC, 23 tubes
|
|
rau |
RA0213100 |
al-k1 |
| |
|
|
|
|
|
| President AX43 |
CB transceiver AM/FM |
|
puc |
RA0213500 |
ra-wk
|
| |
|
|
|
|
|
| PYE Rees Mace
R.M.H. 1942 |
Broadcast receiver |
|
cdö |
RA0213540 |
cdö
|
| PYE Westminster
W15FM 1968 |
FM transceiver 140 - 170 MHz, crystal controlled,
speaker/microphone, power 6 Watts. |
|
KathSie |
RA0213550 |
Al-fu
|
| PYE CAT 1953 |
British Admiralty long, medium and short wave receiver,
8 ranges (0.055-0.125, 0.1-0.26, 0.26-0.66, 0.65-1.55,
1.5-3.4, 3.4-7.2, 7-15 and 15-31MHz), single conversion
for bands 1,2,4,5, double conversion for bands 3, 6,7, 8,
tube complement 6BA6(=EF93) 6C4(=EC90) 2xECH81 2xEF92,
2xEB91, EF92, 6CH6(=EL821), EF92, QS150/45, separate power
supply with AF-amplifier for up to 245VAC, IF 1.6 and
0.46MHz, mass 20kg, cube form with metallic case, part of
PYE radio set 619 |
|
Kittsee |
RA0213560 |
Al-fu
|
| PYE Major 2060
1967 |
Long, medium wave car broadcast receiver, 2 ranges,
fully transistorised with 3xAF117, AF115, 2xNKT275 and
2xNKT450, AF output 8W, microphone input jack |
|
unger |
RA0213570 |
Al-fu
|
| |
|
|
|
|
|
| Quelle Universum
19xx |
Colour TV receiver (PAL system)
for VHF band I and III and UHF band IV
|
|
kaheiho |
RA0213900 |
ra-lkk
|
| |
|
|
|
|
|
| RACAL RA-17 |
Rack mounted continuous coverage
shortwave receiver, Wardley loop principle, no
accessories |
|
M3BVL |
RA0214000 |
al-we
|
| RACAL RA-17 |
Rack mounted continuous coverage
shortwave receiver, Wardley loop principle, with rack
and RA-37 fitted |
|
OE5MBL |
RA0215000 |
ra-kü |
| RACAL RA-17 |
Rack mounted continuous coverage
shortwave receiver, Wardley loop principle,with rack |
|
OE5MBL |
RA0216000 |
ra-kü |
| RACAL RA-17 |
Rack mounted continuous coverage
shortwave receiver, Wardley loop principle, no
accessories |
|
OE5MBL |
RA0217000 |
ra-lkk |
| RACAL RA-17 |
Rack mounted continuous coverage
shortwave receiver, Wardley loop principle, dismounted |
|
OE5MBL |
RA0218000 |
ba |
| RACAL RA-17 |
Rack mounted continuous coverage
shortwave receiver, Wardley loop principle, partially
dismounted, for parts |
|
OE5MBL |
RA0219000 |
al-ku |
| RACAL RA-37 |
Long wave converter for RACAL RA-17 receiver |
|
OE5MBL |
RA0220000 |
al-t5 |
| |
|
|
|
|
|
| Radiomarelli 114
1939 |
Broadcast receiver |
|
cdö |
RA0220500 |
cdö |
| |
|
|
|
|
|
| Radione Midget Dyn MG2
1939? |
Broadcast receiver with DC supply |
|
cdö |
RA0221000 |
cdö |
| Radione AU44
1940 |
Broadcast receiver |
|
cdö |
RA0221010 |
cdö |
| Radione 146GW
|
Small single tube medium wave regenerative receiver
using an RV12P2000, dry rectifier, output to earphones or
amplifier |
|
family |
RA0221020 |
ba |
| Radione G2
1931 |
Portable medium wave receiver; supply 220 VDC with tube
filaments supplied directly from a DC supply via
bleeding resistor, original power cable. No fuses. Two
tube regenerative receiver (triode A425 5V 100mA
filament directly heated, original pentode B543 replaced
by RV12P2000 pentode using 12V 78mA filament heated
indirectly) with external loudspeaker or earphones, one
tuned circuit, one variable feedback capacitor, volume
setting by anode voltage taps of pentode.
|
|
kun |
RA0222000 |
ra-lkk |
| Radione R2
Swiss 12V version |
Portable long, medium, short wave receiver; supply 110
- 220 VAC, also 12 VDC using a special vibrator; this
version employs steel tubes (EF13, ECH11, EF12, EBC11,
EDD11, EZ11). Original voltage selecting power cable,
plus a telescopic antenna that attaches to the side of
the radio. Case and electronics in perfect shape.
Additional markings of Swiss Telecommunications
Authority. Electronics visible here.
|
plastified copies and documentary photographs from war
use, Ser.Nr. 2164
|
ri |
RA0225000 |
ra-lkk |
| Radione R2 Swiss 12V
version |
Portable long, medium, short wave receiver; supply 110
- 220 VAC, also 12 VDC using a special vibrator; this
version employs steel tubes (EF13, ECH11, EF12, EBC11,
EDD11, EZ11). Original voltage selecting power cable,
dial protective glass broken, wrong wiring of filament
circuit. Electronics visible here.
|
Ser. Nr. 5549 |
dany |
RA0225500 |
ra-lkk |
| Radione R2
original 6V version |
for parts. No tubes. No dial.
|
Ser. Nr. 11697 |
faido |
RA0223000 |
ra-lkk |
| Radione R3
1942 |
Short wave receiver, early war version for vehicles
with 12V battery, range 2.5 to 25MHz, tubes EF13, ECH11,
EF12, EBC11, EDD11, EZ11 plus additional EBC11 working
as BFO, supply cable for 220VAC, ID plate missing
|
Ser. Nr. 11xxx |
tief |
RA0223330 |
ra-kü |
| Radione R3
1942 |
Short wave receiver, war version with BFO, supply
110/220VAC or 24VDC, empty case for display only
|
Ser. Nr. 11671 |
tief |
RA0223331 |
ra-kü |
| Radione R2
original 6V version |
Portable long, medium, short wave receiver; supply 110
- 220 VAC, also 6 VDC using a special vibrator; steel
tubes (EF13, ECH11, EF12, EBC11, EDD11, EZ11). No
voltage selecting power cable. Case repainted and
scratched, electronics in perfect shape. Inside view.
|
copy; Ser. Nr. 24600
|
oll |
RA0224000 |
ra-lkk |
| Radione R2
(6V) with EZ41 late wartime |
Portable long, medium, short wave receiver; supply 110
- 220 VAC, also 6 VDC using a special vibrator; this
version employs steel tubes (EF11 [installed. To be
checked whether this is the correct one], ECH11, EF12,
EF12, EF13, EDD11) and one glass tube EZ41. No voltage
selecting power cable. Case repainted and scratched,
screw for rear cover missing. Electronics in perfect
shape. Hint: This version seems to be a "parts on hand"
version. The EZ41 rectifier and also the replacement of
the EBC11 by a diode connected EF13 along with another
EF12 could have been an emergency modification due to
missing tubes during or shortly after the war.
Electronics visible
here
|
Ser. Nr. 25937
|
ri |
RA0226000 |
ra-lkk |
| Radione R2H-12V
from 1950 |
Portable long, medium, short wave receiver; supply 110
- 220 VAC, also 12 VDC using a special vibrator; this
1950 version does not use the usual wartime steel tubes
(EF13, ECH11, EF12, EBC11, EDD11, EZ11) but rather
American tubes from Sylvania, stamped "D": 7H7 RF
amplifier, 7S7 mixer and oscillator, 2 times 7R7 for
intemediate frequency amplification, rectifcation and
audio preamplification, 7C5 tetrode power audio
frequency amplifier, 7Y4 power rectifier; one vibrator;
original power supply cable for mains with coding
connector; no DC cable for 12 VDC supply; slightly
overpainted; finetuning mechanism for main dial; tape
recoder connections and microphone input added on top,
with additional side-mounted audio potentiometer; front
panel DC switch on volume potentiometer. Electronics visible here.
|
copied schematic for 6V version, differences limited to
12V filament circuitry. Ser. Nr. 29864
|
Echenevex |
RA0227000 |
ra-lkk |
| Radione R2
1950 |
Portable long, medium, short wave receiver, supply
110/220vac or 6VDC |
Serien Nr. 41847 |
cdö |
RA0225100 |
cdö |
| Radione R9
1950-55 "EAF42er" |
Portable long, medium, short wave receiver; supply 117
- 240 VAC, 6 VDC or 12 VDC; tubes 3xEAF42, ECH42, EL41,
EZ41; one vibrator; very good quality, all components
original, good selectivity through tuned preamplifier
ahead of mixer. Electronics visible here.
|
copied schematic; Ser. Nr. 869 |
ri |
RA0228000 |
ra-lkk |
Radione R12
1956
|
Portable long, medium, short wave receiver; supply 117
- 240 VAC, 6 VDC or 12 VDC; tubes "D", one vibrator;
very good quality, all components original, good
selectivity through tuned preamplifier ahead of mixer.
Electronics visible
here.
|
copied schematic; Ser. Nr. scratched out |
raa |
RA0228100 |
al-bu
|
| Radione R20
1957 |
Portable VHF, long, medium, short wave receiver; supply
117 - 240 VAC or operation with filament 1.5V and anode
90V batteries; D-Series battery tubes (DC90 DF96 DK96
DF96 DF96 DAF96 DL96); very good quality, all components
original, good selectivity through tuned preamplifier
ahead of mixer; roll-out blade aerial
|
|
ri |
RA0228500 |
ra-lkk |
| Radione R22T
1960 |
Long, medium, short wave broadcast portable receiver;
supply 9 VDC from two 4.5 flat dry batteries; fully
transistorised and last Radione portable without "FM"
|
|
leb |
RA0228700 |
ra-lkk |
| Radione R25T
1957 |
Portable VHF, long, medium, short wave receiver; supply
117 - 240 VAC or operation with batteries; D-Series
battery tubes (DF97 DK96 DF96 DF96 DF96 plus 6
transistors OC71 OC71 OC72 OC72 OC72 OC72); very good
quality, all components original, roll-out blade aerial
|
copied schematic; Ser. Nr. 1578 |
raa |
RA0228800 |
al-bu
|
| Radione SE1 1942 |
Long, medium and short wave portable measurement
receiver, tubes EF11, ECH11, EF11, EBF11, EBC11, EZ11,
GR150/A, supply 110/220VAC or 24VDC
|
Ser. Nr. 283 |
tief |
RA0223337 |
ra-kü |
| Radione WE
1928 |
Medium wave broadcast regenerative receiver; supply 117
VAC
|
|
tief |
RA0229000 |
al-k1 |
| Radione Musiktruhe
from 1958 |
Broadcast receiver, probably a Radione Duplex, built
into a small cupboard
|
|
ho |
RA0229500 |
al-wo |
| Radione Merkur A 1966 |
Broadcast receiver with add'l AF amplifier and AF
intercom built for schools by Kulhanek
|
|
melk |
RA0229600 |
al-ku |
| Radione Junior
A 1968 |
Mixed technology broadcast receiver, with RF transistors
BF173 and BF195, tubes ECH81, EAF801, ECL86 and EM84,
diodes 3xOA79 and B250C100. Supply 220VAC. |
|
horn |
RA0229700 |
ra-ki |
| |
|
|
|
|
|
| RCA ACR-136
1935 |
Short wave receiver for 0.54 to 18 MHz coverage, single
conversion, tube complement 6D6 6A7 6D6 6B7 6D6 41 80,
supply 117 - 240 VAC
|
|
ri |
RA0230000 |
ra-lkk |
| RCA ET-4336-H
1940 |
Crystal controlled short wave transmitter for 2 to 20
MHz coverage, 350W output, tube complement 807
(oscillator), 4 x 866A (rectifier), 2 x 805 (modulator),
2 x 813 (power amplifier), supply 117/230 VAC
|
pdf |
nö |
RA0230251 |
ra-to2 |
| RCA ET-4336-H
1940 |
Crystal controlled short wave transmitter for 2 to 20
MHz coverage, 350W output, tube complement 807
(oscillator), 4 x 866A (rectifier), 2 x 805 (modulator),
2 x 813 (power amplifier), supply 117/230 VAC
|
pdf |
nö |
RA0230252 |
ra-to2 |
| RCA SSB-1 1958 |
Crystal controlled short wave SSB filter-type
transceiver for 3 to 15 MHz coverage (block diagram here), 100W PEP
output, tube complement in the power supply: 3 x 5R4GY
(150mA rectifier), OA3, OD3, 2 x 12AT7=ECC81, 2 x 6AK6
(1Watt NF tube), tube complement radio and speech
clipper: 2 x 6146=QE05/40, 5 x 6BA6=EF93, 2 x 6CL6, 4 x
12AT7=ECC81, 4 x 6BE6=EK90, 4x 6AL5=EAA91, 12AX7=ECC83,
6U8=ECF82, 12AU7=ECC82. supply 117/230 VAC
|
pdf |
steyrpuch |
RA0230501 |
ra-lkk |
| RCA SSB-1
1958 |
Crystal controlled short wave SSB filter-type
transceiver for 3 to 15 MHz coverage (block diagram here), 100W PEP
output, tube complement in the power supply: 3 x 5R4GY
(150mA rectifier), OA3, OD3, 2 x 12AT7=ECC81, 2 x 6AK6
(1Watt NF tube), tube complement radio and speech
clipper: 2 x 6146=QE05/40, 5 x 6BA6=EF93, 2 x 6CL6, 4 x
12AT7=ECC81, 4 x 6BE6=EK90, 4x 6AL5=EAA91, 12AX7=ECC83,
6U8=ECF82, 12AU7=ECC82. supply 117/230 VAC
|
pdf |
BB |
RA0230502 |
ra-lkk |
| RCA SSB-1
1958 |
Crystal controlled short wave SSB filter-type
transceiver for 3 to 15 MHz coverage (block diagram here), 100W PEP
output, tube complement in the power supply: 3 x 5R4GY
(150mA rectifier), OA3, OD3, 2 x 12AT7=ECC81, 2 x 6AK6
(1Watt NF tube), tube complement radio and speech
clipper: 2 x 6146=QE05/40, 5 x 6BA6=EF93, 2 x 6CL6, 4 x
12AT7=ECC81, 4 x 6BE6=EK90, 4x 6AL5=EAA91, 12AX7=ECC83,
6U8=ECF82, 12AU7=ECC82. supply 117/230 VAC
|
pdf |
margit |
RA0230503 |
ra-kü |
| |
|
|
|
|
|
| Realistic C8-8 |
battery operated Taiwanese FM, VHF and shortwave
receiver |
|
ch |
RA0231000 |
al
|
| |
|
|
|
|
|
| REFCOM FC-60 |
Receiving converter from 50 kHz - 60 MHz to 100 MHz
higher |
|
family |
RA0232000 |
al
|
| |
|
|
|
|
|
| RFT Funkwerk Köpenick
FGS 401 (Typ 1340.21) |
Ship receiver KOPENA 14 kHz - 30
MHz - a 60 kg heavy weight, Barlow-Wadley principle,
works when it likes to because of contact problems |
Original |
DL2LSM |
RA0233000 |
al-k2 |
| RFT Funkwerk Köpenick
EKV
1975 |
Triple conversion short wave
receiver, mechanics stuck, mass 51kg, supply 220VAC or
24VDC |
Copy |
beck |
RA0233050 |
al-ku
|
|
RFT Messtechnik Berlin AFE12_proto
around 1980
|
Amateur receiver, completely
unmarked, case and colour resemble AFE-12 from RFT
(Messtechnik Berlin), 80m (3.5 to 3.8MHz) only,
industrial components (in particular the precision
mechanics), supply 12VDC or 220VAC |
none
|
meissen |
RA0233100 |
al-k1
|
| |
|
|
|
|
|
| RME 6900 |
Short wave receiver for amateur bands 80 - 10m |
Orig |
ri |
RA0234000 |
ra-lkk |
| |
|
|
|
|
|
| Rohde & Schwarz EK07D with NZ07 and NZ10/2 ISB conv. and NZ31001 monitoring amplifier |
0.5 - 30 MHz Shortwave receiver
with 25 tubes, teletype converter, double side band
converter, diversity reception controller |
Original with service |
ddf |
RA0235000 |
catu |
| |
Rigas Radio Rupnica or Riga Popov Radiotehnika,
Latvia
|
|
|
|
|
| Riga Popov Radiotechnika (RRR) Gauja |
Long and Medium Wave battery portable with leather case |
|
family |
RA0236000 |
ra-lkk |
| Riga Popov Radiotechnika (RRR) Selga |
Long and Medium Wave battery portable with leather case |
|
family |
RA0236100 |
ra-lkk |
Riga Popov Radiotechnika (RRR) Orbita 2 1971
|
Medium and Short Wave battery portable with leather case |
|
family |
RA0236200 |
ra-lkk |
| |
|
|
|
|
|
| SABA Freudenstadt
FD16 1965 |
Top of the line broadcast stereo receiver featuring two
push-pull-amplifiers.
|
|
kaheiho |
RA0236400 |
ra-lkk |
| |
|
|
|
|
|
| SADIR R87 1940 |
AM aviation and RADAR observation receiver, also known
as FuMB2 |
|
fm |
RA0236500 |
ra-lkk |
| |
|
|
|
|
|
| SAILOR R103
1960 |
Maritime SSB receiver for commercial fleet, 1.6 to 4.2
MHz crystal controlled, supply 220VAC or 12/24VDC |
|
wza |
RA0236600 |
al-k1 |
| |
|
|
|
|
|
| Salora HiFi
receiver and amplifier |
FM stereo broadcast receiver and amplifier |
|
ritva |
RA0237000 |
al
|
| |
|
|
|
|
|
| SATCOMM SSR-7700 |
Satellite receiver for broadcast |
|
goep |
RA0237500 |
al |
| |
|
|
|
|
|
| Scientific Radio SR-210 |
10 channel shortwave transceiver,
3x6146B finals, 2-30 MHz, built-in power supply 230 VAC,
Collins filters, LSB/USB/AM/CW/FSK |
original |
HB9G |
RA0238000 |
al-k2
|
| |
|
|
|
|
|
| Scott Car Radio MP4 player |
4x50W FM car audio system
|
|
grenoble |
RA0239000 |
boe |
| |
|
|
|
|
|
Seibt ER1 1940
|
Seibt broadcast receiver ER1
"Hasenstall", around 1940, tubes AK2, AF3, ABC1, AC2,
AM2, AL12, AZ12; able to
receive CW because of BFO (AC2 tube) that can be
switched in on the rear panel. AF output 8 Watts into
big speaker. Supply 220 VAC.
|
|
family |
RA0240000 |
ba |
| Seibt ER1 1940 |
Seibt broadcast receiver ER1
"Hasenstall", around 1940, tubes AK2, AF3, ABC1, AC2,
AM2, AL12, AZ12; able to
receive CW because of BFO (AC2 tube) that can be
switched in on the rear panel. AF output 8 Watts into
big speaker. Supply 220 VAC.
|
|
tief |
RA0240010 |
al-k1 |
| Seibt ER1 1940 |
Seibt broadcast receiver ER1
"Hasenstall", around 1940, tubes AK2, AF3, ABC1, AC2,
AM2, AL12, AZ12; able to
receive CW because of BFO (AC2 tube) that can be
switched in on the rear panel. AF output 8 Watts into
big speaker. Supply 220 VAC. Magic eye tube AM2 missing.
|
|
wza |
RA0240020 |
al-k1 |
| |
|
|
|
|
|
| SEL SEM-25 |
26 - 70 MHz 50 kHz channelised 15W
transceiver, supplied with 24 VDC |
|
hk01 |
RA0241000 |
al-wo |
| |
|
|
|
|
|
| SEMCO 1.5W FM TRCV 1967 |
144 - 146 MHz 1.5W FM portable transistorised
transceiver with VFO, supply 18 VDC from dry cells or externally |
|
6cy |
RA0241500 |
ra-lkk |
| |
|
|
|
|
|
| SFR RT531 |
3.5 - 30 MHz shortwave receiver
with power supply - ok |
|
dpt 01 |
RA0242000 |
ra-lkk |
| Sharp Ghetto Blaster |
Broadcast stereo receiver mains
and battery supply |
|
chr |
RA0242500 |
ra-lkk |
| |
|
|
|
|
|
| Shimizu SS-105S (also called Dynimex) |
Short wave transceiver 3.5 - 28
MHz for the classical amateur radio bands, 10W output.
Built around 1980. Rare. |
Original |
ri |
RA0243000 |
faido |
| |
|
|
|
|
|
| Siemens 31aG
1942 |
Broadcast receiver |
|
cdö |
RA0246040 |
cdö
|
| Siemens 93W
1939 |
Broadcast receiver, tubes ECH11 EBF11 EF11 EL11 EM11
AZ11 |
|
nickel |
RA0246040 |
al-ku
|
| Siemens Funk 145V615/1 |
1kW linear amplifier 2-20MHz -
modified for grounded grid drive 100W - to be used with
external 3 kV single phase HV supply |
my design |
OE4BKU |
RA0245000 |
al-wo |
| Siemens FSE30 |
Teletype converter for short wave
receiver E311 |
Original |
ddf |
RA0246000 |
al
|
| Siemens Rel 445 E311e1 |
Short wave receiver 1.5-30MHz |
Original |
ddf |
RA0247000 |
ra-lkk
|
| Siemens Klangmeister RG211 1971 |
Broadcast receiver for long,
medium, shortwave and VHF-FM
|
|
krems |
RA0247100 |
al-k1
|
| |
|
|
|
|
|
SIMOCO (Philips)PRM80
1989
|
2m band FM transceiver for mobile applications, power
6W, runs on 14VDC, functions and frequencies programmable
via special cable and software |
|
ampfl |
RA0248001 |
al-we
|
SIMOCO (Philips) PRM80 1989
|
2m band FM transceiver for mobile applications, power
6W, runs on 14VDC, functions and frequencies programmable
via special cable and software |
|
ampfl |
RA0248002 |
al-we
|
SIMOCO (Philips) PRM80 1989
|
2m band FM transceiver for mobile applications, power
6W, runs on 14VDC, functions and frequencies programmable
via special cable and software |
|
ampfl |
RA0248003 |
al-we
|
SIMOCO (Philips) PRM80 1989
|
2m band FM transceiver for mobile applications, power
6W, runs on 14VDC, functions and frequencies programmable
via special cable and software |
|
ampfl |
RA0248004 |
al-we
|
| |
|
|
|
|
|
| SONY ICF-2001 |
All wave receiver, synthesized,
battery operated |
Service manual |
ri |
RA0250000 |
al
|
| SONY ICF-7600 |
All wave receiver, synthesized,
battery operated |
|
9v |
RA0251000 |
al
|
| SONY |
Stereo Amplifier & cassette
recorder |
|
mike |
RA0252000 |
al
|
| |
|
|
|
|
|
| Spectrum
Communications TRX6-10H |
Transverter 28 MHz to 50 MHz,
output 10 W |
|
eb |
RA0253000 |
ra-lkk |
| |
|
|
|
|
|
Sport A.G. 386
(Velectra) 1936
|
Swiss Broadcast receiver with long, medium and
shortwave, equipped with 78 (pentode amp), 76 (triode),
6A7 (pentagrid converter), 78 (pentode amp), 6E5 (magic
eye), 75 (double diode - triode), 85 (double diode -
triode), 42E (power pentode) and 5Z3 (250mA rectifier) |
|
hül |
RA0254000 |
ra-lkk |
| |
|
|
|
|
|
| SSB Electronic TLA432-100 |
Linear power amplifier 432-440 MHz 100W, drive power 3
W, supply 12V, with supply of preamplifier via coaxial
line |
Original |
ri |
RA0255000 |
al
|
| |
|
|
|
|
|
| SSM Europa B
(Solid State Modules, Huddersfield) |
28 MHz/ 144 MHz Transverter,
receiving converter with FET's, transmit converter with
3 tubes, QQE 03/12 mixer and driver, QQE 06/40 final, 80
W output on 144 MHz, adjusted to fit FT-101E, works to
spec's after realignment |
Copy |
eb |
RA0256000 |
ra-lkk |
| |
|
|
|
|
|
| Stabo Stratofon P-12 1945 |
Citizen Band handheld transceiver, 12 channels, supply 8 times 1.2V accu
or 12VDC external, power 2W, built-in telescopic antenna |
|
Steyr_GB |
RA0256040 |
ra-lkk
|
| |
|
|
|
|
|
| Standard Telefon og Kabel Pan 358 1945 |
Norwegian broadcast receiver |
|
cdö |
RA0256050 |
cdö
|
| Standard C5200D |
Mobile transceiver 144 and 430
MHz, FM only, 12V supply 40 W |
|
F2YT |
RA0257000 |
al-bu |
| |
|
|
|
|
|
| STAR SR-700A 1967 |
Amateur shortwave receiver 3.5
to 30MHz, supply 220VAC, tubes 2x6BZ6 (EF-type), 4x6EA8 (ECF82), 2x6AU6 (EF94), 2x6BA6 (EF93),
6AQ5 (EL90), 6AL5 (EB91 or EAA91), OB2 (StV108/30), mass 14kg,
operates transceive with transmitter ST-700 |
|
OE3ASA |
RA0257100 |
ra-m9 |
| STAR ST-700 1967 |
Amateur shortwave transmitter 3.5
to 30MHz, supply 220VAC, tubes 6EA8 6EA8 6AQ8 6AQ8 6DK6
6EA8 6DK6 6AW8 12BY7 6146 6146 6EA8 6EA8,
operates transceive with receiver SR-700A |
|
BB |
RA0257200 |
ra-wk |
| STAR ST-700 1967 |
Amateur shortwave transmitter 3.5
to 30MHz, supply 220VAC, tubes 6EA8 6EA8 6AQ8 6AQ8 6DK6
6EA8 6DK6 6AW8 12BY7 6146 6146 6EA8 6EA8,
operates transceive with receiver SR-700A |
|
oe3asa |
RA0257201 |
ea-m9 |
| |
|
|
|
|
|
| Superstar CB |
Classic 40 channel all mode
CB-transceiver |
|
FC1GYO |
RA0257500 |
al
|
| |
|
|
|
|
|
| STE |
144 MHz AM FM 1W transceiver, all modules exist but the
units were never assembled |
Original |
oe6 |
RA0258000 |
ra-llk
|
| |
|
|
|
|
|
Stuzzi FM_Radiocord 804
1964
|
Mixed technology broadcast
receiver with 4-track tape recorder, supply 220VAC,
tubes ECC83 EC92 ECL86 EM87 and semiconductors AF124
AF125 3xAF116 2xOA79 OA81 |
|
horn-wolfg |
RA0258500 |
al-ku |
| |
|
|
|
|
|
| SWAN 100MX 1975 |
Shortwave amateur band transceiver
80 - 10m, transistorised, supply 14VDC 25A, mass 6.9kg |
|
Andi |
RA0259000 |
ra-wk |
| SWAN Cubic Astro 102BX 1981 |
Shortwave amateur band transceiver
160 - 10m, transistorised, supply 14VDC 25A, mass 6.9kg |
|
rhw |
RA0259025 |
ra-m10 |
| SWAN 260 Cygnet 1969 |
Shortwave amateur band transceiver
80 - 10m with built-in power supply for 117VAC and
12VDC, tube complement 4xHF93 (12BA6), 2xHK90 (12BE6),
6GK5 (EC type), 6LQ6 (EL type TV defl. tube), EM84
(6FG6), 6BZ6 (EF-type), ECC83 (12AX7), 6AQ5 (EC-type),
6JH8 (double anode switching tube) plus 5 transistors |
|
crp |
RA0259050 |
ra-wk |
| SWAN 270 Cygnet |
Shortwave amateur band transceiver
80 - 10m with built-in power supply for 117VAC and
12VDC, tube complement HF94 (12AU6), 2xHK90(12BE6), 6GK6
(EL-type 5W power), 6LQ6 (EL type TV defl. tube), 3xHF93
(12BA6), 2XECC83 (12AX7), EBC91 (6AV6), 6AQ5 (EC-type),
6JH8 (double anode switching tube) plus 5 transistors |
|
Nick |
RA0259100 |
ra-lkk |
| SWAN 350 with
SWAN 220 power
supply |
Shortwave amateur band transceiver
with CW-filter and 234VAC power supply |
Copy |
oll |
RA0260000
PC0095000
|
ra-wk |
| SWAN 400 1965
with SWAN 220
power supply |
Shortwave amateur band transceiver
with CW-filter and 234VAC power supply |
Copy |
bhb |
RA0260050
PC0095100
|
ra-wk |
| SWAN 400 1965 |
Shortwave amateur band transceiver
incomplete, for parts only |
nil |
bhb |
RA0260105
|
ra-wk |
SWAN 406 1965
|
Small remote VFO |
Copy |
bhb |
RA0260110
|
ra-wk |
SWAN 410 1965
|
Remote VFO
|
Copy |
bhb |
RA0260120
|
ra-wk |
SWAN 420 1965
|
Remote VFO |
Copy |
bhb |
RA0260130
|
ra-wk |
| SWAN 500 with 117XC |
Shortwave amateur band transceiver
with 117VAC power supply |
|
Nick |
RA0261000
PC0096000
|
ra-lkk |
| SWAN 500 with 117XC |
Shortwave amateur band transceiver
with 117VAC power supply |
|
bhb |
RA0261100
PC0096100
|
ra-wk
|
| SWAN 1200Z |
Shortwave amateur band amplifier
with 117/230VAC power supply, sporting 4 6LQ6 or 6KD6
tubes in grounded grid, peak envelope input power is
1200 watts. |
|
Erwin |
RA0262000 |
ra-lkk |
| SWAN Mark 2 |
Shortwave amateur band amplifier
with separate 117/230VAC power supply, sporting 2 3-400Z
tubes in grounded grid, peak envelope input power is
2000 watts. Modified to different power supply
connections, metering and QB3,5/750 tubes. |
|
igw |
RA0262020 |
al-fu |
| SWISS CB Mk1 |
CB transceiver |
|
puc |
RA0262500 |
ra-wk
|
| Telefongyar T331 1956 |
Broadcast Receiver, tubes ECH21
ECH21 EBL21 AZ1 EM4 |
|
nickel |
RA0262510 |
al-ku
|
| |
|
|
|
|
|
| Telefunken E127/KW4
1954 |
General coverage single conversion shortwave receiver
from the fifties, nine tubes (five EF85, two ECH81, one
EL84), 220VAC supply, quartz filters |
PC0095000 |
ri |
RA0263000 |
ra-lkk |
| Telefunken E127/KW5
1954 |
General coverage single conversion shortwave receiver
from the fifties, nine tubes (five EF85, two ECH81, one
EL84), 220VAC supply, quartz filters |
PC0096000 |
ri |
RA0264000 |
ra-lkk |
| Telefunken E127/KW5
1954 |
General coverage single conversion shortwave receiver
from the fifties, nine tubes (five EF85, two ECH81, one
EL84), 220VAC supply, quartz filters |
copy |
aac
|
RA0264005 |
al-k2
|
| Telefunken T540 1934/35 |
Pre war medium and long wave car receiver ("Autosuper")
using "A"-tubes replacing the original RENS1224,
RENS1234, REN914 and REN 1374d complement.
Originally believed to be a Telefunken T655 (looks very
similar but the T655 already uses "E"-tubes); recent
research showed that the "A" series tubes were replacing
the "RENxxxxxx" series with small socket wiring
modifications (AH1 for the RENS1224 hexode mixer,
AH1 for the RENS1234 hexode controlled IF amplifier, AC3
for the REN914NF-amplifier and AL1 for the REN1374d as
speaker tube). Supply 6 VDC, with mechanical
remote control to be mounted on dashboard, featuring
original key and station inscriptions. Speaker in case.
Case corroded but electronics is in reasonable shape.
Anode supply inverter box missing. |
|
family |
RA0265000 |
al-wo |
| Telefunken E454Bs "KwEa" 1938 |
1 MHz - 10 MHz (tubes RV2P800) |
Reprint |
OE6BD |
RA0266000 |
ba |
| Telefunken 6436WL
1937 |
Broadcast receiver technically
similar to the 6436WL but slightly different case, tubes
AK1 AF3 ABC1 AL1 AZ1_ |
- |
nickel |
RA0266010 |
al-ku |
Telefunken E454Bs
KwEa 1938
|
1 MHz - 10 MHz (tubes RV2P800),
partially dismounted and incomplete
|
Reprint |
rosen |
RA0266010 |
al-k1 |
| Telefunken compatible
speaker/supply for
KwEa |
Hi impedance Speaker, size
compatible to stand next to KWEa, anode supply 90VDC,
filament supply 2VDC 2A |
|
Birgit |
AM0062000 |
ba |
| Telefunken LWEa 1938 |
0.01 MHz - 1 MHz (tubes RV2P800) |
|
OE5NG |
RA0268000 |
ba |
Telefunken MWEc 1939
|
0.01 MHz - 1 MHz (9 tubes
RV12P2000), coverage 830kHz - 3Mhz
|
|
OE5NG |
RA0269000 |
al-ku |
| Telefunken S526X (transmitter and power supply),
actually it should look like this. |
1.5 - 4.285 MHz, fixed settings,
crystal controlled, AM, (tubes RL12T15 and RS391)Modulator and rack are missing. Used
for German field gendarmerie in the thirties.
|
|
OE5LBL |
RA0270000 |
ba |
| Telefunken V188/KW4 1955 |
1.6 - 30 MHz distribution
amplifier with 6 outputs, using 12 tubes EL803 |
|
ddf |
RA0271000 |
al-k2
|
Telefunken TornEb 1938
|
Regenerative receiver using 4 tubes
RV2P800, coverage 97kHz - 7095 kHz, supply 2VDC and
90VDC
|
|
family |
RA0272000 |
ba |
Telefunken TornEb 1938
|
Regenerative receiver using 4
tubes RV2P800, coverage 97kHz - 7095 kHz, supply 2VDC
and 90VDC |
|
family |
RA0273000 |
ba |
Telefunken Torn.E.b 1938
|
Regenerative receiver using 4
tubes RV2P800, coverage 97kHz - 7095 kHz, supply 2VDC
and 90VDC |
|
wza |
RA0273010 |
al-k1 |
Telefunken E443Bs
"UKWEe" 1935
|
Single conversion SW receiver covering 27,2 - 33,4 MHz,
7 tubes RV12P4000, supply 12VDC and 130VDC
|
|
family |
RA0274000 |
ba |
Telefunken TS10/131
"10 WSc" 1939
|
AM/CW transmitter 27,2 - 33,4 MHz, tubes RL12P35 RL12P35
RV12P4000 T2742
|
|
family |
RA0275000 |
ba |
| Telefunken AS59 or EM5 in France |
2.5 MHz - 20 MHz AM/Hell/CW 200 W
transmitter, tubes RL12T15 RS391 RS391 RS391 RL12T15,
mains supply using mercury vapour rectifiers
|
|
REB |
RA0276000 |
ba |
| Telefunken, for WW II,
named FuG16 |
38 - 58 MHz receiver part only |
|
family |
RA0277000 |
ba |
| Telefunken, for WW II,
named TornFub2 |
3 - 6 MHz transceiver, incomplete |
|
family |
RA0278000 |
ba |
| Telefunken, for WW II,
main chassis. No ID plate. |
Direction finding receiver |
|
Degenh. |
RA0279000 |
ba |
| Telefunken, for WW II,
named FuG10 |
Parts of airborne long wave
(300-600 kHz) and shortwave (3-6MHz) transceiver, namely
antenna relay, main switch, various odd parts, but
original manual |
ORIGINAL |
family |
RA0280000 |
ba |
Telefunken R-77 1961
|
Portable Short Wave receiver 2 -
12 MHz, looks like receiver of AN/GRC-9, DC-DC converter
for 28 VDC input, carrying bag, antenna wires, socket
for car antenna, 28VDC connecting cable. Uses D-series
tubes with filament 1.4 VDC 1L4=DF92 1R5=DK91 1L4 1R5
1S5=DAF91 3Q4=DL95 1R5, transistors 2N441 OD603 TF70
OD603 OD603, diodes OA126 OA131 OA131 OA131 OA131 |
ORIGINAL |
ri |
RA0281000 |
al |
Telefunken RT-77 1961
|
Portable Short Wave transceiver,
range 2 - 12 MHz, main unit of AN/GRC-9 radio set, tubes
2xDF92, 3xDK91, DAF91, 3xDL93, DL95, 2E22, OC3, power
output 15W, equipped with receiver R-77 and PP-77, power
cable and power supply DY88/GRC |
copy |
pwm |
RA0281050 |
ra-to2 |
| Telefunken Fu.G.7 1967 |
Portable government radio set for
simplex or duplex operation, 4m band, 75 - 77MHz and 85
- 87MHz, output power 10W
|
copy |
bhb |
RA0281100 |
al-k2 |
| Telefunken SSB Sender
1967 |
Shortwave transmitter, 100W
output, 1.6 - 25MHz, supply 220VAC, tubes EF85, ECC81,
EL80, EF85, EF85, EF85, EF85, EF85, ECC81, EL803, ECC81,
ECC81, Stv150/30, E55L, E55L, EL3010, EL3010, EL3010,
EL3010
|
copy |
BB |
RA0281200 |
ra-dato |
| Telefunken Train_Radio
1967 |
Operator terminal type "A" for
communication equipment of Austrian Railways
|
copy |
Ti |
RA0281210 |
al-k1 |
| Telefunken lic. to
Kapsch Train_Radio
1967 |
Operator terminal type "A" for
communication equipment of Austrian Railways
|
copy |
Ti |
RA0281211 |
al-k1 |
| Telefunken lic. to
KapschTrain_Radio
1967 |
Operator terminal type "B" for
communication equipment of Austrian Railways
|
copy |
Ti |
RA0281212 |
al-k1 |
| Telefunken Mikroport T200 1960 |
32.4 - 33.4 MHz receiver for
wireless microphone reception |
|
dany |
RA0281500 |
ra-kü
|
Telefunken 2B54GWKb 1942
|
AC or DC powered broadcast
receiver using U-tubes (UCH11 UBF11 UCL11 UY11).
Electronics complete but loudspeaker and dial glass
missing |
|
dany |
RA0281600 |
al-we |
Telefunken Katzenkopf
T340 1946
|
Broadcast receiver |
|
cdö |
RA0281620 |
cdö |
Telefunken Talisman 550W 1951
|
Broadcast receiver |
|
horn-wolfg |
RA0281625 |
al-ku |
Telefunken Condor 965 GWK 1948
|
Broadcast receiver |
|
cdö |
RA0281630 |
cdö |
| Telefunken Bajazzo Transistor 3091
1960 |
AC or DC powered portable
broadcast receiver. For parts. Damage from a heavy
shock, including displacement of dial and a broken
errite antenna disconnected form circuit board. |
|
puces |
RA0281650 |
al-bu
|
| Telefunken Bajazzo TS5411 1964 |
AC or DC powered portable
broadcast receiver. Semiconductors: AF102 AF135 AF136
AF136 AF138 AF137 OC602 AC122 AC116 AC117 AC117 |
|
puces |
RA0281651 |
al-bu
|
| Telefunken Bajazzo CR800
1978 |
AC or DC powered portable
broadcast receiver with built-in cassette recorder. |
|
kautzen |
RA0281652 |
ra-kü
|
| Telefunken HR-660 1981 |
AC powered portable broadcast
receiver/amplifier (2x30W). FM, SW, MW broadcast bands.
|
none |
unknown |
RA0281680 |
ra-lkk |
| |
|
|
|
|
|
| Telemit AM-50 |
25 - 50 MHz (to be verified), 50
Ohms unsymmetric to vertical antenna, 24DC power needed,
motor driven LC network with SWR bridge |
|
Dor |
AR0044000 |
al-k3
|
| |
|
|
|
|
|
| Teleton TF-182FB 1975 |
SW (1.7 - 30Mhz plus spread 49m band),
MW, LW and VHF-FM (88 - 108MHz) broadcast receiver, with BFO and fine tuning |
|
Gr.-S. |
RA0283500 |
ra-kü
|
| |
|
|
|
|
|
| Teltow T-1000
20xx |
Short wave linear amplifier 1.8 - 30 MHz with GU-74 tube |
orig |
gkw |
RA0281580 |
al-fu
|
| |
|
|
|
|
|
|
The Technical Material
Corporation (TMC)
GPR-90
1956
|
0.15-30 MHz receiver, double
conversion, superb quality, supply 115V 60 Hz, looks
like a copy of the Hallicrafters SX-88, 6AB4 RF Amp1,
6CB6 RF Amp2, 6AU6 first mixer, 6AG5 VFO, 6BE6 second
mixer and crystal oscillator, 6BA6 IF1, 3x 6BA6 for IF2
to 4, 6AL5 detector and noise limiter, 6AG5 BFO, 12AX7
Gain control, 6AU6 Calib, 6V6 AF power, OA2 stabiliser,
5U4 power rectifier Frequency Coverage 0.540 to
31.5MHz in 6 Bands: Band 1 - 0.54 to 1.4 MHz, Band 2 - 1.4
to 3.3 MHz, Band 3 - 3.2 to 5.6 MHz, Band 4 - 5.4 to 9.6
MHz, Band 5 - 9.4 to 17.8MHz, Band 6 - 17.3 to 31.5MHz;
Bandspread calibrated for the 160-10M Amateur Bands.
Reception modes AM/MCW/CW/SSB/FSK; Selectivity:
7/2/1.5/1/.5/.25KHz;
Receiver can be operated from battery power: 6VDC
at 5A and 180-300VDC at 100mA. |
Schematic |
HB9JI+ |
RA0283000 |
ra-lkk |
| |
|
|
|
|
|
| TenTec 1253, 1996 |
Regenerative Receiver for amateur
use |
|
property Ni |
RA0284000 |
al
|
| TenTec 505 (Argonaut), 1971 |
Small power shortwave transceiver
for amateur use, supply 12VDC, output 5W |
|
ybbs |
RA0284002 |
al-ku
|
| TenTec 405, 1971 |
Shortwave linear amplifier for the
Argonaut transceiver, supply 12VDC@8A, output 50W |
|
ybbs |
RA0284004 |
al-ku
|
| |
|
|
|
|
|
| Tesla RF-11, 1959 |
Portable shortwave transceiver,
coverage 23 to 28 MHz, output 30mW, powered by
batteries, similar to Feldfunksprecher "d" Dorette |
|
wza |
RA0284100 |
al-k1
|
| Tesla RF-11M, 1959 |
Portable VHF transceiver, coverage
48 to 51.5 MHz, output 30mW, powered by batteries.
similar to Feldfunksprecher "d" Dorette |
|
wza |
RA0284101 |
al-k1 |
| Tesla R-4, 1959 |
Shortwave receiver for Czech 100W
military transceiver, coverage 1.5 to 12 MHz, power
supply ZS-4 12VDC for
dynamotor or 220VAC (built-in) |
|
wza |
RA0284200 |
al-k1 |
| Tesla R-5, 19xx |
Portable military shortwave
receiver 1.5 to 22 MHz, power supply 220VAC (add-on
unit) |
|
dkw |
RA0284205 |
ra-kü |
| Tesla RM-31, 1959 |
Shortwave transceiver, coverage 2
to 5.9 MHz, 3W, tubes 1H33 1F3 1L33 3L31 RL15A, battery
supply |
|
dkw |
RA0284215 |
ra-kü |
| Tesla RS-41, 1959 |
Shortwave transmitter, coverage
1.5 to 12 MHz, power supply ZU-41 for 220VAC |
|
oe3dkw |
RA0284220 |
al-kü |
| |
|
|
|
|
|
| Tonfunk Violetta, 1954 |
Broadcast receiver, case, tubes
and speakers missing
|
|
|
RA0284200 |
al-we |
| |
|
|
|
|
|
| Trans Continents
Pandoni PD9
RS 1948 |
Broadcast receiver |
|
cdö |
RA02847s00 |
cdö |
| |
|
|
|
|
|
| TRIO JR-60 1963 |
Amateur shortwave receiver,
built-in power supply 230VAC |
|
igw |
RA0284800 |
ra-m11 |
| TRIO TR-2E 1967 |
144 MHz AM transceiver, power
supply, two VFO's, 17 tubes (6CW4 6BL8 6CB6 6BA6 6BE6
6AQ8 6AU6 12BY7 6360 12AV6 12AX7 6AQ5 and 4 transistors:
2SB449 2SB449 2SB449 2SB449), built-in power supply
230VAC |
|
F6JTI |
RA0284900 |
ra-lkk |
TRIO TS-510 1965
|
3 - 30 MHz transceiver in 6 bands,
power supply, CW-filter, second VFO, tubes S2001(6146)
S2001(6146) 6AW8A 12BY7A 6CB6 6BZ6 6BA6 6GH8A 6CB6 6BA6
6BM8 6GH8A 6BA6 6GH8A
|
|
F8RU+ |
RA0285000 |
ra-lk, ra-wk |
TRIO TS-515 1972
|
3 - 30 MHz transceiver in 6 bands,
no power supply, CW-filter. Small mech. damage to case.
tubes 6BA6 6BA6 6CB6 6CB6 12GN7A 12BY7A 6BZ6 6AW8A S2001
S2001 |
original box & manual |
ri |
RA0286000 |
ra-lkk |
TRIO TS-520 1975
|
3 - 30 MHz transceiver in 6 bands,
CW-filter, second VFO (al-ku), all cables, tubes 12BY7A
6146 6146 plus 64 semiconductors
|
|
ri |
RA0286500 |
ra-wk |
TRIO TR-2200 1969
|
Amateur Radio FM 2m transceiver |
|
de |
RA0287000 |
al
|
TRIO TR-2300 1979
|
Amateur Radio FM 2m transceiver,
144-146MHz in 25kHz steps, RF power 1W, supply 12VDC
from internal batteries or accumulators, or external |
|
de |
RA0287100 |
al
|
TRIO TR-2200 1969
|
Amateur Radio FM 2m transceiver |
|
F6KAR |
RA0288000 |
emc |
| TRIO LF-30 |
Low Pass Filter against TVI |
|
neup |
AR0045000 |
al
|
| TRIO VP-1 |
Bumper Mount for 3/8x24 threaded
antennae |
|
floh |
AR0046000 |
al
|
| |
|
|
|
|
|
| Unknown maker R 209 Mk II 1951 |
12VDC (external) battery powered
postwar sealed military radio receiver covering 1 MHz -
20 MHz in AM, FM, CW, using 10 tubes (CV131=EF92,
CV782=1R5=DK91, CV284=75B1, 4x CV785=1T4=DF91, 3x
CV784=1S5=DAF91)
|
|
family |
RA0291000 |
ra-lkk |
| Unknown Viennese
Maker: AM/CW Transmitter |
Semiprofessional "marriage" of a
Geloso G 212/TR transmitter with a Lorenz Lo40k39
transmitter and a Lorenz SGLE 0.2/12
power supply. Covers the 5 classical amateur bands on
shortwave in CW or AM using two 6146 in the final. The
modulator was put into the power supply. Further data
unknown. |
|
gr |
RA0292000 |
al-wo
|
| Unknown maker BC RX |
German broadcast receiver, LW, MW,
SW, FM-band, no tubes, no case |
|
dany |
RA0292500 |
al
|
| Unknown maker UHF Amplifier |
UHF amplifier 225 - 400 MHz with 2
tubes 4X150 in the final, no power supply |
|
F'hafen |
RA0294000 |
ra-lkk |
| Unknown Russian maker:
LV6 (Polish Production) |
1kW linear amplifier 1.5-30 MHz,
variometer tuning in four configuration ranges, with
East German three phase power supply, power tube GU43B,
three other tubes for preamplification from the 100 mW
level to full power; no frame to plug in units which
would require an extensive wiring job |
|
F'hafen |
RA0295000 |
ra-lkk |
| |
|
|
|
|
|
| Valst Electrical Factory (Riga, Lettland,
formerly USSR) VEF 12 1969 |
Russian broadcast and shortwave portable receiver - high
quality reception, battery 6 times 1.5V or 9VDC (very
clean) external power source |
|
svet |
RA0297000 |
al-bu
|
| Valst Electrical Factory (Riga, Lettland,
formerly USSR) VEF 202 1975 |
Russian broadcast and shortwave portable receiver -
high quality reception, battery 6 times 1.5V or 9VDC
(very clean) external power source
SPECIAL FEATURE: Contains the original FACTORY
WORKER'S DECLARATION FOR GOOD WORKMANSHIP (The USSR
warranty).
This radio was made in 1975 commemorising the 40th
anniversary of the end of WWII
|
|
kwu |
RA0297100 |
al-bu
|
| Valst Electrical Factory (Riga, Lettland,
formerly USSR) VEF 214 1978 |
Russian portable broadcast and shortwave receiver -
high quality reception, battery 6 times 1.5V or 9VDC (very
clean) external power source |
|
bak |
RA0297200 |
ra-kü
|
| |
|
|
|
|
|
| Voronezh Radiofabrik Alpinist |
Long and medium wave portable broadcast receiver |
|
family |
RA0007500 |
al-k1
|
| Voronezh Signal Radio Works R-109M 1964 |
Military transceiver 21 to 28.5 Mhz 1W FM with whip
antenna "Kulikov", design similar to German portable
radios of WW2, tubes 1Ж17Б 1Ж18Б 1Ж18Б 1Ж18Б 1Ж18Б 1Ж18Б
1Ж18Б 1Ж18Б 1П24Б 1Ж29Б, supply 4.8VDC
|
Original |
Jain |
RA0021110 |
al-k1
|
| Voronezh Signal Radio Works R-109M 1964 |
Military transceiver 21 to 28.5 Mhz 1W FM with whip
antenna "Kulikov", design similar to German portable
radios of WW2, tubes 1Ж17Б 1Ж18Б 1Ж18Б 1Ж18Б 1Ж18Б 1Ж18Б
1Ж18Б 1Ж18Б 1П24Б 1Ж29Б, supply 4.8VDC
|
Original |
wza |
RA0021111 |
al-k1
|
| Voronezh Signal Radio Works R-109M 1964 |
Military transceiver 21 to 28.5 Mhz 1W FM with whip
antenna "Kulikov", design similar to German portable
radios of WW2, tubes 1Ж17Б 1Ж18Б 1Ж18Б 1Ж18Б 1Ж18Б 1Ж18Б
1Ж18Б 1Ж18Б 1П24Б 1Ж29Б, supply 4.8VDC, German
inscriptions
|
Original |
wza |
RA0021112 |
al-k1
|
| Voronezh Signal Radio Works R-109M 1964 |
Military transceiver 21 to 28.5 Mhz 1W FM with whip
antenna "Kulikov", design similar to German portable
radios of WW2, tubes 1Ж17Б 1Ж18Б 1Ж18Б 1Ж18Б 1Ж18Б 1Ж18Б
1Ж18Б 1Ж18Б 1П24Б 1Ж29Б, supply 4.8VDC, German
inscriptions
|
Original |
wza |
RA0021113 |
al-k1
|
| Voronezh Signal Radio Works UM-2 1964 |
Range extender for the R-109M transceiver, using a 10W
amplifier with the 6П23П beam power tube, supply 4.8VDC
|
Original |
tief |
RA0021120 |
al-k1
|
| |
|
|
|
|
|
| Western Electric GF-11 |
Shortwave aircraft transmitter |
|
UA3ADR |
RA0298000 |
ra-lkk |
| |
|
|
|
|
|
| WSW 583W Tango 58,
1957 |
Broadcast receiver for VHF-FM and
LW MW broadcasting, tubes ECC85 ECH81 EF89 EABC80 EM81
EL84 Rectifiier B250C90 |
|
osw |
RA0298500 |
ra-wk |
| WSW Arioso 1957 |
Broadcast receiver for LW MW SW
broadcasting, tubes ECH81 EF89 EBC41 EL84 EM81 |
|
nickel |
RA0298510 |
al-ku |
| |
|
|
|
|
|
| YAESU (Sommerkamp) FL-DX2000 1969 |
Shortwave amateur band linear amplifier, modified for
better performance by a gifted Swiss ham |
see HB9 amateur make |
|
RA0142500 |
ra-wk |
| YAESU (Sommerkamp) FL2000B 1972 |
Shortwave amateur band linear amplifier, modified for
better performance for use with two Soviet GI-7B tubes (copy of Telefunken LD9) |
none |
|
RA0142600 |
ra-lkk |
| YAESU FRG-7 1976 |
Amateur shortwave receiver |
|
fc1gyo |
RA0185000 |
al
|
| YAESU FT-23R 1987 |
VHF handheld transceiver with
loading base and rechargeable battery pack |
Original |
ri |
RA0299000 |
al-bu
|
| YAESU FT-101E 1975 |
1.8 - 30 MHz in 11 bands, power
supply included for 12VDC or 230 VAC (tubes 12BY7A +
2xsweep), with 2m transverter listed under "SSM" above |
|
J28 |
RA0302000 |
al
|
| YAESU FT-200 1969 |
classic amateur band transceiver
with tubes 6BZ6 6U8 6BA6 6BZ6 12AX7/ECC83 6BM8
12AU7/ECC82 12AX7/ECC83 7360 6CB6 6EJ7/EF184 6AV6/EBC91
12AU7/ECC82 12BY7/EL180 6JS6A 6JS6A with power supply FP-200
|
|
rbc |
RA0302500 |
al-k2
|
| YAESU FT-221R 1976 |
VHF desk top SSB/CW/FM/AM transceiver |
|
oe5uvl |
RA0198500 |
al-680Fu
|
| YAESU FT-224 1975 |
VHF portable 144MHz FM transceiver with Sommerkamp markings,
13.8V external or internal battery supply, power 1/10W |
|
6cy |
RA0198512 |
ra-lkk
|
| YAESU FT-736 1988 |
50 MHz, 144 MHz, 430 MHz,
CW-filter, 220V/12V with both cables |
Original |
HB9CUY, birthday |
RA0301000 |
ra-bu |
| YAESU FT-290R 1981 |
VHF portable SSB/CW transceiver |
|
fc1gyo |
RA0198000 |
al-k2 |
| YAESU FT-450 2007 |
Shortwave plus 6m 100W
transceiver, running on 13.8 VDC 22A |
Original |
ri |
RA0300000 |
sü
|
| YAESU FT-757GX 1984 |
Amateur shortwave transceiver |
|
hb9ano |
RA0302000 |
kar
|
| YAESU FT-DX560 1970 |
3.5 - 30 MHz classical amateur
bands, power supply included for 230 VAC (tubes: V7 =
VR105 or 0B2, V1 = 6BZ6, V2,205,211 = 6BA6, V3 = 6AH6,
V4 = 6GK6, V201,202 = 6CB6, V203 = 6BE6, V204 = 6BZ6,
V206,213 = 12AU7/ECC82, V207 = 7360, V208 = 12AX7/ECC83,
V209 = 12AT7/ECC81, V210 = 6BM8, V212 = 6U8/6KD8, Power
Amp V5/V6 = 6KD6, a tv-deflector tube with 33W plate
dissipation and 1Amp peak cathode current) |
Original |
BS |
RA0302500 |
ra-wk
|
| |
|
|
|
|
|
| Zellweger E-646 1980 |
Shortwave receiver with original
separate 24VDC power supply, CW/LSB/FSK, 2 - 12 MHz,
with original accessory bag |
Original |
ase |
RA0307000 |
kar |
| Zellweger SE-222 1956 |
Shortwave mixed technology
transistor and tube transceiver with original separate
power supply free of electrolytic capacitors,
CW/LSB/FSK, 1.7 - 3.5 MHz, 100W, built-in manual tuner,
symmetric antenna connection 450 Ohms, uses only 3 types
of tubes (E95F, ECC81, 6146), final transmitter stage
and blower removed, no clock. Power unit is SG-222 |
Original
SE-222 Nr. 194
SG-222 Nr. ?
|
cbt |
RA0303000
PC0106000
|
ra-kü
|
| Zellweger SE-222 |
Shortwave mixed technology
transistor and tube transceiver with original separate
power supply free of electrolytic capacitors,
CW/LSB/FSK, 1.7 - 3.5 MHz, 100W, built-in manual tuner,
symmetric antenna connection 450 Ohms modified to single
ended, transceiver housing missing, original microphone,
original headphone, uses only 3 types of tubes (E95F,
ECC81, 6146) - in use on 160m once a week. Mechanical
7-day Swiss clock. Power unit is SG-222 |
Original
SE-222 Nr. 487
SG-222 Nr. 355
|
bci |
RA0304000
PC0107000
|
ra-lkk
|
| Zellweger SE-222 |
Shortwave mixed technology
transistor and tube transceiver with original separate
power supply free of electrolytic capacitors,
CW/LSB/FSK, 1.7 - 3.5 MHz, 100W, built-in manual tuner,
symmetric antenna connection 450 Ohms, all covers with
corresponding numbers, works after repair of T/R-relay
circuitry, uses only 3 types of tubes (E95F, ECC81,
6146). Power unit is SG-222 |
none |
ji |
RA0305000
PC0108000
|
al-680
|
| Zellweger SE-222 |
Shortwave mixed technology
transistor and tube transceiver with original separate
power supply free of electrolytic capacitors,
CW/LSB/FSK, 1.7 - 3.5 MHz, 100W, built-in manual tuner,
symmetric antenna connection 450 Ohms, uses only 3 types
of tubes (E95F, ECC81, 6146). Clock damaged by impact.
Interior not checked. Transmitter cover has
corresponding number. Full set of cables, headphones,
microphone, test set, antenna-to-twinlead connection
cables 25cm. Power unit is SG-222
|
SE-222 Nr. 282
SG-222 Nr. 218
|
ri |
RA0306000
PC0109000
|
al-k1
|
| Zellweger SE-415 |
Shortwave transceiver 2 - 52 MHz
1kW; Set includes power units for receiver and
transmitter are RXPS-SE415
(with 1 spare) and TXPS-SE415
(with 3
spares).
Single elements include the AT-415 three
phase connection box with built-in solid-state 400Hz
inverter (with 3 spares),
the signal unit S-415
(with one spare),
the receiver RX-415,
the two master oscillators MO-415, the three
phase regulation transformer ST-SE-415, the
SWR-meter SWR-SE-415,
and the transmitter TX-415. Other items are part of the radio
truck equipment with a large overlap to the SE-430,
listed below. |
copy
|
SQ
|
RA0306000
PC0110000, PC0110010
|
al-k2
|
| Zellweger SE-430 |
Shortwave transceiver 2 - 12 MHz
200W; Power unit for the transmitter is S-430
|
original
|
Ka ri |
RA0306000
PC0109000
|
680Fu
|
| |
|
|
|
|
|
| Zenith 8G005YT Trans–Oceanic
Clipper 1950 |
Portable broadcast receiver |
|
cdö |
RA0307000 |
cdö |
| Zenith Tone Register 7H820r 1950 |
Portable broadcast receiver |
|
cdö |
RA0307010 |
cdö |
| Zerdik 44W 1939 |
Broadcast receiver, tubes ECH11 EBF11 EL11 AZ11 |
|
nickel |
RA0307020 |
al-k3 |
| |
|
|
|
|
|
| Zodiac P-5006 |
Portable 27MHz transceiver, 3W |
|
tief |
RA0308500 |
al-k1 |
| |
|
|
|
|
|
| ZTR 2724 |
East German Medium Wave broadcast receiver |
|
eb |
RA0308000 |
sh1 |
| |
|
|
|
|
|
| ZZ ZZ145 |
VHF linear amplifier, any mode
including FM, 144 - 146 MHz, 600W output at 50W drive,
built-in power supply |
|
eb |
RA0309000 |
ra-lkk |
