| What | Technical details |
Manuals
|
whd Orig
|
Inv.
Nr.
|
Where
|
| AAI N1201SA 2023 | Antenna analyzer 135MHz to 2.7GHz 50 Ohms, supply via USB | mstock | MA0000024 | al-fu | |
| AG für Messapparate Bern | Volt and Ammeter in wooden case, 150/300/600 Volt and 5/40 Amp ranges | ri | MA0001000 | ra-wk | |
| AEG Duty-Cycle-Meter 19xx | Clock-type duty cycle meter, operational voltages 220VAC for synchronous motor and internal clutch | wh | MA0001500 | al-fu | |
| Alfa-Radio (Société Industrielle Alfa (SIA); Bruxelles ALFA_radiotester 1960 | U, I, R multimeter in original box, with test leads | manfred | MA0001900 | al-fu |
|
| APPA 17 | Pencil Tester | fa | MA0002000 | al |
|
| Ate Brake pressure tester | 4-gauge pressure measuring set for hydraulic brakes and vacuum-assisted hydraulic brakes | original | rö | MA0003000 | al |
| Auerswald FZ-1310 1988 | Frequency counter with highly
stable TXCO +/- 1ppm |
jtb | MA0003500 | al-fu |
|
| Avo Universal Measuring Bridge Type 1 1958 | L C R Bridge | ce | MA0004000 | al |
|
| Avo Avometer 1964 | V A Ohm multimeter without accessories | ka | MA0005000 | al |
|
| Avo Avometer model 8 1964 | V A Ohm multimeter without accessories | ce | MA0006000 | ra-kü |
|
| Avo Avometer 1964 | V A Ohm multimeter with leather poach and original leads | Marche P. | MA0007000 | al | |
| Avo Avometer 1964 | V A Ohm multimeter with leather poach and original leads | wgl50 | MA0008000 | al | |
| Avo Avometer 1964 | V A Ohm multimeter with leather poach and original leads | wgl50 | MA0009000 | al | |
| Avo Avometer 1964 | V A Ohm multimeter without accessories | prg | MA0010000 | ra-kü |
|
| Avo Avometer 1964 |
V A Ohm multimeter with leather poach and original leads | wgl50 | MA0011000 | al | |
| Avo HV divider 1964 | 20 kV divider for Avometer | ce | MA0012000 | al |
|
| Avo Transistor Analyser Mk2 1960 | Battery powered transistor analyser |
wgl50 |
MA0013000 | ra-lkk | |
| Avo VCM 4272-3 | Universal tube tester, perfectly ok |
wgl50 |
MA0014000 | al-wo | |
| Avo VCM 163 1966 | Universal tube tester, perfectly ok |
wgl50 |
MA0015000 | al-wo | |
| Avo VCM MK4 1963 | Universal tube tester, perfectly ok |
wgl50 |
MA0016000 | al-wo | |
| Ballantine 323
1975 |
High Frequency Millivoltmeter | veb | MA0017000 |
al |
|
| Ballantine 323 1975 | High Frequency Millivoltmeter | veb | MA0018000 |
al |
|
| BBC Scope Multimeter 1989 | One of the first scope multimeters | ecarn | MA0018400 | al-k2 | |
| BBC Profitester 1990 | Mains parameter tester (Icc, U, Un,...) | ecarn | MA0018500 | al-k2 |
|
| BELCO BR-8 1968 | RLCT measurement bridge, supply 9 Volt. Measures resistance, inductance, capacitance and winding ratio. | ri | MA0019000 | al | |
| BELVAR C1-94 1975 | Oscilloscope, 10Mhz bandwidth | wza |
MA0019100 | al-k1 | |
| Benning Solar PV1 20xx | System measurement apparatus for photovoltaïc panels with case, software and original leads | original | 3812 |
MA0019150 | ra-wk |
| Bittorf und Funke RPG4-3 1943 | Wehrmacht tube tester, for normal and special Wehrmacht tubes, complete with cards | F'hafen | MA0020000 | ra-lkk |
|
| BK Precision Model 290 1963? | extended range Multimeter with original probes | original | doro | MA0021000 | ra-to |
| BK Precision Model 465 1965 | CRT tester | oe5mbl | MA0022000 | al | |
| BK Precision Model 3010 1990 | 1 MHz Function Generator | sigi | MA0023000 | al |
|
| Boonton 202-B 1955 |
TV Signal Generator | ri | MA0023250 | al-wo | |
| Bosch EFAW 105 1969 | Automobile tester for various functions, supply by auto battery | dor | MA0023500 | al |
|
| Brian Leroux Jeanno Ampèremeter | Radio Frequency Current Meter (heated wire meter) | cx9aab | MA0024000 | al |
|
| Brüel & Kjær 2209 | Impulse Sound Level Meter, 2 Hz - 70 kHz, RMS at crest factor up to 40, also good for vibration measurement, range up to 140 dBA, equipped with the original microphone for acoustic measurements. Works with 3 batteries R20. Sligt corrosion in battery housing. | pdf and copy | ri | MA0025000 | al-k2 |
| Cadremo Multimeter | Classic "multimeter", using 2 "AA" batteries for resistance measurements | ri | MA0026000 | al | |
| Cadremo Double Voltmeters | Home made "multimeter" 15 and 150V range | GE flea | MA0027000 | al | |
| J.I.Case Hourmeter 1965 | Hourmeter from J.I. Case, Racine, Wisconsin | family | MA0028000 | al-k2 |
|
| CEWE Ampèremeter 19xx | Swedish moving coil ampère meter, scale 300A, current through instrument 5mA | oevg | MA0028100 | al-fu |
|
| CEWE Voltmeter 19xx | Swedish voltmeter, scale 60V FS | oevg | MA0028101 | al-fu |
|
| Chaleur S.A. 2000 | Fuel level gauge for a 2000 litre reservoir | puc | MA0028500 | poep |
|
| Chauvin Arnoux Megohmmeter | Classical battery powered Megohmmeter | ecarn | MA0028700 | al | |
| Chauvin Arnoux Polycontrole | Multimeter class 0.5 | lyon | MA0028741 | al-k2 |
|
| Chauvin Arnoux Polycontrole | Multimeter class 0.5 | lyon | MA0028742 | al-k2 |
|
| Collins Meter 1ADC | Plate current meter for 30S-1 Linear Amplifier | gkr | MA0028748 | ra-wk |
|
| Compagnie des Compteurs et Matériel d'Usine à Gaz Plurimetre Type 145 1945 |
Precision multimeter for voltage, currents, capacity, resistance (no AC functions because of broken measurement recitifier). described well in the "BULLETIN ANALYTIQUE DU COMITE DE COORDINATIONDES TELECOMMUNICATIONS IMPERIALES" en 1947: Plurimetre type 145 |
balme | MA0029000 | al |
|
| Compagnie des Compteurs et Matériel d'Usine à Gaz Laboratory Ampère Meter 1952? | Precision current meter with four ranges. 0.5% accuracy. Desk top model. | ri | MA0029500 | al | |
|
COSSOR 3100 1975 |
British Oscilloscope, bandwidth 40MHz on two channels
using a custom-designed single beam CRT |
orig. manual |
krems |
MA0029700 | al-k1 |
|
CTR SG-25+HRV-240+SWG26 1967 |
Signal generator 0.12-500MHz / VTVM / Audio generator 10 Hz - 21 kHz | eb | MA0030000 | al-k2 |
|
|
CTR SWG26 1967 |
Audio generator 10 Hz - 21 kHz | oe5mbl | MA0030010 | al-k2 |
|
|
CTR HRV-240 1967 |
VTVM | oe5mbl | MA0031020 | al-k2 |
|
| Cushman CE-15 1977 | Spectrum monitor | ecarn | MA0031500 | ra-lkk | |
| Czeija Nissl 1890 | Galvanometer +/- 7 mA, built 1890 in Vienna. Perfect original condition. | neu | MA0032000 | al | |
| DAIWA | SWR Meter |
family |
MA0032800 |
pr-bu |
|
| DRAKE W4 1970 | 3 - 30 MHz, Wattmeter | dpt. 01 | MA0033500 | ra-lkk |
|
| DRAKE WV4 1970 | 30 - 200 MHz, Wattmeter | dpt. 01 | MA0033550 | ra-lkk |
|
| Dynatra 204 F 1940 | French tube tester |
testf |
MA0033570 | al-k2 |
|
| Dytronics 244RS | Phase sensitive true RMS Voltmeter 1mV - 300V bandwidth 0 - 100 kHz - ok | Original | ve | MA0034000 | sh1 |
| EICO 460 1956 | Oscilloscope, tubes 3x6SN7, 2x5Y3, 2x6J5, 5BP1, supply 117VAC | original | 8111 | MA0034210 | ra-kü |
| EICO 324 1956 | Wide range signal generator, tubes 12AV7 (ECC-type), ECC82, supply 117VAC | x | 3812 | MA0034200 | al-ku |
| EICO 368 19xx | TV-FM Sweep Generator and Marker, tubes 12AV7(ECC-type) ECC81 ECC83 EF94 12B4(EC-type) EZ90 | x | 3812 | MA0034220 | al-ku |
| EICO 460 1956 | Oscilloscope, tubes 3x6SN7, 2x5Y3, 2x6J5, 5BP1, supply 117VAC | original | 8111 | MA0034210 | al-ku |
| EKA Csömérö tube tester 1940 | Hungarian tube tester made by Engel Karoly Tungsram in Budapest, supply 220VAC (selectable also lower AC supply voltages) | - | nikl | MA0034400 | ra-to |
| Elektro_Mechanik_List Berlin Galvanometer 1948 | Microampèremeter/galvanometer with mirror scale. sensitive to 1uV/div. | - | wza | MA0034500 | al-k2 |
| ELGE OSM3 "Oszillometer" 1948 | Mains operated instrument for voltage, current, LCR measurements, resonance determination and signal generator. Equipped with a single EF13. Main analogue display instrument partially blocked. | Original | wgl50 | MA0035000 | al |
| ELGE OSM3
"Oszillometer" 1948 |
Mains operated instrument for voltage, current, LCR measurements, resonance determination and signal generator. Equipped with a single EF13. Main analogue display instrument partially blocked. | family |
MA0035010 | al-k2 |
|
| ELGE OSM3
"Oszillometer" 1948 |
Mains operated instrument for voltage, current, LCR measurements, resonance determination and signal generator. Equipped with a single EF13. Glass of dial broken. | steyr |
MA0035020 | al-bu |
|
| ELMES Ohmmeter 1970? | Battery operated resistance meter | prev | MA0036000 | al-k2 |
|
| ELMES Type 20 1965 | FET Multimeter type ELMES 20 from R. Staub AG - ok (needs two flat batteries 4.5 V) | none | automnales palexpo | MA0037000 | al |
| ELMES Type 1 1965 | Multimeter | ri | MA0038000 | al |
|
| Elwyn MFR/PN102 | Elwyn test lead set | tam | MA0039000 | al |
|
| EMA Fuse tester | Fuse tester | ecarn | MA0039500 | al |
|
| EMA ballast | ballast box for fuse tester | ecarn | MA0039600 | al |
|
| Engler hourmeter | Dashboard hourmeter | family | MA0039650 | al-k2 | |
| Erba voltage tester 1980 | Double lamp voltage tester 100-500VDC or VAC | family | MA0039660 | al-bu | |
| ESI 250DE | Very precise RLC measurement bridge. Accuracy 0.1%. Measures resistance, inductance, capacitance. Battery supply 6 Volt | wgl50 | MA0040000 | al |
|
| Euratele Köln Euratele II 1965 | Tube tester, requires Voltammeter RPG II as indicator for tube parameters | original | nikl | MA0040200 | ra-to |
| Euratele Köln RPG II 1965 | Voltammeter corresponding to tube tester EURATELE II | original | nikl | MA0040201 | ra-to |
| Eurelco SQ10 | 10Hz to 1MHz signal generator, sine and square wave option | IP32seller | MA0040500 | al-k2 |
|
| Excelsior Kiesewetter Vollnetz "D" | Universal tube tester, perfectly ok |
wgl50 |
MA0041000 | al |
|
| Excelsior Kiesewetter Mod. 39 | Universal tube tester, perfectly ok |
wgl50 |
MA0042000 | al |
|
| Exupère Gas detector | Gas leakage detector |
dor |
MA0042100 | al-fu |
|
| FC1GYO frequency Counter | 6 decade frequency counter | fc1gyo | MA0042500 |
al-k2 |
|
| FC1GYO model 158 | Field Strength and SWR meter, also equipped with a QRP-tuner | fc1gyo | MA0042600 |
al |
|
| Ferranti Current Clamp | Current Clamp Ammeter 6 - 600 A | salz | MA0043000 |
pr cav (stolen) |
|
| FF | Small pneumatic leak tester | ri | MA0044000 | al-we |
|
| Fluke 87 | Handheld True RMS Digital Multimeter | fa | MA0045000 | pr | |
| Fluke 112 | Handheld True RMS Digital Multimeter | sp | MA0046000 | al |
|
| Fluke 895A 1981 | Differential voltmeter for voltages up to 1.1kV | Ecarn | MA0046500 | al |
|
| Fluke 8100B | Nixie tube digital multimeter - ok | F'hafen | MA0047000 | al-k2 |
|
| Fluke 80i-600 | Large conductor diameter current clamp, current ratio 1ma/A, bandwidth 50kHz | Copy of manual | Mike | MA0047050 | al-ku |
| Fluke Y8101 | Small conductor diameter current clamp, current ratio 1ma/A | Mike | MA0047051 | al-ku |
|
| Fluke Y8101 | Small conductor diameter current clamp, current ratio 1ma/A | Mike | MA0047052 | al-ku |
|
| Fluke Y8102 type K 19xx | Sheathed thermocouple for connection to DMM with temperature function, range from -40 to 814 degrees Celsius | Mike | MA0047053 | al-ku |
|
| Foxboro tba | Air pollution detector | ecarn | MA0047500 | al |
|
| FRAPIC Ampèremeter 19xx | Panel ampèremeter | oevg | MA0047550 | al-fu |
|
| Funkamateur FA-8 2020 | Antenna impedance analyser | box73 | MA0047700 | al-bu | |
| General Radio 1001B 1949 | 20 kHz to 50 MHz signal generator with original adapters and cables | original | Frö | MA0048000 | al-rkk |
| General Radio 1656 | Impedance Bridge | original | wgl50 | MA0049000 | al-ku |
| Gertsch FM-3 | Frequency Meter (receiver and overtone generator) 20 - 1000 MHz | partly original | be | MA0050000 | al-k2 |
| GIFAS MT10_25 19xx | Three and single phase tester up to 25A, tests cables and equipment against all VDE-requirements, equipped with German single phase and CEE-type three phase connectors 16A and 32A. Runs on 230VAC. | partly original | dor | MA0050500 | ra-lkk |
| Goerz Minitest 3 | Versatile small multimeter, including capacitor measurent range; original probes. | original | ri | MA0051000 | al-k2 |
| Goerz Multiscript_3 19xx | Plotter/Recorder, without paper roll motor | none | ri | MA0051500 | ra-wk |
| Goerz Unigor
1n 1965 |
Multimeter, ruggedized for Swiss military | original | ri | MA0052000 | al |
| Goerz Unigor
3n 1964 |
Multimeter | do-bh | MA0053000 | al |
|
| Goerz Unigor 3n 1964 | Multimeter | hed | MA0054000 | al |
|
| Goerz Unigor 3p 1967 | Multimeter | wgl50 | MA0055000 | al |
|
| Goerz Unigor_3p 1967 | Multimeter | wgl50 | MA0056000 | ra-lkk |
|
| Goerz Unigor_3p 1967 | Multimeter | do | MA0057000 | al |
|
| Goerz Unigor 3p 1967 | Multimeter | hed | MA0058000 | al |
|
| Goerz Unigor 3p 1967 | Multimeter | kaheiho | MA0058500 | ra-wk |
|
| Goerz Unigor
3p 1964 |
Multimeter | zieg | MA0052500 | al-fu |
|
| Goerz Unigor 3s 1963 | Multimeter | hed | MA0059000 | al |
|
| Goerz Revitester 100 19xx |
Power outlet system tester | 3812 | MA0059400 | ra-kü |
|
| Goerz Universal HV (T.126205) 1954 |
General purpose multimeter with HV position | meissen | MA0059500 | al |
|
| Goerz WZI 300 | Current clamp ammeter | do | MA0060000 | ba | |
| Goerz GE4196 19xx | 30kV voltage divider | do | MA0060100 | al | |
| Goerz 50kV | 50kV voltage divider | do | MA0060120 | al | |
| GOKA hydraulics gauge 0-250bar | Hydraulics pressure gauge with sphere shutter | holl | MA0060770 | al-we |
|
| Gossen 0413 1975 | FI-FU tester | do |
MA0061000 |
ra-lkk |
|
| Gossen 0701 1975 | Differential circuit breaker tester | do |
MA0061500 |
al-ku |
|
| Gossen Isolation Meter | Crank-up type insulation meter | wgl50 | MA0062000 | al |
|
| Gossen Mavolux | Luxmeter from 1 Lux to 3000 Lux | hed | MA0063000 | al |
|
| Gossen Panel meter 40A 19xx | 72mm x 72mm panel meter | oevg | MA0063120 | al-fu | |
| Gossen Miniature panel meter | 25mm x 25mm miniature panel meter, one plus/minus 900ADC range using a 135mV shunt | bo | MA0063130 | al-fu | |
| Gossen round panel meter 1940 | Wartime black round panel meter fitting into 80mm hole. Producer code "bmr" (=Gossen, Wetzlar), 500VAC or DC | vitis | MA0063140 | al-we | |
| Gossen table meter in wooden box 1940 | Wartime black table meter. Producer code "bmr" (=Gossen, Wetzlar), 500mA AC or DC | 8111 | MA0063150 | al-we | |
| Gould Advance DMM7A 19xx | DMM | kaheiho | MA0064400 | ra-wk | |
| Gould Advance OS3000A 1977 | Oscilloscope | kaheiho | MA0064500 | ra-lkk | |
| GRANIT DMM 2022 | Auto-ranging digital multimeter with protective cover | kainz_stainz | MA0064600 | ra-kü | |
| Greiner MUI 1960 | Watchmaker's electronic voltmeter with plug-in for testing small batteries | puc | MA0064700 | al |
|
| Grundig MO20
1985 |
20MHz TV service oscilloscope, supply 220VAC |
co, Ser.Nr.6115 |
MA006500x | accidentally destroyed |
|
| Grundig MO32 1985 | Dual channel 30MHz TV service oscilloscope, supply 230VAC | Ser. Nr. 101 027 000 |
MA0065000 | ra-kü | |
| Grundig Q 1978 |
"Tonhöhenschwankungsmesser" |
krems |
MA0065300 | al-k1 |
|
| Grundig SV1 1960 | Signal tracer | serial 4083 | wgl50 | MA0065500 | ra-lkk |
| Grundig UV4 1970 | FET Voltmeter, supply 1.5VDC dry longlife battery and
rechargeable battery 12VDC or mains unit 220VAC,
transistors AC126 ASY26 ASY26 BC107 BC107 BC107 BFY39
BFY39 BF115 BF115 |
paper copy |
hirsch | MA0065600 | ra-we |
| Grundig WS3 1964 | UHF Wobbler, tubes ECC86 ECC86 ECC86 PCC88 ECC85 EF80 |
paper copy |
BB | MA0065700 | al-k1 |
| Grundig 701
"Resonanzmeter" 1957 |
Classic "dip" meter from 100 kHz to lower VHF range | wgl50 | MA0066000 | al |
|
| Haas & Streit AG Tension (Force) Meter | Precision mechanical force (tension) meter by leverarm, range 0 - 50 pond (0 - 490 mN or 0 - 0.49 Newton) | family | MA0067000 | al |
|
| Hallicrafters BC-221 (SCR-211)
1941 |
WW II Frequency Meter (part of SCR-399) | phil | MA0068000 | al |
|
| Hallicrafters HO-1 1964 |
Kit of 5" Oscilloscope with vertical bandwidth of 5MHz, horizontal response is 4Hz to 400kHz with a sensitivity of 120 mV/cm, rise time of 0.08 microseconds, priced at 85 USD. Remark: Unit was also available fully wired called HOW-1 | pvc | MA0068500 | ra-wk |
|
| Hameg HM-107 1965 |
Oscilloscope | wgl50 | MA0069000 | al-ku | |
| Harden 661004 2023 |
True RMS DMM | Qala | MA0069100 | sü | |
| Hartmann & Braun Elavi 12 1957 |
UIR-Meter | ri | MA0069500 | al |
|
| Hartmann & Braun Kapavi 1937 |
C-Meter 10pF - 10microF, f=800Hz, buzzer for 800Hz missing, output indicator = earphones, very high price before the war at one fifth of the cheapest car | Berndorf | MA0069600 | ra-lkk |
|
| Hartmann & Braun Isolavi 1948 | Precision isolation meter 500VDC using a vibrator inverter off a rechargeable battery. | ri | MA0069700 | al |
|
| Hartmann & Braun Isolavi 2 1955 | Precision isolation meter 500VDC using a vibrator inverter off a 4V battery. | family | MA0069800 | al |
|
| Hartmann & Braun Isolavi 7 1971 | Precision insulation meter, supply 6V NiCd-accumulator, built-in charger from 230VAC | Kainz_Stainz | MA0069822 | ra-kü |
|
| Hartmann & Braun Multavi 1 1933 |
Precision multimeter | family | MA0069900 | al | |
| Hartmann & Braun Multavi 2 1934 |
Precision multimeter | family | MA0070000 | al | |
| Hartmann & Braun Pontavi 1933 |
Precision measurement bridge with null indicator, internal battery or external bridge supply | hed | MA0070100 | al |
|
| Hartmann & Braun Pontavi Wh2 1960 | Precision measurement bridge with null indicator, internal battery or external bridge supply | ndeut | MA0070101 | al | |
| Hartmann & Braun Wattavi 1979 |
Precision Wattmeter 300V 5A | hed | MA0070200 | ra-wk |
|
| Hartmann & Braun Leistungsmesskoffer
19xx |
Three phase power and phase succession measurement system in metal carrying case | wh | MA0071000 | ra-kü |
|
| HB (Hartmann & Braun) JK 5000N 1970 | Isolation meter 500VDC with manual crank | Kainz_Stainz | MA0071100 | ra-kü |
|
| Heathkit AA-1 | Audio Analyser: Measures Audio power, voltage, distortion for testing audio amplifiers | wgl50 | MA0077000 | ra-m11 |
|
| Heathkit AF-1 | Audio Frequency Meter: measures voltages up to 100 Khz | wgl50 | MA0078000 | ra-m11 | |
| Heathkit AG-9A | Audio Frequency generator | andi | MA0078500 | al-m11 | |
| Heathkit AO-1U 1965 |
Sine Square Generator | wgl50 | MA0079000 | ra-m11 | |
| Heathkit AO-1U | Sine Square Generator | bhb | MA0079010 | al-k2 | |
| Heathkit COA-1015 | Engine tester | eb | MA0080000 | al | |
| Heathkit EC-1 1956 |
Analogue Computer | wgl50 | MA0081000 | ra-lkk |
|
| Heathkit ET-3400G 1977 |
Microcomputer learning system, using a Motorola 6800
processor |
All manuals, serial 1002 | wgl50 | MA0082000 | ra-m11 |
| Heathkit EUW-19A 1965 |
Operational amplifier system - set of four operational amplifiers with free wiring on the front panel - the "Analogue Computer" | ri | MA0083000 | ra-lkk |
|
| Heathkit GD-1U 1965 |
Grid Dip Meter with all coils plus set of auxiliary VLF coils (works) | OE5NG | MA0084000 | al |
|
| Heathkit GD-48 1970 |
Metal detector (works after repair of transport damage and leaky battery case) | eb | MA0085000 | al |
|
| Heathkit GD-125 1966 |
Q-Multiplier | wgl50 | MA0086000 | ?? | |
| Heathkit HD-1250 1975 |
Battery operated FET dipmeter | wgl50 | MA0087000 | al |
|
| Heathkit HD-1422 1985 |
Antenna noise bridge | eb | MA0088000 | ra | |
| Heathkit HD-1426 1957 |
Relative Field Strength Meter | eb | MA0089000 | al |
|
| Heathkit HM-15 1966 |
SWR meter 3 - 30 MHz 50 Ohm | ase | MA0090000 | al |
|
| Heathkit IA-1 1966 |
Ignition Analyser | Original | wgl50 | MA0091000 | ra |
| Heathkit IA-1 1966 | Ignition Analyser | Original | eb | MA0092000 | ra |
| Heathkit IB-2 1960 | LCR Impedance Bridge with hand null | Original | eps | MA0093000 | ra-m11 |
| Heathkit IB-2A 1961 | LCR Impedance Bridge with hand null | Original | ndeut | MA0094000 | ra-m11 |
| Heathkit IB-3128 1965 | LCR Impedance Bridge with hand null | Original | wgl50 | MA0094010 | ra-m11 |
| Heathkit ID-101
1971 |
Dual trace input circuit for monotrace oscilloscopes | ri | MA0094500 | al |
|
| Heathkit ID-4001
1975 |
Digital Weather Computer with Mostek microprocessor |
epw | MA0095000 | ra-m11 |
|
| Heathkit IG-18
1969 |
Function generator | ri | MA0096000 | al | |
| Heathkit IG-28 1969 |
TV colour bar and dot generator, output via clip cables | co1070 | MA0097000 | ra-m11 |
|
| Heathkit IG-52 1965 |
TV alignment generator | wgl50 | MA0098000 | ra-m11 |
|
| Heathkit IG-72E 1962 |
Audio generator | Ser.Nr.526 | wgl50 | MA0099000 | ra-m11 |
| Heathkit IG-102 1965 |
Signal generator 0.1 - 110 MHz (in daily use) | ase | MA0100000 | al |
|
| Heathkit IG-112 1965 |
FM-stereo generator | wgl50 | MA0101000 | ra-m11 | |
| Heathkit IM-11/D 1961 |
VTVM (vacuum tube volt meter) | Ser.Nr.2596 | wgl50 | MA0102000 | ra-m11 |
| Heathkit IM-11/D 1961 | VTVM (vacuum tube volt meter) | wgl50 | MA0102010 | al-m11 |
|
| Heathkit IM-11 1961 | VTVM (vacuum tube volt meter) | eb | MA0103000 | al |
|
| Heathkit IM-12 1963 |
Distortion Meter | wgl50 | MA0104000 | ra-m11 |
|
| Heathkit IM-13 1964 |
VTVM (vacuum tube volt meter) | wgl50 | MA0105000 | ra-m11 |
|
| Heathkit IM-13 1964 |
VTVM (vacuum tube volt meter) | wgl50 | MA0106000 | ra-m11 | |
| Heathkit IM-13 1964 |
VTVM (vacuum tube volt meter) | 3812 | MA0106000 | al-ku | |
| Heathkit IM-16 1964 |
VTVM (FET volt meter) | jo | MA0106022 | ra-kü | |
| Heathkit IM-17G 1971 |
Utility volt meter | wgl50 | MA0107000 | ra-m11 | |
| Heathkit IM-17 1968 |
Called "Utility Voltmeter" by the manufaturer; it is actually a multimeter for voltage and resistance, needs 9V and 1.5 V battery, not yet calibrated | ri | MA0108000 | al |
|
| Heathkit IM-17G 1971 |
Called "Utility Voltmeter" by the manufaturer; it is actually a multimeter for voltage and resistance, needs 9V and 1.5 V battery, not yet calibrated. Inside view. | ri | MA0108500 | al |
|
| Heathkit IM-18 1961 |
VTVM | eb | MA0109000 | al |
|
| Heathkit IM-18D 1971 | VTVM (vacuum tube volt meter) | wgl50 | MA0110000 | ra-m11 |
|
| Heathkit IM-18D
1971 |
VTVM, all inscriptions in German | ri | MA0111000 | al-m11 |
|
| Heathkit IM-21 | manual only (contains schematic for VTVM using 6AW8 followed by EF184/6EJ7) | original | ri | MA0112000 | al |
| Heathkit IM-21E 1962 |
NF Millivoltmeter, VTVM for AC,
using two tubes (6AW8 triode/penthode, EF 184) |
prig | MA0114100 | al-k2 |
|
| Heathkit IM-21D 1962 |
NF Millivoltmeter, VTVM for AC, using two tubes (6AW8 triode/penthode, EF 184) | wgl50 | MA0113000 | ra-lkk |
|
| Heathkit IM-21D 1962 |
NF Millivoltmeter, VTVM for AC, using two tubes (6AW8 triode/penthode, EF 184) | wgl50 | MA0114000 | ra-m11 |
|
| Heathkit IM-25 1967 | Solid state FET volt meter | fa | MA0115000 | ra-m11 |
|
| Heathkit IM-25 1967 |
Solid state FET volt meter (does not work because it uses reference voltage batteries that are removed) | eb | MA0116000 | ra-m11 |
|
| Heathkit IM-28 1970 | VTVM | ri | MA0116500 | al |
|
| Heathkit IM-30 1962 | Transistor Tester | wgl50 | MA0117000 | ra-m11 |
|
| Heathkit IM-36 1967 | Transistor tester | oe5mbl | MA0118000 | ra-m11 | |
| Heathkit IM-38 1969 | NF Millivoltmeter | Ser.Nr.344 | wgl50 | MA0119000 | ra-m11 |
| Heathkit IM-1202 1973 | Nixie tube digital voltmeter, one of the first | ri | MA0120000 | al |
|
| Heathkit IM-2202 1975 | LED digital voltmeter | eps | MA0121000 | al |
|
| Heathkit IM-5218 1982 | VTVM (vacuum tube volt meter) | wgl50 | MA0122000 | al | |
| Heathkit IM-5218 1982 | VTVM (vacuum tube volt meter) | wgl50 | MA0123000 | ra-lkk |
|
| Heathkit IO-12 1962 | Oscilloscope | wgl50 | MA0124000 | ra-wk |
|
| Heathkit IO-12S 1962 | Oscilloscope, special version for
schools |
wgl50 | MA0125000 | ra-wk |
|
| Heathkit IO-12 1962 | Oscilloscope | eb | MA0126000 | da | |
| Heathkit IO-18 1971 | Oscilloscope | wgl50 | MA0127000 | ra-wk |
|
| Heathkit IO-18U 1973 | Oscilloscope | eb | MA0128000 | da | |
| Heathkit IO-21 1961 | Oscilloscope, bandwidth 100kHz, tubes 4xECC82, ECC83, EZ90, 1V2 HV rect., 3RP1 cathode ray tube, supply 220VAC, mass 4.3kg | zieg | MA0128140 | ra-wk | |
| Heathkit IO-103 1973 | Transistorised service oscilloscope bandwidth 10 MHz | winkling | MA0128500 | al-k2 |
|
| Heathkit IO-4235
1982 |
Dual trace oscilloscope bandwidth 35 MHz |
Original | eps | MA0129000 | ra-lkk |
| Heathkit IO-4550 1982 | Oscilloscope | wgl50 | MA0130000 | ra-kü | |
| Heathkit IT-11 1963 |
Capacitance measurement bridge and tester with magic eye indicator - not yet tested | wgl50 | MA0131000 | ra-m11 | |
| Heathkit IT-11 1963 | Capacitance measurement bridge and tester with magic eye indicator - works very well on all ranges | eb | MA0132000 | al |
|
| Heathkit IT-12 1962 | Signal Tracer | wgl50 | MA0133000 | ra-m11 | |
| Heathkit IT-17 1967 | Universal tube tester |
wgl50 |
MA0134000 | al |
|
| Heathkit IT-18 1968 | Portable Transistor Tester | fa | MA0135000 | al |
|
| Heathkit IT-18 1968 | Portable Transistor Tester; wooden case, test leads added for better connection of transistors. | willh | MA0135500 | al |
|
| Heathkit IT-27 1971 | Transistor Tester | wgl50 | MA0136000 | ? | |
| Heathkit IT-28 1969 | Capacitor Checker | wgl50 | MA0137000 | ? | |
| Heathkit IT-1121 1974 | Transistor curve tracer | fa | MA0138000 | al |
|
| Heathkit IT-121 1973 | Transistor/FET curve tracer | Ser.Nr. 165 | wgl50 | MA0139000 | ra-m11 |
| Heathkit IT-7400 19xx | Digital IC Tester | Ser.Nr. 3644 | wgl50 | MA0139500 | ra-m11 |
| Heathkit O-11 1957 |
oscilloscope, no markings |
wgl50 | MA0140000 | ra-wk |
|
| Heathkit O-12S 1960 |
oscilloscope for schools | wgl50 | MA0141000 | ra-wk |
|
| Heathkit OS-2 1971 | Small uncalibrated oscilloscope for audio frequencies up to 100 kHz | wgl50 | MA0142000 | al-ku |
|
| Heathkit OS-2 1971 |
Small uncalibrated oscilloscope for audio frequencies up to 100 kHz | hb9ase+ | MA0143000 | al |
|
| OE6CY Calibrator 1971 | 10/100/1000 kHz transistorised calibration generator | 6cy | MA0143500 | ra-kü |
|
| Heathkit OS-2 1971 |
Small uncalibrated oscilloscope for audio frequencies up to 100 kHz | oe6wu+ | MA0144000 | al |
|
| Heathkit QM-1
1955 |
"Q" Meter | ri | MA0145500 | ra-lkk |
|
| Heathkit QF-1 1956 |
"Q"-multiplier | wgl50 | MA0145000 | ra-m11 | |
| Heathkit RF-1U
1973 |
Signal generator | mbl | MA0146000 | al | |
| Heathkit SG-8 1954 | Signal generator, 1954 model, 160 kHz - 220 MHz, original condition | wgl50 | MA0147001 | ra-m11 |
|
| Heathkit SG-8 1954 | Signal generator, 1954 model, 160 kHz - 220 MHz, original condition | ri | MA0147002 | al |
|
| Heathkit SG-8 1954 | Signal generator, 1954 model, 160 kHz - 220 MHz, with two circuit improvements and an add-on output level meter | Original | ri | MA0147003 | al |
| Heathkit SG-8 1954 | Signal generator, 1954 model, 160 kHz - 220 MHz | orig | bhb | MA0147004 | ra-m11 |
| Heathkit SG-8 1954 | Signal generator, 1954 model, 160 kHz - 220 MHz, modified connectors, bolted to Heathkit AG-9A | andi | MA0147005 | al-m11 | |
| Heathkit S-3 1958 |
Electronic switch | wgl50 | MA0150000 | ra-m11 |
|
| Heathkit TS-4A 1956 |
TV alignment Generator | wgl50 | MA0151000 | ra-m11 | |
| Heathkit TT-1A 1960 |
Universal tube tester, with socket extension, perfectly ok | Original | wgl50 | MA0152000 | dany |
| Heathkit TT-1 1960 |
Universal tube tester, with socket extension, perfectly ok | ua3adr | MA0153000 | al |
|
| Heathkit T-3 1958 |
Visual/aural signal tracer | wgl50 | MA0154000 | ra-m11 | |
| Heathkit V-7A 1957 |
VTVM (vacuum tube volt meter) | wgl50 | MA0155000 | ra-lkk |
|
| Heathkit V-7A 1957 | VTVM | Original | lfu | MA0156000 | al |
| Heathkit V-7A 1957 | VTVM, quarter inch cinch connector, no test leads | ri | MA0156500 | Nova Lh. | |
| Heathkit RF-probe | t.b.a. | fa | MA0157000 | al |
|
| Heathkit Demodulator Probe | t.b.a. | fa | MA0158000 | al |
|
| Heiru voltage tester 1980 | Double lamp voltage tester 100-500VDC or VAC | sig |
MA0158100 | al-we | |
| Hewlett Packard 141T 1969 | Spectrum Analyzer up to 110 MH, additional HP-8556A low frequency plug-in | ce | MA0159000 | ra-lkk |
|
| Hewlett Packard 410B 1955 | Vacuum tube voltmeter, tubes: 2-01C=EA53 UHF-diode for the probe, 2x12AU7=ECC82 6X4=EZ90 6-4(=FeH resistor) and 0B2 voltagestabiliser | wgl50 | MA0160000 | al-ku |
|
| Hewlett Packard 410B 1955 | Vacuum tube voltmeter, tubes: 2-01C=EA53 UHF-diode for the probe, 2x12AU7=ECC82 6X4=EZ90 6-4(=FeH resistor) and 0B2 voltage stabiliser | wgl50 | MA0161000 | al-ku | |
| Hewlett Packard 425 1960 | Vacuum tube milliammeter.
Sophisticated separation of input and display section by
synchronous modulator/demodulator ensemble using 4 light
bulbs, a mechanical light beam interrupter and
photocells. The four bulbs are GE #12 bulbs. A fifth
bulb is used for the dial lamp. Tubes 5751 12AX7 12AT7
6X4 0B2 0A2. |
ecarn | MA0161500 | al |
|
| Hewlett Packard 461A 1972 | 1 kHz - 150 MHz small signal amplifier 20dB/40dB | ua3adr | MA0162000 | al-k2 |
|
| Hewlett Packard 465A 1972 | Signal Broadband Amplifier
20dB/40dB 5Hz - 1MHz |
ua3adr | MA0163000 | al-k2 |
|
| Hewlett Packard 628A 1955 | Microwave signal generator 15
-25GHz |
BB | MA0163100 | al-k1 |
|
| Hewlett Packard 3580A 1980 |
Low frequency spectrum analyser | |
ecarn | MA0163500 | al |
| Hewlett Packard 3586A 1980 |
Selective Level Meter (or shortwave receiver), AM/CW/SSB, 20 Hz - 32.5 MHz, tracking generator 0 dBm, option 004 high stability - out of service because of bad fan | Copy on CD-ROM | electropuces | MA0164000 | al |
| Hewlett Packard 3586A 1980 |
Selective Level Meter (or shortwave receiver), AM/CW/SSB, 20 Hz - 32.5 MHz, tracking generator 0 dBm, option 004 high stability - noisy fan, unit has trouble to synchronise PLL when exposed to temperatures below 10 degrees C | STA Sarl, Napoli | MA0165000 | al |
|
| Hewlett Packard 8640 1974 |
Signal generator, AM/CW, 0.1 - 520 MHz, option back power protection 50W | ce | MA0166000 | al-k2 |
|
| Hewlett Packard 8590 1991 |
Spectrum analyser | ecarn | MA0166500 | al |
|
| Hewlett Packard 8595A 1991 |
Spectrum analyser | 3eh | MA0166550 | al-fu |
|
| Hewlett Packard 34401A 1996 |
6 1/2 digit system multimeter | oevg | MA0166570 | al-fu |
|
| Hewlett Packard tba | Probe preamplifier | ecarn | MA0166600 | al |
|
| Hewlett Packard tba | H-field probes | ecarn | MA0166700 | al |
|
| Hickok 202N 1950?? |
Ruggedised vacuum tube volt-, ohm-
and milliampmeter, stamped US Navy |
1110 | MA0166800 | ra-wk | |
| Hickok KS-15560L1 1960 |
Universal tube tester, perfectly
ok, made by Hickok for Western Electric, bears
RD-Instruments marks on outer case, based on Hickok 539,
tubes 83 and 5Y3 |
Original (in pre) | wgl50 | MA0166850 | al-ku |
| Hickok 600 1951 |
Universal tube tester, tubes 83 5Y3GT | Original | wgl50 | MA0166900 | al-wo |
| Hickok (RD Instruments) RD1700 | Universal tube tester, restored by a very devoted German collector who even constructed a wooden custom-made protection box, installed brand-new tubes and a custom-made copy of the original filament transformer that is down with insulation fault on one of its 11 (!) windings | Copy, attached to protection box | wgl50 | MA0166950 | ra-lkk |
| Hickok 6000 1957 |
Universal tube tester, perfectly ok | Original | wgl50 | MA0167000 | al-wo |
| Hickok Cardmatic (AN/USM118B)
1965 |
Universal tube tester, ruggedised,
in military transport box, with second box "MK827"
containing all cards, tubes 6AU6 6DQ6 5U4 6X4 |
Original | wgl50 | MA0167100 | al-ku |
| Hickok 870 1964 |
Dynamic transistor tester |
Original | shw | MA0167200 | al-fu |
| HIOKI Tester | URI-Tester in leather case | oe5mbl | MA0172000 | al |
|
| HIOKI 3211 | Pencil tester | fa | MA0173000 | al |
|
| IME Z7-WA | Current transformer 250/5A | vitis | MA0173501 | al-vitis |
|
| IME TAS20B | Current transformer 250/5A | vitis | MA0173502 | al-vitis |
|
| IME TAS20B | Current transformer 250/5A | vitis | MA0173503 | al-vitis |
|
| IME TAS20B | Current transformer 250/5A | vitis | MA0173504 | al-vitis |
|
| Jako gauge | Combined pressure and temperature gauge for central heating | korherr | MA0173594 | ra-we |
|
| Jaquet DHR-905 19xx | Digital stroboscopic rpm meter, supply 6VDC by 4 AA-cells | whw | MA0174000 | al-fu |
|
| JBT Double Frequency Meter | Aircraft 60 and 400 Hz frequency meter | fhafen | MA0175000 | al |
|
| Jemco 821 1957 | Japanese vacuum tube voltmeter sitting in a stable swiss metal enclosure with remade wiring. Very professional layout. Classic design with 1.5V ref battery | ri | MA0216000 | al |
|
| Jewell MS2T | 100µADC moving coil panel meter, new in box | bo | MA0175500 | al |
|
| JOY-IT JT-LCR-T7 2022 | Intelligent component tester, supply from accumulator charged via USB | reichelt | MA0175550 | al-fu |
|
| Keck Raymond Genève type THF81 | Frequency generator step settable, using one EAF80 and an external power source | no doc | dany | MA0176000 | al |
| Kimmel LC580K
1965 |
LC Bridge in R&S-style | oe5mbl | MA0178000 | al-ku |
|
| Knight VTVM
1969 |
Vacuum tube voltmeter | cx9aab | MA0179000 | al-ku |
|
| Kontron DMM
3003 19xx |
Digital multimeter with HV-probe | mike | MA0179505 | ra-wk |
|
| KP VAT
set 19xx |
Voltage tester for HV distribution | willh | MA0179500 | al-k2 |
|
| KP clamp 19xx |
600A current clamp ratio 1:1000 | willh | MA0179510 | al-k2 |
|
| KP clamp 19xx |
600A current clamp ratio 1:1000 | willh | MA0179520 | al-k2 |
|
| KP HV
tester 19xx |
3-30kV safety tester | willh | MA0179530 | al-we |
|
| Kyoritsu K-1420 VTVM | Kyoritsu vacuum tube volt meter | ri | MA0180000 | al |
|
| Kyoritsu Current Clamp Multimeter | Kyoritsu Current Clamp Multimeter for field use | eb | MA0181000 | al |
|
| Landers, Frary and Clark TS-505 D/U
1958 |
Vacuum tube voltmeter with RF-detection capability, type
TS-505D/, mains supply 117 VAC 50 - 1000 Hz, around 1958,
tubes 6AU6 6AU6 12AT7 6AL5 6X4 NE32 NE32 |
ri | MA0182000 | ce | |
| LANTELME Thermometer 2022 | Analogue thermometer for grill, range 500 degrees Celsius | oevg | MA0182050 | al-fu |
|
| Leader LCR-740
1984 |
Battery operated LCR-Bridge with Q-function | original | fa | MA0183000 | al |
| Leader LDC-824
1979 |
520 MHz Counter | fa | MA0184000 | al |
|
| Leader LDM-170
1976 |
Distortion Meter | original | fa | MA0185000 | al |
| Leader LDM-815
1974 |
Battery operated Dip-Meter | original | fa | MA0186000 | al |
| Leader LSG-16
1970 |
RF Signal generator | wza | MA0187200 | al-k1 |
|
| Leader LSG-231
1970 |
FM Stereo Signal generator | fa | MA0187000 | al |
|
| Leader LBN-06 | Measurement and impedance adapter cable | fa | MA0187100 | al |
|
| Logic Probe LP-2050 | Logic Probe with memory | fa | MA0188000 | al |
|
| Lorenz TV-7/U 1944 | Vacuum tube tester | Ser.Nr.190 | crp | MA0271600 | ra-to |
| Lyon Instruments (listed under Eurelco) SQ10 | This Lyons Instruments apparatus bears "Eurelco" markings | MA0040500 | al-k1 |
||
| Marconi TF2100
1970 |
AF Generator | wza |
MA0189200 | al-k1 |
|
| Marconi TF2600
1970 |
Sensitive Millivoltmeter, sensitive down to 0.1 mV, ranges from 1 mV to 3 V Full Scale | wza |
MA0189100 | al-k1 |
|
| Marconi TF2603
1970 |
RF Millivoltmeter with incomplete probe set in wooden box, useful from 10 kHz to 3000 MHz, sensitive down to 0.1 mV, ranges from 1 mV to 3 V Full Scale | original | do |
MA0189000 | al |
| Marconi TF995A
1955 |
Signal generator, tubes EB91 6AK6 6AU6 QS150/15 | original | BB |
MA0189200 | al |
| Mashpriborintorg (MPI Moscow) Z435 1968 | Russian multimeter, in metal container, with test leads | original | bak | MA0275930 | ra-m1 |
| Mashpriborintorg (MPI Moscow) Z4313 1971 | Russian multimeter, in metal container, with test leads | original | tief | MA0275940 | al |
| Mashpriborintorg (MPI Moscow) Z4315 | Russian multimeter - ok | F'hafen | MA0276000 | al |
|
| Mashpriborintorg (MPI Moscow) Z4315 1971 | Russian multimeter - backplate missing | oe5mbl | MA0277000 | ra-lkk |
|
| Mashpriborintorg (MPI Moscow) Z4341 | Russian multimeter/transistor tester | oe5mbl | MA0278000 | ra-lkk |
|
| Mashpriborintorg (MPI Moscow) Z4342 | Russian multimeter/transistor tester | meissen | MA0278500 | al-k1 |
|
| Matsushita hourmeter | Hourmeter, supply 220VAC | oevg | MA0278600 | al-fu |
|
| Matter Patocchi Measurement Unit "Uni" | Monophase and Threephase Volt/Ampère/Wattmeter combination in wooden box | ri | MA0190000 | ra-wk |
|
| Maxon Motors "LSC30" 2011 | Multi purpose servo amplifier | holl | MA0190500 | al-we |
|
| Maxon Motors "LSC30" 2011 | Multi purpose servo amplifier | holl | MA0190501 | al-we |
|
| Megger | Ohmmeter, erroneous function | ko_Wi | MA0191000 | al |
|
| Mercer GAMMA | Mechanical measuring device, range 5mm, precision 2 microns | ri | MA0191500 | al |
|
| MIW Voltmeter | Analogue panel voltmeter, 72x72mm, 100VDC | oevg | MA0191510 | al-fu |
|
| MTM Wheatstone Bridge 1955 | Low resistance bridge made by VEB Mellingen Thüringen (now MTM) | fa | MA0275500 | al-ku | |
| Metrawatt Metrapont RLC G19
1963 |
RLC Bridge | oe5mbl | MA0192000 | ba | |
| Metrawatt Terrafix III
1960 |
Ground impedance meter, range up to 10kOhms, manual crank supply | orig | Kainz_Stainz | MA0192500 | ra-kü |
| Metrix 232B 1963 | Sweep Analyzer "Wobuloscope", up
to 800MHz, tubes 6AF4A 6AF4A EF86 EF86 12AX7 ECF82 ECF82
6AQ5 12AT7 6X4 6X4 DG7-6 |
coll | MA0193000 | al |
|
| Metrix MX51/CX2000 | True RMS Liq Crystal Mulitmeter with preamplifier CX2000 and adapters for temperature, humidity, lux, windspeed | magn | MA0194000 | al |
|
| Metrix MX707
1977 |
Classic LED Mulitmeter with mains supply 230 VAC. Out of order after transport. | ri | MA0195000 | al-k2 | |
| Metrix U61 1955 | Universal tube tester, in original box, perfectly ok | Original |
wgl50 |
MA0196000 | al-ku |
| Metrix 310BTR 19?? | Universal tube tester, in original box, perfectly ok | Original, with amendments |
Pell |
MA0196050 | ra-lkk |
| Metrix 310 1968 | Universal tube tester | Copy |
jero |
MA0196100 | ra-lkk |
| Metrix 744 1960 | Vacuum Tube Voltmeter with 600 Mhz tube rectifier in probe, 220V supply, accurate and precise but twice as large as US-models - tested and calibrate, tubes 12AX7S EA52 6AL5 6BX4 | Copy | F9NS | MA0197000 | ra-lkk |
| MFJ 247 1995 | SWR Analyser ; modified for 12V supply from outside because internal batteries wear too fast. | F8RU | MA0198000 | ga | |
| Millen 90672 1962 | Antenna noise bridge | cx9 | MA0199000 | ga | |
| Miselco Electromaster | URI Meter | oe5mbl | MA0200000 | ba | |
| Monroe AC fieldmeter | AC fieldmeter, with telescopic highly insulating rod for insulator measurement | ecarn | MA0200500 | al |
|
| Moto Meter ASUtherm | Portable battery supplied ruggedized digital thermometer for oil or water temperature measurements in vehicle or stationary engines | fm | MA0201000 | pr-ga |
|
| Motorola S1327 1970 | Desk top service monitor for 2-way radios with
modulation scope, synthesizer, deviation meter and mixer |
copy of manuals |
lienz |
MA0201050 | al |
| MTM UNI 10 1979 | Transistorised Laboratory Multimeter from MTM
(Mellenbach, Thüringen, German Dem. Rep.) |
meissen | MA0201100 | al |
|
| Müter BMR 90 19xx | Cathode ray colour image tube tester and regenerator
with protective case and all necessary connection cables |
original | 3812 | MA0201130 | ra-wk |
| Munston AN-URM48 1955 | Signal Generator 20 - 102MHz, supply 230VAC, tubes
5Y3WG, OA2, 6AH6, 6AH6, 6C4W, 6AH6, 6AH6, RT1, 6J6W, 6AH6,
6AH6, 12AU5, 6AK6, 6C4W, 6C4W |
BB | MA0201150 | al-k1 |
|
| Narda 8616 | RF radiation monitor with two (huge) probes | ecarn | MA0201200 | al |
|
| Neuberger Elavi 12 | Multimeter in leather case | jogi | MA0201600 | al |
|
| Neuberger Testavo 10 | Transistor Multimeter - Electricians' multimeter, with 60A range and phase succession meter. Ruggedized. | ri-wk | MA0202000 | al |
|
| Neuberger Multimeter | Old style Volt-mA meter with banana plug changeover for measurement ranges | family | MA0203000 | al | |
| Neuberger RP 270 | Universal tube tester, perfectly ok |
wgl50 |
MA0204000 | al | |
| Neuberger RPM 375 | Universal tube tester, perfectly ok, with original set of coding cards | copy |
wgl50 |
MA0205000 | al |
| Neuberger W252 | Universal tube tester, perfectly ok |
wgl50 |
MA0206000 | al | |
| Neuberger Voltmeter | DC panel voltmeter 60V FS, protection glass damaged |
oevg |
MA0206100 | al-fu | |
| NITRA intensity meter 19xx | Square panel meter, vertical mounting into 96 by 96mm
window, scale 0 - 100% |
willh | MA0206500 |
al-k1 |
|
| Nordmende FG 387 19xx | TV colour signal generator | fa | MA0207000 | al |
|
| Nordmende FG 3360 | TV colour signal generator | fa | MA0207000 | al |
|
| Nordmende SW3330 |
Signal generator and wobbler for TV-repair | fa | MA0208000 | al-k2 | |
| Nordmende UWM346/U-2
1969 |
Signal generator and wobbler for TV-repair | fa | MA0208000 | al-k2 | |
| NORMA PK110
1965 |
Clamp type Ampèremeter with additional leads for voltage
measurements. Accuracy given for 50Hz operation only. |
kran | MA0208520 |
al |
|
| NORMA 1805
28303/2384298 1968 |
"Erdungsmesser" (Earth measurement bridge) | do | MA0208500 | al | |
| NORMA 1805 GB 2
D/E 1968 |
"Erdungsmesser" (Earth measurement bridge), with protective leather case | originaL | 3812 | MA0208501 | ra-kü |
| NORMA Wheatstone-Thomson Bridge | Precision low resistance bridge in Thomson configuration, in metal case | mike | MA0208600 | al-ku |
|
| NORMA Insulation Test Meter | Isolation and mains tester, battery operated using six LR6-size dry batteries. Battery case like new. With leather protection case and test leads | original | do | MA0209000 |
al |
| NORMA Insulation Test Meter | Isolation and mains tester, battery operated using six LR6-size dry batteries. Battery case like new. With leather protection case and test leads | original | do | MA0209001 |
al |
| NORMA 66801 Insulation Test Meter | Isolation and mains tester in large box, with charging cable from 230VAC and possibility to run the apparatus directly from an external 12VDC source, measures insulation resistance at 1kv, 2.5kV or 5kV test voltage | original, in the cover | Kainz_Stainz | MA0209023 | ra-kü |
| NORMA 66702 Insulation Test Meter | Isolation and mains tester, battery operated using six LR6-size dry batteries | do | MA0210000 | al | |
| NORMA FI_FU Tester | Fault voltage and fault current detection tester | do | MA0210500 |
al |
|
| NORMA phase succession meter | Phase succession meter using miniature asynchronous motor with visible rotor indicating the phase succession | family | MA0211000 |
al |
|
| NORMA type U,I,P set or Drehstrommesskoffer 1965 | In large carrying case there are analogue precision AC voltmeter, AC ammeter and eletrodynamic wattmeter plus two 4-range current transformers. | htl10 | MA0212000 |
ra-lkk |
|
| NORMA Wattmeter | Classic electrodynamic wattmeter 520 - 260 - 130V and 1 - 5 Amps. Displays U times I times cosphi | ebu - eva | MA0213000 |
al |
|
| NORMA type 1811GB4D/E ("Normatronic FET") 1975 | Battery-operated (2x9V, 1x1.5V AA) FET input multimeter, also known as Normatronic FET | original | wi | MA0214000 |
al-k1 |
| NORMA Normacord 19xx | 2 channel paper roll data recorder | none | whw | MA0214020 | ra-sto1 |
| NORMA type Normatest 2000 1975 | Classic multimeter | ? | gk | MA0214150 |
al-k2 |
| NORMA type Normatest 2000 1975 | Classic multimeter | ? | eb | MA0214151 |
ra-kü |
| NORMA type Normameter GW 1937 | Classic analogue AC/DC multimeter in original leather carrying case with test leads, two AC-shunts, two DC-shunts and current clamp | kaut | MA0214170 | ra-kü | |
| NORMA type Normameter S2 1975 | Analogue AC/DC multimeter | roth | MA0214180 | ra-lk | |
| NORMA type Type 450 19xx | 12 channel measurement recorder | 3812 | MA0214185 | al-ku | |
| NORMA -50/+100A panel meter | Shunt type square panel meter, vertical mounting into 96
by 96mm window, scale -50 to 100ADC, shunt 100A/60mV |
willh | MA0214200 |
al-k1 |
|
| NORMA 10VAC 19xx | Square panel meter, vertical mounting into 96 by 96mm
window, scale 0 - 10VAC |
willh | MA0214220 |
al-k1 |
|
| NORMA 25VAC 19xx | Square panel meter, vertical mounting into 96 by 96mm
window, scale 0 to 25VAC |
willh | MA0214240 |
al-k1 |
|
| NORMA 100/5A 19xx | Square panel meter, vertical mounting into 96 by 96mm
window, scale 0 to 100A |
family | MA0214241 |
al-RS291 |
|
| NORMA 100/5A 19xx | Square panel meter, vertical mounting into 96 by 96mm
window, scale 0 to 100A |
family | MA0214242 |
al-RS291 |
|
| NORMA 100/5A 19xx | Square panel meter, vertical mounting into 96 by 96mm
window, scale 0 to 100A |
family | MA0214243 |
al-RS291 |
|
| NORMA "vitis"19xx | Moving iron type panel meters, vertical mounting into 96 by 96mm window, 400VAC, 80A direct, 200A direct, 50A direct, 100mA, 5A | vitis | MA0214244-49 | al-vitis | |
| NORMA GE2472 19xx | Norma 5A 10A 20A combined shunt |
garsten | MA0214221 |
al-k2 |
|
| NORMA GE2473 19xx | Norma 15A 25A combined shunt |
garsten | MA0214222 |
al-k2 |
|
| NORMA GE2477 19xx | Norma 60A 100A combined shunt |
mike | MA0214231 |
al-ku |
|
| NORMA GE2477 19xx | Norma 60A 100A combined shunt |
mike | MA0214232 |
al-ku |
|
| NORMA 680101302 19xx | 16MOhm_4800V_HV divider |
garsten | MA0214223 |
al-k2 |
|
| NORMA GE2475 19xx | 30A 50A combined shunt |
garsten | MA0214224 |
al-k2 |
|
| NORMA 680102101 19xx | 1200VDC_divider |
garsten | MA0214225 |
al-k2 |
|
| NORMA 680102201 19xx | 1500VAC_divider |
garsten | MA0214226 |
al-k2 |
|
| NORMA 680501006 19xx | Current clamp 500:1 |
garsten | MA0214227 |
al-k2 |
|
| NORMA 680501004 19xx | Current clamp 1000:1 |
garsten | MA0214228 |
al-k2 |
|
| NORMA ts 19xx | Temperature sensor for Normatronic_FET |
garsten | MA0214229 | al-k2 | |
| NORMA 8 panel meters | 8 Panel meters (3x100A direct, 3x200A via CT 5A, 1x100A via CT 5A, 1x300A via CT 5A | 3812 | MA0214230-37 | al-we | |
| Oerlikon Brass Ampère Meter 1904 | Current meter 100A max., switchboard model with polished brass exterior | ri | MA0214250 | al |
|
| OE3HKA DIP Meter 19xx | DIP meter with 21 ranges (coils) | vka | MA0214260 | al |
|
| OE6WU SWR | SWR and power meter | OE6WU | MA0215000 | al | |
| Optoelectronics Counter | 55/550 MHz frequency counter | fc1gyo | MA0215500 | al | |
| Oritel RO 310 1991 | RF generator 1.5 - 30 MHz feeds SWR meter for three possible impedances (50, 75 600 Ohms) | orig | emir | MA0215550 | ra-kü |
| PeakTech 1020A 2021 | Miniature multimeter for low voltage | reich | MA0215700 | al-fu | |
| Philips GM28891958 | AM/FM measurement signal generator 5-525MHz, tubes EC81
EC81 EC81 ECC81 EAA91 ECL82 PY82 |
3812 |
MA0216040 | al-ku |
|
| Philips GM2892 1960 | TV pattern generator |
3812 |
MA0216049 | al-ku |
|
| Philips GM2892/40 1960 | TV pattern generator |
kaheiho |
MA0216050 | ra-lkk |
|
| Philips GM4144 1950 | "Philoskop" CR Bridge with optical ("magic eye") indicator, 3 tubes EZ40 EF40 EM4 | ka | MA0216500 | ra-lkk |
|
| Philips GM4144 1950 | "Philoskop" CR Bridge with optical ("magic eye") indicator, 3 tubes EZ40 EF40 EM4 | kaheiho | MA0216510 | ra-kü |
|
| Philips GM4579B 1950 | RF probe with tube for GM6009 VTVM |
kaheiho | MA0216550 | ra-kü |
|
| Philips GM5650 1957 | Small TV-service oscilloscope - tested Feb. 2017. Tube complement PCF80 PCC85 EAA91 PCF80 PCC85 PCF80 EZ80 EAA91 DG7-32 | wgl50 | MA0217000 | al |
|
| Philips GM5650 | Oscilloscope | wgl50 | MA0218000 | al |
|
| Philips GM5655/01 1946 | Small oscilloscope up to a 100 kHz; uses only 6 tubes (3xECH21, DG7-6, 2x EZ2) | wgl50 | MA0219000 | al |
|
| Philips GM5655 | Small oscilloscope up to a few MHz | F6FGI | MA0220000 | pr |
|
| Philips GM5659 1955 | Laboratory oscilloscope with shade | kaheiho | MA0220000 | ra-p1 |
|
| Philips GM5659 1955 | Laboratory oscilloscope with shade | 3812 | MA0220001 | al-ku |
|
| Philips GM6009 1957 | Service VTVM with the famous E80CC, including active RF probe etc. | kaheiho | MA0220500 | ra-lkk |
|
| Philips GM6009 1957 | Service VTVM with the famous E80CC, including active RF probe etc. | 3812 | MA0220501 | al-ku |
|
| Philips GM6058 1955 | Top notch VTVM, including active RF probe etc. | oe5mbl | MA0221000 | ra-lkk |
|
| Philips GM7628 1950 | Signal tracer with RF probe | kaheiho | MA0221100 | ra-lkk |
|
| Philips GM7628 1950 | Signal tracer with RF probe | 3812 | MA0221101 | al-ku |
|
| Philips GM3156 1940 | Early Philips oscilloscope from 1940, using DN9-5 EC50 5xEF6 1876 AZ1 2x4687. The price was 1200 RM. The instrument was more expensive than the VW beetle priced at 990 RM. For comparison, the average salary was 300 RM. | gr | MA0216000 | ra-lkk |
|
| Philips GM3156 1940 | Oscilloscope - the apparatus lost its original case and
was inserted into a small kitchen cabinet with a double
door. We assume that it was left over by troops after WWII
and promptly "civilised", or stolen and hidden. Tube
complement as originally designed by Philips: DN9-3 or -5,
5xEF6, EC50, plus four tubes for the power supply: AZ1 for
low voltage, 1876 for the high voltage plus two 4687 gas
regulator tubes. |
ramsau |
MA02160001 | ra-sto1 |
|
| Philips PM3231 1960 | Philips oscilloscope | family | MA0216100 | al-ku |
|
| Philips PR9300 | Impedance bridge with probe cables | ecarn | MA0221500 | ra-lkk |
|
| Philips PR9300 | Impedance bridge, no accessories | ecarn | MA0221502 | ra-lkk |
|
| Polymetron Type 39C pH-Meter | Mains operated pH-meter with one ECL80, one FeH-Resistor and measurement probe, made by Hach & Lange | ri | MA0222000 | al |
|
| RACAL 314A | Mains operated VTVM | Nick | MA0222500 | al |
|
| RACAL 9055 | Calibrator | ecarn | MA0222700 | al |
|
| Radiometer Copenhagen pA-Meter 1965 | Mains operated Pico Ampère and Megaohm Meter | wgl50 | MA0223000 | ra-lkk |
|
| Radiometer Copenhagen BKF6 1965 | Distortion meter | wza | MA0223100 | al-k1 |
|
| Radiometer Copenhagen RV24 1965 | Mains operated VTVM | wza | MA0223200 | al-k1 |
|
| RAHAM fieldmeter | Field meter for RF | ecarn | MA0223500 | al |
|
| RAU air gauge 0-4bar | Pressure gauge | holl | MA0223600 | al-we |
|
| RCA WV-98A | VTVM "senior voltohmist" vacuum tube voltmeter | cx9 | MA0224000 | al |
|
| RCA radio Testset 1955?? | Testset for connection to 11-pin socket at the rear of certain radios and amplifiers for determining voltages, gain, field strength, activation of PTT, and modulation from microphone or external LF-source, speaker. Apparatus is completely passive but has a small speaker in the rear panel. | Berndorf | MA0224100 | ra-lkk |
|
| RFT Funkwerk Dresden M2746 1952 | Signal generator 100kHz - 18MHz, tubes 2xEF12 and stabiliser GR145/DP, supply 220VAC | Eggenburg | MA0224200 | ra-kü |
|
| Rohde & Schwarz HHF | Field Strength Meter, with all rotatable frame antennas, 2.5 MHz - 25 MHz 220 VAC or 6 VDC 1microVolt/meter to 100milliVolt/meter | F1OFQ | MA0225000 | ba | |
| Rohde & Schwarz KARU | Capacitance Bridge | oe5mbl | MA0226000 | al-ku | |
| Rohde & Schwarz KARU | Capacitance Bridge (dismounted) | oe5mbl | MA0227000 | al-ku | |
| Rohde & Schwarz KRH | Capacitance Bridge | oe5mbl | MA0228000 | al-ku | |
| Rohde & Schwarz KRT | Capacitance meter | ecarn | MA0228500 | al | |
| Rohde & Schwarz NAUS4 | RF forward and reflected power meter for 50 Ohms, covering 25 to 1000MHz | wgl50 | MA0229000 | al | |
| Rohde & Schwarz SLRD | Signal Generator AM/FM, 225 MHz - 2525 MHz | Original | schreiber_EMC | MA0230000 | al |
| Rohde & Schwarz SMAF | Signal Generator 8.5 - 216 MHz with AM/FM modulation | Copy | oe5mbl | MA0231000 | al-ku |
| Rohde & Schwarz SMFA | Signal Generator AM/FM, 0.5 MHz - 525 MHz | Copy | vebeg | MA0232000 | al |
| Rohde & Schwarz SMLR | Signal Generator AM/FM, 0.1 MHz - 30 MHz | Orig | Ulf Norw | MA0233000 | al |
| Rohde & Schwarz URI 1964 | VTVM for current, resistance and voltage measurement up to 20 MHz | wgl50 | MA0234000 | al | |
| Rohde & Schwarz URI 1964 | VTVM for current, resistance and voltage measurement up to 20 MHz | oe5mbl | MA0235000 | al |
|
| Rohde & Schwarz UTKT 1945 | VTVM for RF voltage measurement up to 100MHz with tube-equipped probe, tubes RD12Ta in the probe, MSTV140/60Z as stabiliser, EZ11 as rectifier. Supply 220VAC. | hri | MA0235010 | al-fu | |
| Rohde & Schwarz WAM | Resonance frequency meter 30 MHz - 500 MHz | Orig | Ulf Norw | MA0236000 | ra-lkk |
| Rohde & Schwarz SNF 19xx | Norm video generator | whw | MA0236100 | al-fu | |
| SACI Ampèremeter 19xx | Panel ampère meter for use with current transformer 40/5A | oevg | MA0236150 | al-fu | |
| Scheldt NS 10/65 1965 | Power line tester for FU-type protection (meanwhile banned) | unknown | MA0236200 | al-k1 | |
| Schlumberger FSM500 1975 | VHF/UHF Generator for radio debugging | wza | MA0236300 | al-k1 | |
| Schlumberger IP500 1975 | Power meter for radio debugging | wza | MA0236310 | al-k1 |
|
| Schoeller & Co Frankfurt pocket voltmeter 6-120V 1933 | Pocket Multimeter "Taschen Voltmeter", 6V and 120V range with probes fixed to case. AC & DC function. Silver case. | ri | MA0236500 | al |
|
| Schoeller & Co Frankfurt pocket voltmeter 6-240V 1933 | Pocket Multimeter "Taschen Voltmeter", 6V and 240V range with probes fixed to case. AC & DC function. Silver case. | ri | MA0236600 | al |
|
| Schoeller Multimeter | Multimeter in wooden case | family | MA0237000 | al | |
| Schulmeister Galvanometer 18xx | Galvanometer | dor | MA0237100 | al-fu | |
| Scuola Radio Elettra (S.R.E.) Tube checker 1951 | Mains operated compact tube checker; to be used with the matching multimeter from the same company. | Original | Nick | MA0237500 | al-k1 |
| SECO GTC-5 | Tube tester limitd to the most current tubes, testing 4 things: grid emission, vacuum, filament to cathode short, grid-to-cathode leakage. A magic eye will open (and look at you) upon inserting a bad tube. | ri | MA0238000 | al-k1 |
|
| SEI Ammeter 19xx | Clamp type multi range ammeters in carrying case | wh | MA0238500 | ra-mu | |
| Shunt 1kA | Heavy brass shunt for precision current measurements | ce | MA0239000 | al |
|
| Shunt 2kA | Heavy nickel shunt for precision current measurements | ce | MA0240000 | al |
|
| Siemens 60A 19xx | Square panel meter, vertical mounting into 96 by 96mm
window, scale 0 - 60AAC - 120AAC, direct connection |
willh | MA0240200 |
al-k1 |
|
| Siemens Milliohmmeter 19xx | High precision digital milliohmmeter | mike | MA0240400 | ra-kü |
|
| Siemens low resistance bridge | Bridge-type Ohmmeter | ecarn | MA0240500 | al |
|
| Siemens plusminus30mA.jpg | Switchboard milliammeter for positive/negative current | oe5mbl | MA0241000 | al |
|
| Siemens AC Voltmeter 19xx | 3-range AC Voltmeter in wooden box | mh | MA0241020 | ra-kü |
|
| Siemens Meters V&mA | Set of large scale meters | family | MA0242000 | al | |
| Siemens Ohmmeter | Ohmmeter, 2 ranges, battery operated | oe5mbl | MA0243000 | ga | |
| Siemens Ohmmeter | Ohmmeter, battery operated | family | MA0244000 | ga | |
| Siemens HalskeVoltmeter 19xx | Multi range Voltmeter in wooden case, switchable to 150/300/600 Volt full scale | wh | MA0244100 | ra-wk |
|
| Siemens SAM317W 1961 | Measurement receiver for TV antenna alignment | none | kaheiho | MA0244600 | ra-lkk |
| Siemens SAM372aSt 1967 | Battery operated (12 x LR20) measurement receiver for medium wave, short wave and FM-band, built-in speaker, no possibility for external power supply, complete with cable set, modified for external 12 - 18 VDC power | none | kk | MA0244500 | ra-lkk |
| Siemens SAM372 1967 | Battery operated (12 x LR20) measurement receiver for medium wave, short wave and FM-band, built-in speaker, no possibility for external power supply | none | ri | MA0245000 | al |
| Siemens SAM390a 1966 | TV level meter for three TV bands, using oscilloscope like display | none | kk | MA0245500 | al |
| Siemens S 43202-M-C 1977 | TV level meter for two TV bands, using oscilloscope like display | none | puc | MA0245550 | al |
| Siemens Rel_SK_VII_8_15_F 1935 | RF Generator for receiver debugging and calibration,
tubes AC2 AC2 RGN354 |
none | chr | MA0245560 | ra-p1 |
| Siemens Rel_3W_432_a4b 19xx | Random noise level oscillator 12kHz - 12MHz | none | BB | MA0245570 | al-k1 |
| Sigogne Multimeter 1890 | Voltage and current gauge from Paris, dated 1890 | none | atten | MA0245750 | al-ku |
| Simpson 240 | Multimeter with additonal 3kV range | ri | MA0246000 | al |
|
| Simpson 260 | Multimeter | do | MA0247000 | ba | |
| Simpson 260 | Multimeter | do | MA0248000 | ba | |
| Simpson 260 | Multimeter, empty but meter ok | GE flea | MA0249000 | al |
|
| Simpson 269 | Multimeter | cx9 | MA0250000 | al |
|
| Simpson 479 | FM Signal Generator | ri | MA0250500 | al | |
| Simpson I-177B 1952 | Military tube tester I-177B, tubes 83 and 5Y3GT, supply 117VAC 60Hz, booklet missing | msalz | MA0250600 | al-fu | |
| SAA (Société d'Appareillage Aéronautique) Manomètre | Pression pressure gauge, used as variometer in old aircraft, can measure positive and negative pressures up to 300 mbar | ri | MA0251000 | al |
|
| SUN VAT-60 1982 | Automotive tester for alternators and batteries | do | MA0251400 | al-ku | |
| Sylvania 140 1946 | Tube tester. Supply 110 VAC. Instructions printed on inner side of cover. Tube 1LE3 (=VT-239). | eb | MA0251500 | al |
|
| Tachometerwerke TSG model TAVO | Universal meter for various electrical measurements, using a range of adapters, all neatly arranged in a wooden shock absorbing box | n | ni | MA0252000 | al-k2 |
| TECH Tradiper TE-15 Dipmeter | 9VDC Battery operated instrument for resonance
measurements of LC circuits, with 5 coils and two
transistors OC44 and OC45 |
None | OE5UVL |
MA0034500 | al |
| Tektronix Mod. 422 | 20 MHz portable Oscilloscope with original probes, power cable, cover, bag for accessories, parts kit, manual | Original | fa | MA0253000 | al-k2 |
| Tektronix Mod. 464 1975 | 100MHz dual trace portable storage oscilloscope | with attached Battery Pack | mik | MA0253100 | al-ku |
| Tektronix Mod. 465 Service Manual | Full service Manual | Original | fa | MA0254000 | sch |
| Tektronix 524D 1951 | TV-service oscilloscope of the fifties with 61 tubes, mass 27kg, supply 220VAC | - | wurz | MA0254400 | al-ku |
| Tektronix 536 1957 | X-Y oscilloscope mainframe of the fifties with phase error of max. 1 degree up to 15MHz, with plug-ins type "G", "A", "D", "1A2", "T", 31 tubes of types EL180 (12BY7), ECC189 (6DJ8), QQE03/12 (6360), E83CC (12AX7), EF94 (6AU6), ECC230 (6080), 5642 HV rectifier, E82CC (12AU7), EL90 (6AQ5), E180CC (6BQ7A), 5651 (93V low current stabiliser), CRT Tektronix T5360-31 with equal vertical and horizontal sensitivity, mass 26kg. Nota: The tube listing does not include the tubes of the plug-in units | Original | kemm | MA0254500 | al-ku |
| Tektronix 545B 1964 | 30 MHz Oscilloscope of the fifties with original chariot and plug-ins type "D", "M", "CA", 56 tubes of types EAA91 (6AL5), 6AU5, EF94 (6AU6), 6L43 (6CL6), E88CC (ECC189, 6DJ8), UB91 (12AL5), HF94 (12AU6), E82CC (12AU7), E83CC (12AX7), 12B4, EL180 (12BY7), 5642, 5651, ECC230 (6080), E182CC (7119), E810F (7788). Mass 30kg. | wgl50 | MA0255000 | al-ku D in ra-lkk, M in al-ku, CA built-in |
|
| Tektronix RM564 | Oscilloscope 10 MHz series "5" with 4 plug-in units - ok | ce | MA0256000 | al-k1 |
|
| Tektronix 10A1 1967 | Differential amplifier/comparator plug-in unit for the Tektronix 647 or RM647 oscilloscope | Original | tali | MA0256500 | al-ku |
| Tektronix R7704 | Oscilloscope 400 MHz 4 channel with 7 plug-in units - ok | vebeg | MA0257000 | al-we |
|
| Tektronix P6021 | Current probe for oscilloscope | ce | MA0258000 | al |
|
| Tektronix P6021 | Current probe for oscilloscope | Original | fa | MA0259000 | al |
| Tektronix AM 503 19xx | Current probe amplifier for oscilloscope | - | Mike | MA0259100 | al |
| Telefunken Austria P0474 1942 | Completely shielded RF generator 100kHz - 30MHz in a
suitcase for portable use, using two tubes UCH4 and one
UY1N, supply 220VAC |
pyhra | MA0252550 | al-ku |
|
| Telefunken Austria P0474 1942 | Completely shielded RF generator 100kHz - 30MHz in a
suitcase for portable use, using two tubes UCH4 and one
UY1N, supply 220VAC |
nickel | MA0252551 | ra-lkk |
|
| Telefunken Austria P0461-1 1941 | Tube tester, tubes RGN354 and AZ12, supply 220VAC |
3812 | MA0252560 | al-ku |
|
| Telequipment D54 1959 |
20 MHz portable Oscilloscope | ecarn | MA0252500 | al |
|
| Telequipment D54 1959 | 20 MHz portable Oscilloscope | kk | MA0252502 | al |
|
| Telequipment D61a 1975 | Portable Oscilloscope 10 MHz |
kaheiho | MA0252504 | ra-lkk |
|
| Thermophil 4421 | Precision electronic thermometer | he | MA0260000 | al |
|
| Thermophil 4445 | Precision electronic thermometer | he | MA0261000 | al |
|
| Thurlby Thandar SM620 | Multi function meter: Oscilloscope, Multimeter, Serial Analyser, counter, data logger | copy | ri | MA0262000 | ti |
| TLH 154 19xx | Wobbler 8 - 220 MHz centre frequency | copy | BB | MA0262100 | al-k1 |
| TMK 700 1960 | Multimeter with with 10A and 5000V range | puce | MA0262500 | al |
|
| Triplett 1200E 1934 | Multimeter with two meters | cx9 | MA0263000 | ra-lkk |
|
| Trüb und Täuber Zürich Wattmeter | AC & DC 0.15% precision Waltmeter with two switchable ranges: 30-150-300-450 Volts, 2.5 and 5 Ampères | GE flea | MA0264000 | al |
|
| Trüb und Täuber Zürich Clamp Ammeter 1955 | Clamp ammeter with integrated voltmeter and provision to connect to the secondary of current transformers | sig | MA0264100 | al-bu |
|
| Trüb und Täuber Zürich Voltmeter | AC Voltmeter with two switchable ranges: 0-60 VAC, 0-600 VAC | ri | MA0265000 | al |
|
| Trüb und Täuber Zürich Ampèremeter | AC Ampèremeter 5A | ri | MA0265500 | al |
|
| Trüb und Täuber Zürich Miniature panel meter | 25mm x 25mm miniature panel meter, one 60VDC range | bo | MA0265600 | ra |
|
| Uni-T Multimeter 2023 | Digital multimeter | 8th-km | MA0265700 | süv-fu | |
| Unisound DT-1202 | Analogue multimeter with test leads | Gr.-S. | MA0265750 | ra-kü | |
| Unitec 76983 | Automotive tester. Connecting cord for ignition missing. | puce | MA0265800 | pr | |
| Unknown maker: VTVM | VTVM VT-650; looks like (Japanese) copy of Heathkit IM-18; could be coming from Radio Riehm München | oe5mbl | MA0266000 | al-k2 |
|
| Unknown maker Galvanometer 18xx | Galvanometer with unknown company logo featuring an ornamented light bulb | dor | MA0266100 | al-fu | |
| Unknown maker: Ammeter | Switchboard moving iron ammeter 5A with current transformer scales indicating 300A - not functional - for museaum only | oe5mbl | MA0267000 | al |
|
| Unknown maker: Ammeter | Switchboard moving iron ammeter 30A | oe5mbl | MA0268000 | al |
|
| Unknown maker: Ammeter | Switchboard moving iron ammeter 500A (without current transformer!) | oe5mbl | MA0269000 | al |
|
| Unknown maker: Milliammeter | Milliammeter in box for three ranges: 300mA, 3000mA, 15000mA | oe5mbl | MA0270000 | al |
|
| Unknown maker: Voltmeter | Small switchboard or front panel voltmeter 40mm diameter, single 400VDC range, square appearance from front | family | MA0270500 | al |
|
| Unknown maker: Voltmeter | Switchboard voltmeter 200mm diameter | puc | MA0271000 | al |
|
| Unknown maker: VTCT prewar or WWII | Vacuum tube tester for tube comparison, running two equal tubes as audion and LF-amplifier,, with auditive test and extensive metering | wh-horn | MA0271500 | ra-lkk |
|
| Unknown maker: RF-Ammeter | Switchboard thermo-coupled RF current meter, probably from a large transmitter, 0 - 15 Amps, frequencies and further spec's unknown | ri | MA0272000 | al |
|
| Unknown maker: Static Voltmeter | Electrostatic voltmeter with brush for surface charge detection | ecarn | MA0272300 | al |
|
| Unknown maker: Voltmeter | Moving iron voltmeter, 150/300/600V ranges, in leathercase | Gr.-S. | MA0272400 | ra-kü | |
| Unknown maker: Voltmeter | Moving iron voltmeter, 600V full scale, in leathercase | Gr.-S. | MA0272401 | ra-kü | |
| Unknown maker: Volt and Ammeter | DC voltmeter 15V f.s. and ammeter 10A f.s. in metal case with test leads | Gr.-S. | MA0272402 | ra-kü | |
| Unknown maker: calibrator | Calibration generator for 100kHz and 1MHz harmonics | family | MA0272500 | al |
|
| Unknown maker: presumably Wattmeter | Presumably wattmeter made for a school project | whw | MA0272520 | al-fu |
|
| Unknown maker: Batterie tester 19xx | Tester with load resistor for lead battery testing cell by cell | egg | MA0272522 | al-ku | |
| Unknown maker: mV-meter 19xx | Homemade UIR meter in wooden box, R-bridge supplied by dry battery | 8111 | MA0272523 | al-we | |
| Unknown Soviet maker DP-5B 1955 | Battery operated radiation meter (Geiger counter) | bak | MA0272530 | süv |
|
| Unknown Soviet maker Pressure Gauge 30 19xx | Pressure gauge for vehicular use, 60bar max. | bak | MA0272550 | al-ku |
|
| Unknown Soviet maker Frequency Meter 19xx | Panel meter 47-53Hz, resonant steel blades | bak | MA0272570 | al-ku |
|
| Unknown Soviet maker Frequency meter motorized 19xx | Motor type frequency meter 350 - 450 Hz | bak | MA0272590 | al-ku |
|
| Voltcraft M-3650 B | Classic 3 1/2 digit handheld multimeter | Original | family | MA0273000 | stolen (pr) |
| Wavetek Model DM71 | Pencil Multimeter | kuk | MA0273500 | ra-lkk | |
| Wavetek Model 185 | 5 MHz function generator and (triggerable) wobbler | fa | MA0274000 | al |
|
| Weston 749 1950 | Clamp-on Ampèremeter and voltmeter, complete with instructions, leather case and test cable set | Original | ri | MA0274500 | al |
| Weston 774-5 1942 | Tube tester and multimeter | none | msalz | MA0274550 | ra-kü |
| WF LC-Meter | LC bridge | dany | MA0275000 | al |
|
| WIKA air gauge 0-2500mbar | Pressure gauge | holl | MA0275100 | al-we |
|
| WIKA air gauge 0-2500mbar | Pressure gauge | holl | MA0275101 | al-we |
|
| WIKA air gauge 0-2500mbar | Pressure gauge | holl | MA0275102 | al-we |
|
| WIKA air gauge 0-2500mbar | Pressure gauge | holl | MA0275103 | al-we |
|
| WIKA air gauge 0-25bar | Pressure gauge | holl | MA0275104 | al-we |
|
| WSW Panel meter 19xx | Panel ampere meter, moving iron type, range 0 - 5 Amps AC, scale 0 - 600A | hub | MA0275500 | al-k2 |
|
| WSW Multizet 1946 | Multimeter for voltage and current, DC and AC, no resistance bridge | velden | MA0275520 | al-fu |
|
| L3-3
1969 (Korpus Plant, Saratov) |
Russian tube tester, internal tubes 6P1P 6P1P 6P1P 6P1P 6Ж3P 6Ж3P 6Ж3P 6Ж3P 6Ж3P 6Н3P 6Н3P 6Н3P SG15P SG15P SG15P 5Ц4М 6Z4P 6Z4P | tief | MA0275900 | al |
|
| JU16 | Russian lux meter | ri | MA0279000 | al |
|
| ZECA battery tester | Cell-by-cell load tester for lead batteries | willh | MA0280000 | ba | |
| Zellweger SE-415 tester | 4-fold test apparatus with oscilloscope, vacuum tube voltmeter, AF and RF generator, made as radio system tester for the Zellweger SE-415 radio station | dl1cq | MA0290000 | al-k2 | |
Radio Collection, Aerials
and Accessories, Electron Tubes, Power Converters, Generators
and Traction Batteries, Transformers,
Telegraph Collection, Audio
Material Collection, Measurement
Apparatus Collection
![hourmeter](Matsushita_Hourmeter.jpg"){kind=link}
